| Domestic |
|
9/17/241619Z
|
!LVN 09/008 LVN OBST TOWER LGT (ASR 1019789) 444121.00N0930422.00W (7.6NM ENE LVN) 1753.0FT (798.9FT AGL) U/S 2409171619-2503172359
|
| FDC |
|
10/15/242018Z
|
!FDC 4/9424 LVN IAP AIRLAKE, MINNEAPOLIS, MN.
ILS OR LOC RWY 30, ORIG-G...
ADF REQUIRED EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
FOW VOR/DME OUT OF SERVICE. 2410152018-2412172018EST
|
|
5/11/231739Z
|
!FDC 3/4997 LVN IAP AIRLAKE, MINNEAPOLIS, MN.
ILS OR LOC RWY 30, ORIG-G...
DISREGARD NOTE: WHEN CIRCLING TO RWY 12 AT NIGHT, OPERATIONAL VGSI REQUIRED, REMAIN ON OR ABOVE VGSI GLIDEPATH UNTIL THRESHOLD.
CIRCLING RWY 12 NA AT NIGHT.
2305111739-2505101739EST
|
|
5/11/231739Z
|
!FDC 3/4996 LVN IAP AIRLAKE, MINNEAPOLIS, MN.
VOR RWY 12, AMDT 3A...
CHANGE NOTE TO READ: STRAIGHT-IN RWY 12 AT NIGHT, OPERATIONAL VGSI REQUIRED, REMAIN ON OR ABOVE VGSI GLIDEPATH UNTIL THRESHOLD.
2305111739-2505101739EST
|
|
5/11/231739Z
|
!FDC 3/4995 LVN IAP AIRLAKE, MINNEAPOLIS, MN.
RNAV (GPS) RWY 30, ORIG-B...
LPV DA 1208/HAT 250 ALL CATS.
LNAV MDA 1340/HAT 382 ALL CATS.
CHANGE ALTERNATE MINIMUMS TO READ: STANDARD - CAT D 800-2 1/4; NA WHEN LOCAL WEATHER NOT AVAILABLE.
DISREGARD NOTE: WHEN CIRCLING TO RWY 12 AT NIGHT, OPERATIONAL VGSI REQUIRED, REMAIN ON OR ABOVE VGSI GLIDEPATH UNTIL THRESHOLD.
CIRCLING RWY 12 NA AT NIGHT.
DISREGARD NOTE: RWY 30 HELICOPTER VISIBILITY REDUCTION BELOW 3/4 SM NA.
2305111739-2505101739EST
|
|
5/11/231739Z
|
!FDC 3/4994 LVN IAP AIRLAKE, MINNEAPOLIS, MN.
RNAV (GPS) RWY 12, AMDT 1...
LNAV/VNAV DA 1350/HAT 390 ALL CATS.
CHANGE NOTE TO READ: STRAIGHT-IN RWY 12 AT NIGHT, OPERATIONAL VGSI REQUIRED, REMAIN ON OR ABOVE VGSI GLIDEPATH UNTIL THRESHOLD.
CHANGE ALTERNATE MINIMUMS TO READ: STANDARD - 800-2 1/4; NA WHEN LOCAL WEATHER NOT AVAILABLE.
2305111739-2505101739EST
|
|
4/18/231948Z
|
!FDC 3/3353 LVN PART 1 OF 3 ODP AIRLAKE, MINNEAPOLIS, MN.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 12: TERRAIN 11 FT FROM DER, 191 FT
RIGHT OF CENTERLINE, 954 FT MSL.
LIGHT POLE 38 FT FROM DER, 4 FT LEFT OF CENTERLINE, 3 FT AGL/955 FT
MSL.
LIGHT POLE 39 FT FROM DER, 6 FT RIGHT OF CENTERLINE, 3 FT AGL/955
FT MSL.
TERRAIN 94 FT FROM DER, 297 FT RIGHT OF CENTERLINE, 958 FT MSL.
TERRAIN 108 FT FROM DER, 453 FT RIGHT OF CENTERLINE, 959 FT MSL.
TERRAIN 168 FT FROM DER, 378 FT RIGHT OF CENTERLINE, 961 FT MSL.
TERRAIN, LIGHT POLES BEGINNING 187 FT FROM DER, 7 FT RIGHT OF
CENTERLINE, UP TO 964 FT MSL.
LIGHT POLE 258 FT FROM DER, 5 FT LEFT OF CENTERLINE, 10 FT AGL/961
FT MSL.
TRAVERSE WAYS, TERRAIN, TREE, LIGHT POLES BEGINNING 334 FT FROM
DER, 6 FT RIGHT OF CENTERLINE, UP TO 979 FT MSL.
LIGHT POLE 479 FT FROM DER, 4 FT LEFT OF CENTERLINE, 14 FT AGL/965
FT MSL.
LIGHT POLES BEGINNING 697 FT FROM DER, 3 FT LEFT OF CENTERLINE, UP
TO 20 FT AGL/969 FT MSL.
FT AGL/1056 FT MSL. 2304181948-2504181948EST
END PART 1 OF 3
!FDC 3/3353 LVN PART 2 OF 3 ODP AIRLAKE, MINNEAPOLIS, MN.
TREE 1291 FT FROM DER, 506 FT LEFT OF CENTERLINE, 1002 FT MSL.
TREES BEGINNING 3623 FT FROM DER, 874 FT RIGHT OF CENTERLINE, UP
TO 104 FT AGL/1046 FT MSL.
RWY 30: LIGHT POLE 1 FT FROM DER, 111 FT RIGHT OF CENTERLINE, 3 FT
AGL/961 FT MSL.
LIGHT POLE 1 FT FROM DER, 112 FT LEFT OF CENTERLINE, 2 FT AGL/963
FT MSL.
TERRAIN BEGINNING 108 FT FROM DER, 482 FT LEFT OF CENTERLINE, UP TO
965 FT MSL.
BUILDING 172 FT FROM DER, 407 FT RIGHT OF CENTERLINE, 985 FT MSL.
POLES, TRAVERSE WAYS, BUILDINGS, TREE BEGINNING 337 FT FROM DER,
258 FT RIGHT OF CENTERLINE, UP TO 1000 FT MSL.
TREES, TRAVERSE WAYS BEGINNING 407 FT FROM DER, 508 FT LEFT OF
CENTERLINE, UP TO 995 FT MSL.
POLE, BUILDING, TRAVERSE WAYS, TREE BEGINNING 548 FT FROM DER, 81
FT LEFT OF CENTERLINE, UP TO 34 FT AGL/999 FT MSL.
BUILDINGS, TRAVERSE WAYS BEGINNING 821 FT FROM DER, 1 FT RIGHT OF
CENTERLINE, UP TO 48 FT AGL/1008 FT MSL.
TREES BEGINNING 1364 FT FROM DER, 530 FT RIGHT OF CENTERLINE, UP TO
1028 FT MSL.
FT AGL/1056 FT MSL. 2304181948-2504181948EST
END PART 2 OF 3
!FDC 3/3353 LVN PART 3 OF 3 ODP AIRLAKE, MINNEAPOLIS, MN.
TREE 2026 FT FROM DER, 977 FT LEFT OF CENTERLINE, 1040 FT MSL.
TRANSMISSION LINE 3187 FT FROM DER, 1284 FT RIGHT OF CENTERLINE, 73
FT AGL/1048 FT MSL.
TRANSMISSION LINE 3496 FT FROM DER, 1124 FT RIGHT OF CENTERLINE, 76
FT AGL/1052 FT MSL.
TRANSMISSION LINE 3818 FT FROM DER, 969 FT RIGHT OF CENTERLINE, 77
FT AGL/1056 FT MSL. 2304181948-2504181948EST
END PART 3 OF 3
|
