No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KLLU
LAMAR MUNI
PublicPUB

2 miles SW of LAMAR, MO
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
37° 29' 10"N 94° 18' 43"W
1010' MSL
2010' MSL
02E
JET A, 100LL
COLUMBIA (COU)
KANSAS CITY
KANSAS CITY (ZKC)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

KLLU FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 122.9

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

No TAF is available for this location.
KLLU
Domestic
1/5/251518Z !COU 01/103 LLU OBST TOWER LGT (ASR 1325180) 372248.47N0940705.64W (11.2NM SE LLU) 1316FT (260FT AGL) U/S 2501051518-2502052300
12/18/241800Z !COU 12/265 LLU OBST TOWER LGT (ASR 1249134) 372956.10N0940906.70W (7.7NM E LLU) 1350.1FT (345.1FT AGL) U/S 2412181800-2503190500
8/15/241536Z !COU 08/287 LLU RWY 17 RWY END ID LGT U/S 2408151536-2502142111EST
FDC
6/6/231329Z !FDC 3/6174 LLU ODP LAMAR MUNI, LAMAR, MO.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES: RWY 03, LIGHT POLES, BEGINNING 1130 FROM DER, BEGINNING 386 FT RIGHT OF CENTERLINE, 60 AGL/UP TO 1043 MSL (2021-ACE- 1808/1810-OE PERMANENT). ALL OTHER DATA REMAINS AS PUBLISHED. 2306061329-2506061329EST
No
UNATNDD
CITY OF LAMAR
132 WEST 10TH
LAMAR, MO 64759
Phone: 417 682-5554
RUSS WORSLEY
132 WEST 10TH
LAMAR, MO 64759
Phone: 417-682-5554
COLUMBIA FSS (COU)
Toll Free: 1-800-WX-BRIEF
COU
--
ACTVT MIRL RYS 03/21 & 17/35, PAPI RYS 17 & 35 - CTAF.
N/A
Yes - Lighted
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
Crop Dusting
Pilot Instruction
Aircraft Rental

Runway 03/21

2900 ft. x 60 ft.
ASPH CONC
Good
AFSC
MED
10 /R/C/W/T
--
--
--
--
  Runway 03 Runway 21
True Heading 33°213°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 37° 29' 10"N 37° 29' 34"N
Longitude 94° 18' 51"W 94° 18' 32"W
Elevation 1,005' 998'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 17/35

4000 ft. x 75 ft.
CONC
Excellent
NONE
MED

--
--
--
--
  Runway 17 Runway 35
True Heading 169°349°
Traffic Pattern
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 37° 29' 20"N 37° 28' 41"N
Longitude 94° 18' 49"W 94° 18' 40"W
Elevation 1,010' 990'
Threshold Crossing Height 42 ft. AGL 42 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes
A110-1FOR CD CTC KANSAS CITY ARTCC AT 913-254-8508.
LAMAR MUNI (ICAO: KLLU, IATA: LLU) is a public airport located in LAMAR, MO.
