No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KJEF
JEFFERSON CITY MEML
PublicPUB

2 miles NE of JEFFERSON CITY, MO
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
38° 35' 28"N 92° 09' 22"W
549' MSL
1549' MSL
03E
JET A, 100LL
COLUMBIA (COU)
KANSAS CITY
KANSAS CITY (ZKC)
7/11/24-8/8/24
KJEF VFR
5:53 AM CDT
Clear
10sm
63°F
59°F
29.93"Hg
140° 5kts
AO2 SLP120 T01720150 PWINO $
KJEF 191053Z AUTO 14005KT 10SM CLR 17/15 A2993 RMK AO2 SLP120 T01720150 PWINO $
Add Your Business

KJEF FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 125.6

ASOS

ASOS
573-635-9266
 133.625

Ground

GND/P
 121.7

Tower

LCL/P
 125.6
LCL/S
FM
 41.95

Other

ARNG OPS
 41.65
ARNG OPS
 142.4
NG OPS
 118.55

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KJEF
Thu, 9/19 12:20 AM CDT
Thu, 9/19 1:00 AM CDT - Fri, 9/20 1:00 AM CDT
VFR
1:00 AM CDT - 3:00 PM CDT
Few 25,000'
6sm
VRB° 3kts
VFR
3:00 PM CDT - 1:00 AM CDT
Sky Clear
6sm
180° 7kts
KJEF 190520Z 1906/2006 VRB03KT P6SM FEW250
   FM192000 18007KT P6SM SKC
KJEF
Domestic
9/11/240511Z !JEF 09/009 JEF OBST TOWER LGT (ASR 1005497) 383937.70N0920722.00W (4.5NM NNE JEF) 1141.7FT (279.9FT AGL) U/S 2409110511-2410110001
9/5/241846Z !JEF 09/008 JEF OBST TOWER LGT (ASR 1006735) 384215.00N0920522.00W (7.5NM NNE JEF) 1784.8FT (944.9FT AGL) U/S 2409051846-2410052359
8/20/241258Z !JEF 08/016 JEF RWY 09/27 END ID LGT U/S 2408201258-2411302359
8/20/241257Z !JEF 08/015 JEF RWY 12 END ID LGT U/S 2408201257-2411302359
8/20/241253Z !JEF 08/012 JEF RWY 27 PAPI U/S 2408201253-2411302359
8/20/241252Z !JEF 08/011 JEF RWY 09 PAPI US 2408201252-2411302359
8/14/240022Z !JEF 08/009 JEF OBST TOWER LGT (ASR 1265104) 383711.40N0922502.50W (12.4NM W JEF) 1121.4FT (279.9FT AGL) U/S 2408140022-2410152359
7/29/240723Z !JEF 07/014 JEF NAV ILS RWY 30 ALGOA LOM U/S 2407290723-2409252000EST
FDC
8/27/241456Z !FDC 4/6526 JEF ODP JEFFERSON CITY MEML, JEFFERSON CITY, MO.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 7...
TAKE-OFF MINIMUMS RWY 27, 300-1 5/8 OR STANDARD WITH MINIMUM CLIMB OF 360 FEET PER NM TO 900. TAKEOFF OBSTACLE NOTES:RWY 27, BRIDGES, BEGINNING 3551 FEET FROM DER, 652 FEET LEFT OF CENTERLINE UP TO 712MSL/UP TO 171AGL (2020-ACE-5307 AND 5310-OE PERMANENT BRIDGES). ALL OTHER DATA REMAINS AS PUBLISHED.. 2408271456-2608271456EST
7/8/241631Z !FDC 4/8083 JEF IAP JEFFERSON CITY MEML, JEFFERSON CITY, MO.
ILS OR LOC RWY 30, AMDT 6...
MISSED APPROACH: CLIMB TO 1500 THEN CLIMBING LEFT TURN TO 2700 DIRECT VIH VOR/DME AND HOLD NE, RT 241.00 INBOUND.
DME REQUIRED EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
JEF LOM OUT OF SERVICE. 2407081631-2410011630EST
4/3/231901Z !FDC 3/5311 JEF IAP JEFFERSON CITY MEML, JEFFERSON CITY, MO.
ILS OR LOC RWY 30, AMDT 6...
S-LOC 30 WAPGY FIX MINIMUMS: MDA 920/HAT 371 ALL CATS, VISIBILITY CATS C/D 5/8.
DISREGARD NOTE: VDP NA WITH COLUMBIA ALTIMETER SETTING.
2304031901-2504301901EST
Yes
0630-2030
CITY OF JEFFERSON
320 E. MCCARTY ST.
JEFFERSON CITY, MO 65101
Phone: 573-634-6469
ERIC BOWERS
320 E. MCCARTY ST.
JEFFERSON CITY, MO 65101
Phone: 573-634-6469
COLUMBIA FSS (COU)
Toll Free: 1-800-WX-BRIEF
JEF
--
WHEN ATCT CLSD ACTVT MALSR RWY 30; REIL RWYS 9, 12, 27; HIRL RWY 12/30; & TWY A LGTS - CTAF. VASI RWYS 12 & 30 OPR CONSLY.
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
42
13
11
5
7
0
Major
Major
High & Low Pressure
None
Air Freight
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 09/27

3401 ft. x 75 ft.
CONC
Good
NONE
MED
11 /R/D/W/T
34,000lbs
44,000lbs
--
--
  Runway 09 Runway 27
True Heading 91°271°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 38° 35' 28"N 38° 35' 27"N
Longitude 92° 09' 51"W 92° 09' 08"W
Elevation 546' 546'
Threshold Crossing Height 23 ft. AGL 29 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes

Runway 12/30

6000 ft. x 100 ft.
CONC
Excellent
GRVD
HIGH
32 /R/D/W/T
85,000lbs
104,000lbs
168,000lbs
--
  Runway 12 Runway 30
True Heading 123°303°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 38° 35' 45"N 38° 35' 13"N
Longitude 92° 09' 50"W 92° 08' 46"W
Elevation 547' 547'
Threshold Crossing Height 64 ft. AGL 50 ft. AGL
Visual Glide Path Angle 3.5° 3°
Visual Slope Indicator V4L V4L
Approach Lights MALSR
Centerline Lights
Runway End Identifier Lights Yes
A110-1LIGHT TO MODERATE BIRD ACTVTY INVOF ARPT.
A110-2ENTRANCES TO E & S HANGARS, NOT VISIBLE BY TWR.
A110-3ARFF AVBL WITH PPR 24 HOURS 573-634-6469.
A110-4FOR CD CTC MIZZOU APCH AT 417-868-5620/5619.
JEFFERSON CITY MEML (ICAO: KJEF, IATA: JEF) is a public airport located in JEFFERSON CITY, MO.
