iFlightPlanner



...
No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KLIC
LIMON MUNI
PublicPUB

1 miles NE of LIMON, CO
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
39° 16' 29"N 103° 39' 57"W
5374' MSL
6374' MSL
07E
100LL
DENVER (DEN)
WICHITA
DENVER (ZDV)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

KLIC FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 122.9

ASOS

ASOS
719-775-0515
 121.125

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

No TAF is available for this location.
KLIC
Domestic
12/11/240612Z !LIC 12/001 LIC OBST TOWER LGT (ASR 1025191) 385615.00N1031352.00W (28.6NM SE LIC) 5171FT (313FT AGL) U/S 2412110612-2501250521
FDC
1/8/251625Z !FDC 5/1513 LIC IAP LIMON MUNI, LIMON, CO.
RNAV (GPS) RWY 34, ORIG...
LPV DA NA. LNAV/VNAV DA, BARO-VNAV AND VDP NA WHEN USING COLORADO AIR AND SPACE PORT ALTIMETER SETTING..
2501081625-2701081625EST
6/26/241949Z !FDC 4/4145 LIC IAP LIMON MUNI, LIMON, CO.
RNAV (GPS) RWY 16, ORIG...
LPV VIS ALL CATS 1.
2406261949-2606261949EST
No
UNATNDD
TOWN OF LIMON
TOWN HALL, BOX 9
LIMON, CO 80828
Phone: 719-775-2346
GREG TACHA
TOWN OF LIMON, BOX 9
LIMON, CO 80828
Phone: 719-775-2346
DENVER FSS (DEN)
Toll Free: 1-800-WX-BRIEF
LIC
--
ACTVT PAPI RWY 16 & 34; MIRL RWY 16/34 - CTAF.
N/A
Yes
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Minor
Minor
None
None
Pilot Instruction

Runway 16/34

4700 ft. x 60 ft.
CONC
Fair
NONE
MED

12,000lbs
--
--
--
  Runway 16 Runway 34
True Heading 169°349°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 39° 16' 52"N 39° 16' 06"N
Longitude 103° 40' 03"W 103° 39' 52"W
Elevation 5,374' 5,349'
Threshold Crossing Height 39 ft. AGL 39 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1CTN: UNCTLD VEHICLE ACES.
A110-2TWY MKD WITH BLUE REFLECTORS.
A110-3DEER ON & INVOF ARPT.
A110-4CTN: MIL STUDENT TRNG INVOF COLORADO SPRINGS & PUEBLO COLORADO.
A110-6FOR CD IF UNA TO CTC ON FSS FREQ, CTC DENVER ARTCC AT 303-651-4257.
A110-7PAJA ON & INVOF ARPT; MIDFIELD OVR FLT NA.
LIMON MUNI (ICAO: KLIC, IATA: LIC) is a public airport located in LIMON, CO.
