KLAS
HARRY REID INTL
PublicPUB

5 miles S of LAS VEGAS, NV
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
36° 04' 48"N 115° 09' 08"W
2181' MSL
3181' MSL
11E
JET A-1+, 100LL, 100
RENO (RNO)
LAS VEGAS
LOS ANGELES (ZLA)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

KLAS FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 --

ATIS

D-ATIS
702-736-0950
 132.4

Clearance Delivery

CD/P
 118.0

Emergency

EMERG
 121.5

Ground

GND/P
E OF RWY 01R/19L
 121.1
GND/P
W OF RWY 01L/19R
 121.9

Tower

LCL/P
RWY 01L/19R, 01R/19L
 118.75
LCL/P
RWY 08L/26R, 08R/26L
 119.9

Other

RAMP CTL
A, B, C GATES & GA, CUSTOMS.
 124.4
RAMP CTL
D, E GATES & CARGO.
 127.9
RAMP CTL
RAMP ALTERNATE FREQUENCY
 130.0

Terminal Area Forecast

No TAF is available for this location.
KLAS
Domestic
1/16/250900Z !LAS 01/080 LAS RWY 01R RWY END ID LGT U/S 2501160900-2501161400
1/16/250900Z !LAS 01/079 LAS RWY 19L RWY END ID LGT U/S 2501160900-2501161400
1/16/250900Z !LAS 01/078 LAS RWY 19L PAPI U/S 2501160900-2501161400
1/16/250900Z !LAS 01/077 LAS RWY 01R PAPI U/S 2501160900-2501161400
1/15/251600Z !LAS 01/076 LAS OBST CRANE (ASN UNKNOWN) 360516N1150438W (2.25NM ENE APCH END RWY 26R) 2021FT (195FT AGL) FLAGGED NOT LGTD 2501151600-2501160100
1/15/251300Z !LAS 01/052 LAS OBST RIG (ASN UNKNOWN) 360404N1150747W (0.62NM NW APCH END RWY 26R)
UNKNOWN (80FT AGL) FLAGGED AND LGTD 2501151300-2501152300
1/15/251300Z !LAS 01/051 LAS OBST RIG (ASN UNKNOWN) 360504N1150744W (0.62NM NW APCH END RWY 26R)
UNKNOWN (80FT AGL) FLAGGED AND LGTD 2501151300-2501152300
1/15/251300Z !LAS 01/050 LAS OBST RIG (ASN UNKNOWN) 360501N1150744W (0.62NM NW APCH END RWY 26R)
UNKNOWN (80FT AGL) FLAGGED AND LGTD 2501151300-2501152300
1/15/251300Z !LAS 01/049 LAS OBST RIG (ASN UNKNOWN) 360501N1150747W (0.62NM NW APCH END RWY 26R)
UNKNOWN (80FT AGL) FLAGGED AND LGTD 2501151300-2501152300
1/15/251200Z !LAS 01/082 LAS RWY 08L/26R CLSD 2501151200-2501152000
1/15/250900Z !LAS 01/081 LAS RWY 01R/19L CLSD 2501150900-2501151200
1/14/251400Z !LAS 01/031 LAS OBST CRANE (ASN 2024-AWP-6926-NRA) 360516N1150846W (0.6NM NNE LAS) 2160FT (90FT AGL) FLAGGED AND LGTD 2501141400-2501162300
1/14/251400Z !LAS 01/030 LAS OBST CRANE (ASN 2024-AWP-6924-NRA) 360525N1150847W (0.7NM NNE LAS) 2159FT (90FT AGL) FLAGGED AND LGTD 2501141400-2501162300
1/14/251400Z !LAS 01/016 LAS OBST CRANE (ASN UNKNOWN) 360538N1150803W (2.1NM NE LAS) UNKNOWN (60FT AGL) FLAGGED AND LGTD DLY 1400-2300 2501141400-2501162300
1/13/251825Z !LAS 01/068 LAS RWY 01R PAPI U/S 2501131825-2501152000
1/13/251659Z !LAS 01/067 LAS APRON TXL Q BTN TWY C1 AND TWY C2 CLSD 2501131659-2504292300
1/13/251554Z !LAS 01/065 LAS TWY C1 BTN TWY C AND TXL Q CLSD 2501131554-2504292300
1/13/251200Z !LAS 01/055 LAS APRON TXL Q1 BTN TXL Q AND HLDG PAD NUMBER 6 CLSD 2501131200-2504292300
1/4/250846Z !LAS 01/009 LAS OBST TOWER LGT (ASN 2016-AWP-6698-OE) 360434N1151157W (2.3NM W LAS) 2369FT (80FT AGL) U/S 2501040846-2502180845
12/13/241400Z !LAS 12/074 LAS OBST CRANE (ASN UNKNOWN) 360715N1151023W (2NM NNW LAS) 2450FT (342FT AGL) FLAGGED AND LGTD DLY 1400-0030 2412131400-2505010030
12/3/241515Z !LAS 12/015 LAS AD AP CLSD TO NON SKED TRANSIENT GA ACFT EXC 24HR PPR 702-261-7775 2412031515-2503192300
12/2/242008Z !LAS 12/007 LAS OBST CRANE (ASN UNKNOWN) 360503N1151018W (1.0NM WNW LAS)
2380FT (232FT AGL) FLAGGED AND LGTD 2412022008-2508202300
11/12/241950Z !LAS 11/034 LAS OBST CRANE (ASN UNKNOWN) 360616N1150903W (1.5NM NNE APCH END RWY 19L)
UNKNOWN (79FT AGL) FLAGGED AND LGTD 2411121950-2502132100
2/1/241758Z !LAS 02/009 LAS TWY H2 NOW COMISSIONED 2402011758-PERM
12/13/231400Z !LAS 12/072 LAS OBST SILO (ASN 2023-AWP-3561-NRA) 360508N1150742W (1.2NM ENE LAS) 2108FT (80FT AGL) FLAGGED AND LGTD 2312131400-2506112300
FDC
12/17/241327Z !FDC 4/7774 LAS IAP HARRY REID INTL, LAS VEGAS, NV.
RNAV (GPS) Y RWY 19R, AMDT 3A...
LPV ALL CATS VISIBILITY 1.
DELETE PROFILE NOTE: *LNAV ONLY. DELETE ASTERISK FROM VDP 1.77 NM
TO RW19R.
THIS IS RNAV (GPS) Y RWY 19R, AMDT 3B. 2412171327-PERM
12/17/241327Z !FDC 4/7773 LAS IAP HARRY REID INTL, LAS VEGAS, NV.
RNAV (GPS) Y RWY 19L, AMDT 3...
LPV ALL CATS VISIBILITY 1.
PBN REQUIREMENTS NOTE: RNP APCH - GPS.
DELETE PROFILE NOTE: *LNAV ONLY. DELETE ASTERISK FROM VDP 1.33 NM
TO JABNA.
THIS IS RNAV (GPS) Y RWY 19L, AMDT 3A. 2412171327-PERM
12/4/242027Z !FDC 4/1774 LAS IAP HARRY REID INTL, LAS VEGAS, NV.
VOR/DME-A, ORIG-E...
PROCEDURE NA.
2412042027-2507162026EST
10/31/241309Z !FDC 4/6962 LAS SID HARRY REID INTL, LAS VEGAS, NV.
MCCARRAN SEVEN DEPARTURE...
LIDAT TRANSITION NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
OAL VORTAC OUT OF SERVICE. 2410311309-2506121309EST
9/11/241402Z !FDC 4/3822 LAS IAP HARRY REID INTL, LAS VEGAS, NV.
VOR/DME-A, ORIG-E...
ALTERNATE MINIMUMS: CAT A, B 900-2, CAT C 1100-3, CAT D 1400-3.
2409111402-2609111402EST
4/26/241740Z !FDC 4/5741 LAS IAP HARRY REID INTL, LAS VEGAS, NV.
ILS OR LOC RWY 1L, AMDT 4...
LOC MAP I-CUA 1.7 DME. S-ILS 1L VIS ALL CATS 1. S-LOC 1L VIS ALL CATS 1 1/2. VDP NA. ADD PROFILE NOTE: I-CUA LOC UNUSABLE 0.20 NM FROM THRESHOLD.
2404261740-2604271740EST
3/25/241832Z !FDC 4/1396 LAS ODP HARRY REID INTL, LAS VEGAS, NV.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT ...
TAKE-OFF MINIMUMS RWY 19L STANDARD WITH MINIMUM CLIMB OF 276 FT/NM TO 4900.
ALL OTHER DATA REMAINS AS PUBLISHED. 2403251832-2603251832EST
7/24/231820Z !FDC 3/1551 LAS SID HARRY REID INTL, LAS VEGAS, NV.
HOOVER EIGHT DEPARTURE...
DISREGARD NOTE: TURBOJETS ONLY. ALL OTHER DATA REMAINS AS PUBLISHED. 2307241820-2506241820EST
Yes
ALL
CLARK COUNTY
P O BOX 11005
LAS VEGAS, NV 89111
Phone: 702-261-5211
ROSEMARY A. VASSILIADIS
5757 WAYNE NEWTON BLVD
LAS VEGAS, NV 89119
Phone: 702-261-5211
RENO FSS (RNO)
Toll Free: 1-800-WX-BRIEF
LAS
Sunset to Sunrise
--
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
High Pressure
High & Low Pressure
Air Freight
Air Ambulance
Avionics
Cargo Handling
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales
Annual Surveying

Runway 01L/19R

8988 ft. x 150 ft.
CONC
Good
GRVD
HIGH

120,000lbs
250,000lbs
550,000lbs
1,120,000lbs
  Runway 01L Runway 19R
True Heading 25°205°
Traffic Pattern Left Right
Markings PIR NPI
Markings Condition GOOD GOOD
Latitude 36° 04' 31"N 36° 05' 52"N
Longitude 115° 10' 13"W 115° 09' 27"W
Elevation 2,181' 2,088'
Threshold Crossing Height 63 ft. AGL 80 ft. AGL
Visual Glide Path Angle 3.4° 3.04°
Visual Slope Indicator P4L P4L
Approach Lights MALSF
Centerline Lights No No
Runway End Identifier Lights No Yes

Runway 01R/19L

9771 ft. x 150 ft.
CONC
Good
GRVD
MED

120,000lbs
250,000lbs
550,000lbs
1,120,000lbs
  Runway 01R Runway 19L
True Heading 25°205°
Traffic Pattern Right Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 36° 04' 27"N 36° 05' 55"N
Longitude 115° 10' 03"W 115° 09' 13"W
Elevation 2,175' 2,078'
Threshold Crossing Height 76 ft. AGL 75 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes

Runway 08L/26R

14515 ft. x 150 ft.
CONC
Good
GRVD
HIGH

120,000lbs
250,000lbs
550,000lbs
1,120,000lbs
  Runway 08L Runway 26R
True Heading 90°270°
Traffic Pattern Left Left
Markings NPI PIR
Markings Condition GOOD GOOD
Latitude 36° 04' 35"N 36° 04' 35"N
Longitude 115° 10' 13"W 115° 07' 16"W
Elevation 2,179' 2,033'
Threshold Crossing Height 76 ft. AGL 84 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALS
Centerline Lights No No
Runway End Identifier Lights No No

Runway 08R/26L

10526 ft. x 150 ft.
CONC
Excellent
GRVD
HIGH

120,000lbs
250,000lbs
550,000lbs
1,120,000lbs
  Runway 08R Runway 26L
True Heading 90°270°
Traffic Pattern
Markings NPI PIR
Markings Condition GOOD GOOD
Latitude 36° 04' 25"N 36° 04' 25"N
Longitude 115° 09' 41"W 115° 07' 33"W
Elevation 2,157' 2,048'
Threshold Crossing Height 61 ft. AGL 84 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSF
Centerline Lights
Runway End Identifier Lights Yes
A110-1EXTSV GLDR/SOARING OPNS WKENDS & HOLS; SR-SS; LAS R187/020; ALTS UP TO BUT NOT INCLG FL180. GLDRS RMN CLEAR OF THE TCA BUT OTHERWISE OPR WI THE ENTIRE SW QUAD OF THE TCA VEIL.
A110-10LGTD GOLF RANGE 1400 FT S OF RWYS 01L/19R AND 01R/19L.
A110-11TIEDOWN FEE.
A110-13(E98) PLUS 64 SHELTERS & 24 SHEDS.
A110-2ALL NON-STD RWY OPNS PPR FM DEPT OF AVN.
A110-20ACFT USING FULL LEN DEP ON RWY 08L USE MINIMAL PWR TIL PASSING THE PWR-UP POINT ON RWY. PWR-UP POINT IS 348 FT EAST OF BLAST PAD AND MKD WITH SIGN AND STD MARKINGS FOR BGNG OF RWY.
A110-25LRG NR OF BIRDS AND BATS INVOF OF ARPT BTWN SS AND SR.
A110-28ACFT DEPG RWY 19R USE MINIMAL PWR UNTIL PASSING THE RWY THLD. RWY 19R THLD HAS STD RWY MARKINGS AND IS 780 FT S OF THE BLAST PAD.
A110-3TBJT DEPS NOT PMTD ON RWY 01R/19L OR RWY 01L/19R 2000-0800. XCPNS FOR WX OR OPNL NECESSITY.
A110-30ACFT OPER NEAR THE INT OF TWYS S, D, G AND THE N END OF TWY Z SHOULD BE ALERT AS THERE ARE CLOSELY ALIGNED TWY CNTRLN AND RADIUS TURNS.
A110-31ACFT THAT DEP FULL LENGTH OF RWYS 01L AND 08L MUST HOLD AT THE SAME HOLD LINE AS THERE IS NO ROOM TO HOLD BTN THE RWY ENDS AND SUCH ACFT SHOULD VERIFY THAT THEY ARE ON THE CORRECT RWY.
A110-32GA CUST AND IMG LCTD WEST SIDE OF AFLD BTWN FBO'S.
A110-33ACFT WITH WINGSPAN GTR THAN 135 FT PPR FM DEPT OF AVN TO USE TWY H.
A110-34NMRS HOP ON WEST SIDE OF ARPT.
A110-37GA CBP RSVNS ARE RQRD TO BE SMTD A MIN OF 12 HOURS IN ADVN (OTHER CONDS APPLY). RSVNS MUST BE MADE ONLINE AT WWW.MCCARRAN.COM/GACBP . QNS CAN BE DCTD TO CBP559@MCCARRAN.COM.
A110-38ACFT TAX WB ON TWY B NEAR TWY E USE CARE NOT TO ENTER THE RWY ON TWY Y, ACFT TAX WB ON TWY W NEAR TWY E USE CARE NOT TO ENTER THE RWY ON TWY U.
A110-4ACFT MAY EXPERIENCE REFLECTION OF SUN FM GLASS HOTELS LCTD NW OF ARPT. REFLECTION MAY OCCUR AT VARIOUS ALTS, HDGS, & DSTCS FM ARPT.
A110-41RWY STS LGTS ARE IN OPN.
A110-42PLA AUZD BTN 0200 & 0600.
A110-43CTN PAJA INVOF ARPT.
A110-44WHEN SPL EVENT PRKG PPR PROGRAM NOTAM IS ACTV, TSNT ACFT OPERS NOT PERM BASED NEED TO OBTAIN A PPR NR FM AN FBO FOR EA LDG. PPR APPVL & CONFIRMATION NRS CAN BE OBTAINED FM THE SEL FBO AT 702-261-7775. PPR CONFIRMATION NRS SHOULD BE ENTERED IN THE RMKS SECTION OF EACH FLT PLAN.
A110-45ALL ACFT CTC RAMP CTL ON FREQ 124.4 FOR OPS AT A, B, C GATES, AND GA, CUSTOMS; CTC RAMP CTL FREQ 127.9 FOR OPNS AT D AND E GATES AND CARGO RAMP PRIOR TO ENTERING RAMP OR PUSHING BACK FM GATE OR PRKG SPOT. RAMP CTL OPR HRS 0500-0100L. WHEN RAMP IS CLSD (0100-0500L) BROADCAST ALL NON-MOVEMENT AREA OPNS ON UNICOM 122.95.
A110-46PILOTS CONDUCTING EFVS OPS; BE AWARE LED ALS IN USE.
A110-6GA PRKG VERY LTD. FOR PRKG AVAILABILITY CTC EITHER FBO (702) 736-1830 OR (702) 739-1100.
A110-8RWY 08L 589 FT CWY; RWY 26R 645 FT CWY.
HARRY REID INTL (ICAO: KLAS, IATA: LAS) is a public airport located in LAS VEGAS, NV.
