4/1/251654Z
|
!FDC 5/0458 LHV PART 1 OF 3 ODP WILLIAM T PIPER MEML,
LOCK HAVEN, PA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES:
RWY 27R: UTILITY BUILDING 9 FT FROM DER, 124 FT RIGHT OF
CENTERLINE, 5 FT AGL/559 FT MSL.
UTILITY BUILDING 9 FT FROM DER, 125 FT LEFT OF CENTERLINE, 4 FT
AGL/558 FT MSL.
BUILDING 50 FT FROM DER, 415 FT RIGHT OF CENTERLINE, 20 FT AGL/577
FT MSL.
FENCE, TREE BEGINNING 50 FT FROM DER, 231 FT LEFT OF CENTERLINE, UP
TO 9 FT AGL/564 FT MSL.
POLE 132 FT FROM DER, 349 FT RIGHT OF CENTERLINE, 28 FT AGL/585 FT
MSL.
TREE 151 FT FROM DER, 303 FT LEFT OF CENTERLINE, 572 FT MSL.
BUILDING 181 FT FROM DER, 537 FT RIGHT OF CENTERLINE, 29 FT AGL/587
FT MSL.
TREE 259 FT FROM DER, 340 FT RIGHT OF CENTERLINE, 612 FT MSL.
TREES, TRAVERSE WAY BEGINNING 269 FT FROM DER, 6 FT RIGHT OF
CENTERLINE, UP TO 630 FT MSL.
BUILDINGS, POLES, TRAVERSE WAY BEGINNING 493 FT FROM DER, 16 FT
LEFT OF CENTERLINE, UP TO 57 FT AGL/611 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2504011654-2704011654EST
END PART 1 OF 3
!FDC 5/0458 LHV PART 2 OF 3 ODP WILLIAM T PIPER MEML,
LOCK HAVEN, PA.
TREES, BUILDINGS, POLES BEGINNING 650 FT FROM DER, 77 FT RIGHT OF
CENTERLINE, UP TO 640 FT MSL.
TREES, BUILDINGS, POLES BEGINNING 831 FT FROM DER, 134 FT LEFT OF
CENTERLINE, UP TO 620 FT MSL.
TREES, POLES, BUILDINGS BEGINNING 906 FT FROM DER, 9 FT RIGHT OF
CENTERLINE, UP TO 642 FT MSL.
TREES, BUILDINGS, POLES BEGINNING 1154 FT FROM DER, 23 FT LEFT OF
CENTERLINE, UP TO 623 FT MSL.
TREES, TOWER BEGINNING 1672 FT FROM DER, 21 FT LEFT OF CENTERLINE,
UP TO 631 FT MSL.
TREES BEGINNING 2409 FT FROM DER, 10 FT RIGHT OF CENTERLINE, UP TO
643 FT MSL.
BUILDING 3477 FT FROM DER, 1403 FT RIGHT OF CENTERLINE, 667 FT MSL.
TREES, TRAVERSE WAY > BEGINNING 1.3 NM FROM DER, 1544 FT RIGHT OF
CENTERLINE, UP TO 847 FT MSL.
TREES, TRAVERSE WAY BEGINNING 1.4 NM FROM DER, 1284 FT RIGHT OF
CENTERLINE, UP TO 927 FT MSL.
TREES, TERRAIN, TRAVERSE WAY> BEGINNING 1.5 NM FROM DER, 1031 FT
RIGHT OF CENTERLINE, UP TO 951 FT MSL.
TREES, TOWERS BEGINNING 1.7 NM FROM DER, 128 FT RIGHT OF
ALL OTHER DATA REMAINS AS PUBLISHED. 2504011654-2704011654EST
END PART 2 OF 3
!FDC 5/0458 LHV PART 3 OF 3 ODP WILLIAM T PIPER MEML,
LOCK HAVEN, PA.
CENTERLINE, UP TO 1021 FT MSL.
TREES BEGINNING 2.4 NM FROM DER, 2162 FT RIGHT OF CENTERLINE, UP TO
1063 FT MSL.
TREE 2.5 NM FROM DER, 1879 FT RIGHT OF CENTERLINE, 1066 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2504011654-2704011654EST
END PART 3 OF 3
|
