iFlightPlanner



...
No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KLNP
LONESOME PINE
PublicPUB

3 miles NE of WISE, VA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
36° 59' 15"N 82° 31' 47"W
2685' MSL
3685' MSL
06W
JET A (FSII), 100LL
LEESBURG (DCA)
CINCINNATI
INDIANAPOLIS (ZID)
10/31/24-11/28/24
KLNP VFR
6:55 AM EST
Clear
10sm
45°F
36°F
30.27"Hg
Calm
AO2
KLNP 091155Z AUTO 00000KT 10SM CLR 07/02 A3027 RMK AO2
Add Your Business

KLNP FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
123.0 123.0

AWOS-3

AWOS-3
276-328-3727
 118.6

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KTRI (31nm)
Sat, 11/9 6:29 AM EST
Sat, 11/9 7:00 AM EST - Sun, 11/10 7:00 AM EST
VFR
7:00 AM EST - 9:00 AM EST
Scattered 25,000'
6sm
020° 2kts
Shear 030° 30kts @ 2000'
VFR
9:00 AM EST - 7:00 PM EST
Broken 25,000'
6sm
120° 5kts
VFR
7:00 PM EST - 7:00 AM EST
Broken 10,000'
6sm
090° 4kts
KTRI 091129Z 0912/1012 02002KT P6SM SCT250 WS020/03030KT
   FM091400 12005KT P6SM BKN250
   FM100000 09004KT P6SM BKN100
KLNP
Domestic
11/5/241436Z !LNP 11/003 LNP RWY 06/24 NOW 5100FT X100FT. DECLARED DIST: RWY 06 TORA 5100FT TODA 5100FT ASDA 5100FT LDA 5100FT. RWY 24 TORA 5100FT TODA 5100FT ASDA 5100FT LDA 5100FT. 2411051436-2502282359
11/5/241435Z !LNP 11/002 LNP RWY 06 PAPI U/S 2411051435-2502282359
11/5/241434Z !LNP 11/001 LNP RWY 24 PAPI U/S 2411051434-2502282359
10/21/241422Z !LNP 10/006 LNP OBST TOWER LGT (ASR 1237127) 365022.90N0824417.30W (13.5NM SW LNP) 3778.9FT (439.0FT AGL) U/S 2410211422-2412312359
5/7/241924Z !LNP 05/001 LNP RWY 24 ALS U/S 2405071924-2411072111EST
FDC
9/12/241253Z !FDC 4/4354 LNP IAP LONESOME PINE, WISE, VA.
RNAV (GPS) RWY 6, ORIG-B...
STRAIGHT-IN MINIMUMS NA.
2409121253-2609121253EST
9/9/241327Z !FDC 4/2505 LNP IAP LONESOME PINE, WISE, VA.
LOC RWY 24, AMDT 1...
VGSI AND DESCENT ANGLES NOT COINCIDENT (VGSI ANGLE 3.00/TCH 32).
2409091327-2609091327EST
No
MON-SAT 0900-1800
THE CUMBERLAND ARPT COMSN
6225 AIRPORT ROAD
WISE, VA 24293
Phone: 276-328-5300
JOSEPH TEAGUE
6225 AIRPORT RD.
WISE, VA 24293
Phone: 276-328-5300
LEESBURG FSS (DCA)
Toll Free: 1-800-WX-BRIEF
LNP
--
ACTVT ODALS RWY 24; REIL RWY 06; MIRL 06/24 - CTAF.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
Pilot Instruction
Aircraft Rental
Annual Surveying

Runway 06/24

5131 ft. x 100 ft.
ASPH
Excellent
NONE
MED

42,000lbs
55,000lbs
100,000lbs
--
  Runway 06 Runway 24
True Heading 56°236°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 36° 59' 01"N 36° 59' 30"N
Longitude 82° 32' 13"W 82° 31' 21"W
Elevation 2,669' 2,685'
Threshold Crossing Height 32 ft. AGL 32 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights ODALS
Centerline Lights
Runway End Identifier Lights Yes No
A110-2WILDLIFE ON/INVOF AIRPORT.
A110-3UNATTENDED SUNDAY.
A110-4FOR CD CTC INDIANAPOLIS ARTCC AT 317-247-2411.
LONESOME PINE (ICAO: KLNP, IATA: LNP) is a public airport located in WISE, VA.
