KLHW
WRIGHT AAF (FORT STEWART)/MIDCOAST RGNL
PublicPUB

View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
31° 53' 16"N 81° 33' 46"W
47' MSL
1047' MSL
04W
JET A (FSII), 100LL
MACON (MCN)
JACKSONVILLE
JACKSONVILLE (ZJX)
10/31/24-11/28/24
KLHW VFR
6:55 AM EST
Clear
8sm
67°F
66°F
30.05"Hg
010° 3kts
AO2 SLP179 T01960191 10213 20195 52010 $
KLHW 091155Z AUTO 01003KT 8SM CLR 20/19 A3005 RMK AO2 SLP179 T01960191 10213 20195 52010 $
Add Your Business

KLHW FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 126.25

ATIS

ATIS
Hours: 1230-0400Z++, EXC HOL.
 118.475

Ground

GND/P
 121.7

Tower

LCL/P
 126.25

Other

BASE OPS
 140.55
FLT FLW
FM
 41.3
FLT FLW
 127.35
GCA
 134.65
OPS
FM ;MARNE RDO
 41.3
OPS
MARNE RDO
 127.35
PTD
 140.55

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KSVN (23nm)
Fri, 11/8 8:00 PM EST
Fri, 11/8 8:00 PM EST - Sun, 11/10 2:00 AM EST
VFR
8:00 PM EST - 11:00 PM EST
Broken 7,000'
Scattered 4,000'
6sm
30.03"Hg
Calm
IFR
Becoming 11:00 PM EST - 3:00 AM EST
Mist
Broken 700'
1.24sm
30.03"Hg
Calm
LIFR
Becoming 3:00 AM EST - 10:00 AM EST
Mist
Broken 200'
1.24sm
30.06"Hg
Calm
LIFR
Temporary 6:00 AM EST - 9:00 AM EST
Fog
No Clouds
0.25sm
050° 3kts
MVFR
Becoming 10:00 AM EST - 3:00 PM EST
Broken 2,000'
Scattered 900'
6sm
30.12"Hg
060° 10kts
Gusts 15kts
VFR
Becoming 3:00 PM EST - 11:00 PM EST
Showers in vicinity
Broken 4,500'
Scattered 2,000'
6sm
30.12"Hg
060° 10kts
Gusts 20kts
MVFR
Becoming 11:00 PM EST - 2:00 AM EST
Broken 2,000'
6sm
30.15"Hg
060° 9kts
TAF KSVN 090100Z 0901/1007 00000KT 9999 SCT040 BKN070 QNH3003INS
   BECMG 0904/0905 00000KT 2000 BR BKN007 QNH3004INS
   BECMG 0908/0909 00000KT 2000 BR BKN002 QNH3006INS
   TEMPO 0911/0914 05003KT 0400 FG
   BECMG 0915/0916 06010G15KT 9999 NSW SCT009 BKN020 QNH3011INS
   BECMG 0920/0921 06010G20KT 9999 VCSH SCT020 BKN045 QNH3013INS
   BECMG 1004/1005 06009KT 9999 NSW BKN020 QNH3014INS TX26/0920Z TN19/0912Z LAST NO AMDS AFT 0903 NEXT 1209
KLHW
Domestic
11/1/241905Z !LHW 11/001 LHW OBST TOWER LGT (ASR 1217313) 314607.60N0812703.50W (9.0NM SE LHW) 279.2FT (260.2FT AGL) U/S 2411011905-2503011905
10/31/241503Z !LHW 10/031 LHW OBST TOWER LGT (ASR 1231268) 315127.00N0814231.80W (7.7NM WSW LHW) 385.2FT (307.1FT AGL) U/S 2410311503-2411150400
10/28/242135Z !LHW 10/030 LHW OBST TOWER LGT (ASR 1046364) 314548.00N0812227.00W (12.0NM SE LHW) 332.0FT (315.0FT AGL) U/S 2410282135-2411140400
10/26/240003Z !LHW 10/029 LHW OBST TOWER LGT (ASR 1231717) 315254.40N0815056.20W (14.6NM W LHW) 434.7FT (308.7FT AGL) U/S 2410260003-2411110400
10/25/241338Z !LHW 10/028 LHW APRON PRKG PADS 7-14 CLSD 2410251338-2412202359
10/22/242321Z !LHW 10/027 LHW OBST TOWER LGT (ASR 1246717) 314352.30N0812523.20W (11.6NM SE LHW) 324.1FT (305.1FT AGL) U/S 2410222321-2411211700
10/17/241719Z !LHW 10/021 LHW OBST TOWER LGT (ASR 1004117) 315102.00N0813603.00W (3.0NM SW LHW) 272.0FT (203.1FT AGL) U/S 2410171719-2504172359
10/16/240232Z !LHW 10/018 LHW OBST TOWER LGT (ASR 1311106) 314835.66N0812538.23W (8.2NM SE LHW) 278FT (265FT AGL) U/S 2410160232-2411300231
10/15/242253Z !LHW 10/013 LHW RWY 06L/24R CLSD EXC MIL ACFT DLY SS-SR 2410152253-2411151155
10/15/241607Z !LHW 10/015 LHW RWY 15L/33R WIP MEN AND EQUIP ADJ WEST SIDE 2410151607-2411152359
10/15/241232Z !LHW 10/012 LHW RWY 24R END ID LGT U/S 2410151232-2411152359
10/15/241232Z !LHW 10/011 LHW RWY 06L RWY END ID LGT U/S 2410151232-2411152359
10/13/241448Z !LHW 10/007 LHW OBST TOWER LGT (ASR 1023092) 315652.30N0812021.60W (12.1NM ENE LHW) 282.2FT (269.0FT AGL) U/S 2410131448-2501120400
9/27/241901Z !LHW 09/051 LHW OBST TOWER LGT (ASR 1223320) 315259.50N0813644.50W (2.6NM W LHW) 298.6FT (222.8FT AGL) U/S 2409271901-2501251901
9/27/240716Z !LHW 09/044 LHW OBST TOWER LGT (ASR 1295677) 315300.10N0813758.80W (3.6NM W LHW) 252.0FT (184.7FT AGL) U/S 2409270716-2411110716
9/27/240521Z !LHW 09/034 LHW OBST TOWER LGT (ASR 1229531) 314240.40N0812316.00W (13.7NM SE LHW) 274.6FT (259.8FT AGL) U/S 2409270521-2501250521
9/21/242010Z !LHW 09/017 LHW OBST TOWER LGT (ASR 1025227) 315215.00N0812618.00W (6.4NM E LHW) 439.0FT (419.0FT AGL) U/S 2409212010-2412200400
9/21/241737Z !LHW 09/016 LHW OBST TOWER LGT (ASR 1254823) 315152.60N0813631.60W (2.8NM WSW LHW) 226.0FT (140.1FT AGL) U/S 2409211737-2412210400
9/15/241430Z !LHW 09/012 LHW OBST TOWER LGT (ASR 1221291) 315022.30N0812441.10W (8.2NM ESE LHW) 252.0FT (231.0FT AGL) U/S 2409151430-2501131430
8/14/240617Z !LHW 08/020 LHW OBST TOWER LGT (ASR 1013673) 315053.50N0811531.40W (15.6NM E LHW) 335.0FT (319.9FT AGL) U/S 2408140617-2412120617
8/9/241529Z !LHW 08/009 LHW OBST TOWER LGT (ASR 1289917) 315147.60N0813819.40W (4.2NM WSW LHW) 270.0FT (202.1FT AGL) U/S 2408091529-2411070400
1/5/242236Z !LHW 01/006 LHW RWY 15L/33R CLSD EXC MIL ACFT DLY SS-SR 2401052236-2501061227
1/5/241343Z !LHW 01/009 LHW NAV LHW NDB U/S 2401051343-2501062359
1/5/241339Z !LHW 01/008 LHW RWY 33R RENL U/S 2401051339-2501061230
1/5/241339Z !LHW 01/007 LHW RWY 15L RENL U/S 2401051339-2501061230
11/3/221725Z !LHW 11/003 LHW RWY 15L SIGNS LGT U/S 2211031725-PERM
2/4/221557Z !LHW 02/011 LHW TWY C SIGNS LGT U/S 2202041557-PERM
2/4/221554Z !LHW 02/010 LHW TWY B SIGNS LGT U/S 2202041554-PERM
2/4/221553Z !LHW 02/009 LHW TWY A SIGNS LGT U/S 2202041553-PERM
2/4/221552Z !LHW 02/008 LHW RWY 24R SIGNS LGT U/S 2202041552-PERM
2/4/221547Z !LHW 02/006 LHW RWY 33R SIGNS LGT U/S 2202041547-PERM
Military
11/5/241304Z M0160/24 NOTAMC M0154/24
11/5/241304Z M0159/24 NOTAMC M0153/24
11/5/241304Z M0158/24 NOTAMC M0156/24
11/5/241303Z M0157/24 NOTAMC M0155/24
10/22/240600Z AERODROME MAKE APPROACHES AND DEPARTURES TO THE 3ID COMMAND PAD VIA HEADINGS 068 AND 248 DEGREES RESPECTIVELY. USE CAUTION AND AVOID OVERFLIGHT OF PERSONNEL, TENTS, AND EQUIPMENT ON THE EAST AND WEST SIDES OF TRENT FIELD.
10/16/241920Z !KLHW M0147/24 LHW SVC BASE OPS NEW PHONE NUMBERS 571-801-1579/1580 2410161920-2411302359
9/25/241747Z AERODROME PCL AT THE COMMAND PAD U/S
Yes
MON-FRI 0600-2300
TWR WILL OPEN FOR JOSAC MISSIONS, DSN 435-3103. WHEN BASE OPS CLSD, CTC HUNTER BASE OPS DSN 729-5110, SEE FLIP AP/1 FLT HAZ AND SUPPLEMENTARY ARPT RMK.
US ARMY AERONAUTICAL SVCS AGENCY

FT BELVOIR, VA 22060
JESSE WILLETT
1116 E. LOWE CIRCLE
HINESVILLE, GA 31315
Phone: (912) 435-3130
MACON FSS (MCN)
Toll Free: 1-800-WX-BRIEF
LHW
--
WHEN ATCT & MARNE RDO BOTH CLSD, ACTVT PAPI RWY 06L & 33R; HIRL RWY 06L/24R & 15L/33R; TWY A, B, C, & F - CTAF.
N/A
Yes - Lighted
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
None

Runway 06L/24R

6500 ft. x 100 ft.
ASPH
Good
NONE
HIGH
46 /F/A/W/T
--
--
--
--
  Runway 06L Runway 24R
True Heading 51°231°
Traffic Pattern Right
Markings NPI NPI
Markings Condition FAIR FAIR
Latitude 31° 52' 54"N 31° 53' 35"N
Longitude 81° 34' 30"W 81° 33' 32"W
Elevation 46' 34'
Threshold Crossing Height 48 ft. AGL --
Visual Glide Path Angle 3° --
Visual Slope Indicator P4L --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 06R/24L

2610 ft. x 100 ft.
ASPH
Poor
NONE


--
--
--
--
  Runway 06R Runway 24L
True Heading 51°231°
Traffic Pattern
Markings BSC BSC
Markings Condition POOR POOR
Latitude 31° 53' 07"N 31° 53' 24"N
Longitude 81° 34' 04"W 81° 33' 40"W
Elevation 41' 39'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 15L/33R

5001 ft. x 100 ft.
ASPH
Excellent
NONE
HIGH
15 /F/A/W/T
--
--
--
--
  Runway 15L Runway 33R
True Heading 141°321°
Traffic Pattern Left
Markings NPI NPI
Markings Condition FAIR FAIR
Latitude 31° 53' 40"N 31° 53' 01"N
Longitude 81° 33' 49"W 81° 33' 12"W
Elevation 37' 33'
Threshold Crossing Height -- 65 ft. AGL
Visual Glide Path Angle -- 3°
Visual Slope Indicator -- P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 15R/33L

2520 ft. x 100 ft.
ASPH
L
NONE


--
--
--
--
  Runway 15R Runway 33L
True Heading 141°321°
Traffic Pattern
Markings BSC BSC
Markings Condition POOR POOR
Latitude 31° 53' 23"N 31° 53' 03"N
Longitude 81° 33' 39"W 81° 33' 20"W
Elevation 38' 32'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway H1

50 ft. x 50 ft.
TURF
Fair
NONE


--
--
--
--
  Runway H1 Runway
True Heading 94°274°
Traffic Pattern
Markings BSC
Markings Condition GOOD
Latitude 31° 53' 10"N N/A
Longitude 81° 33' 34"W N/A
Elevation 41' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-13FUEL: J8 AVBL FBO, C912-877-4359 (NC 100LL) 1300-0600Z++ MON-FRI, EXC HOL, OT 24 HR PPR. TRAN FUEL PPR, CTC BASE OPS 571-801-1579/1580.
A110-16CAUTION: EXTV R/W TRNG MIN LGT SS-SR. CTC TWR PRIOR TO ENTERING CLASS D AIRSPACE. R3005 1.4 NM NW OF AFLD. DEER AND PIG HAZ.
A110-18MISC: MOORING/TIE-DOWN STRAPS NOT AVBL.
A110-19RSTD: AVIATORS BRIEFED IN THE LAST 6 MOS MAY RECEIVE A TELEPHONIC UPDATE BRIEFING. CTC HUNTER AAF OPS C571-801-8263/64. 1200-0100Z++ MON-FRI.
A110-20CIVILIAN FBO PH#'S 912-877-4364 & 912877-4359.
A110-23UNMANNED ACFT ACT IN CLASS D.
A110-24RSTD: TWY E NON MOVEMENT AREAS CLSD TO FIXED WING, ROTARY WING USE WITH PRIOR APPROVAL.
A110-25MISC: FULL WX SVC EFF 1100-0400Z++MON-FRI, CLSD WEEKEND AND FEDERAL HOL, OT REMOTE BRIEFING FR 26 OWS BARKSDALE AFB, LA, DSN 331-2651/2/3, C318-529-2651/2/3. DUR PERIODS OF AUGMENT ATC WILL ASSIST IN COOPERATIVE WX WATCH BY NOTIFYING WX OF UNREPORTED COND. AUGMENTATION MODE, PREVAIL SFC VIS MAY NOT BE REPRESENTED OF ENTIRE AFLD DUE TO BLDG OBST AND LACK OF VIS. MARK BYD 1 1/2 SM. KLHW FCST 571-801-1585/86.
A110-26MISC: OPR HRS MAY VARY WITH LCL FLYING SHED.
A110-27COMM: CTAF MARNE RDO - OPR 1230Z++ MON-0400Z++ SAT, SUN 1230Z++ - 0400Z++ EXC HOL. MIDCOAST REGIONAL-FBO OPR 1200-0000Z++. 123.075.
A110-28MISC: MAIN RAMP PARKING PADS 15-18 PERM CLSD / SOUTHERN TAXI LANE PERM CLSD.
A110-29CAUTION: TWYS A, B, C SIGNS REMOVED OR U/S. TWY E PERM CLSD.
A110-3R/W ACFT PILOTS PLANNING TO CONDUCT OPR WITHIN R3005 MUST RCV A RNG BRIEFING PRIOR TO ANY OPR. BRIEFING SHALL BE ACCOMPLISHED AT LEAST 4 HRS PRIOR TO FLT ON THE RESERVATION.
A110-30CAUITON: RWY 33R/15L SIGNS REMOVED OR U/S. RWY 24R SIGNS REMOVED OR UNSERVICEABLE.
A110-31CAUTION: ALL DISTANCE REMAINING SIGNS MISSING FROM ALL RWYS.
A110-32MISC: NO OVERRUNS FOR RWY 24R, 15L/33R.
A110-5RSTD: ALL MIL PPR AND MIL TRAN ACFT, CTC BASE OPS 571-801-1579/1580.
A110-8NS ABTMT: NO OVFT OF CANTONMENT AREA OR CITY OF HINESVILLE BELOW 1000 FT AGL.
WRIGHT AAF (FORT STEWART)/MIDCOAST RGNL (ICAO: KLHW, IATA: LHW) is a public airport located in FORT STEWART (HINESVILLE), GA.
