iFlightPlanner



...
SPRINGERVILLE MUNI - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KJTC
ICAO KJTCLocal JTC
SPRINGERVILLE MUNI
PublicPUB

1 miles WSW of SPRINGERVILLE, AZ, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
34° 07' 46"N 109° 18' 39"W
Elevation
7055' MSL
Pattern Alt
8055' MSL
Mag Variation
9°E
Declination
12°E
Fuel
JET A (FSII), 100LL
FSS
PRESCOTT (PRC)
Sectional
PHOENIX
ARTCC
ALBUQUERQUE (ZAB)
Data Effective
2/19/26-3/19/26
KJTC VFR
6:55 PM MST
Clear
10sm
48°F
12°F
30.15"Hg
240° 5kts
AO2
METAR KJTC 040155Z AUTO 24005KT 10SM CLR 09/M11 A3015 RMK AO2
+ Add Your Business

KJTC FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

AWOS-3PT 119.65
(928) 333-5716

Common

CTAF 122.8
ACTVT PAPI RWY 03, 11 & 21; MIRL RWY 03/21 & 11/29 - CTAF: 5 CLICKS ON; 7 CLICKS OFF.
UNICOM 122.8

Center

ALBUQUERQUE CENTER 132.9
LOW/HIGH, APCH/DEP SVC PRVDD BY ALBUQUERQUE ARTCC (ABQ) ON FREQS 132.9/239.05 (GLOBE NR 1 RCAG).

FAA A/FD Pages

Airport Minimums

Instrument Approach

Terminal Area Forecast

KGUP (87nm)
Tue, 3/3 5:20 PM MST
Tue, 3/3 5:00 PM MST - Wed, 3/4 5:00 PM MST
VFR
5:00 PM MST - 7:00 PM MST
Few 10,000'
6sm
320° 8kts
VFR
7:00 PM MST - 5:00 PM MST
Sky Clear
6sm
VRB° 4kts
TAF KGUP 040020Z 0400/0424 32008KT P6SM FEW100
   FM040200 VRB04KT P6SM SKC
KJTC
No NOTAM Available
No
0800-1600
TOWN OF SPRINGERVILLE
418 EAST MAIN STREET
SPRINGERVILLE, AZ 85938
Phone: 928-333-2656
TOWN OF SPRINGERVILLE
905 WEST AIRPORT RD
SPRINGERVILLE, AZ 85938
Phone: 928-333-5746
PRESCOTT FSS (PRC)
Toll Free: 1-800-WX-BRIEF
PRC
--
ACTVT PAPI RWY 03, 11 & 21; MIRL RWY 03/21 & 11/29 - CTAF: 5 CLICKS ON; 7 CLICKS OFF.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
None
None
None
None
Air Ambulance

Runway 03/21

8422 ft. x 75 ft.
ASPH
Good
NONE
MED

30,000lbs
--
--
--
  Runway 03 Runway 21
True Heading 44°224°
Traffic Pattern Left Right
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 34° 07' 19"N 34° 08' 19"N
Longitude 109° 19' 15"W 109° 18' 05"W
Elevation 7,055' 7,012'
Threshold Crossing Height 46 ft. AGL 35 ft. AGL
Visual Glide Path Angle 4° 3°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights No No
Runway End Identifier Lights

Runway 11/29

4603 ft. x 60 ft.
ASPH
Good
NONE
MED

19,000lbs
--
--
--
  Runway 11 Runway 29
True Heading 128°308°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition POOR POOR
Latitude 34° 07' 54"N 34° 07' 26"N
Longitude 109° 18' 59"W 109° 18' 16"W
Elevation 7,033' 7,042'
Threshold Crossing Height 35 ft. AGL --
Visual Glide Path Angle 3° --
Visual Slope Indicator P2L --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights
A110*GTHIS AIRPORT HAS BEEN SURVEYED BY THE NATIONAL GEODETIC SURVEY.
A110-1MIL TFC INVOF ARPT.
A110-2WILDLIFE ON & INVOF ARPT.
A110-3DENSITY INDCR AT FUEL PUMPS.
A110-5FOR CD CTC ALBUQUERQUE ARTCC AT 505-856-4861.
A43-03PAPI DOES NOT PROVIDE OBSTN CLEARANCE 2 NM BYD THR.
A70-100LLAFT HR - 928-245-0151.
A75-HAVBLTY - AMGR
A81-APTACTVT PAPI RWY 03, 11 & 21; MIRL RWY 03/21 & 11/29 - CTAF: 5 CLICKS ON; 7 CLICKS OFF.
SPRINGERVILLE MUNI (ICAO: KJTC, IATA: JTC) is a public airport located in SPRINGERVILLE, AZ, US.
