HARTFORD MUNI - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KHXF
ICAO KHXFLocal HXF
HARTFORD MUNI
PublicPUB

2 miles NW of HARTFORD, WI, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
43° 21' 00"N 88° 23' 25"W
Elevation
1070' MSL
Pattern Alt
1570' MSL
Mag Variation
4°W
Declination
3°W
Fuel
JET A (FSII), 100LL, MOGAS
FSS
GREEN BAY (GRB)
Sectional
CHICAGO
ARTCC
CHICAGO (ZAU)
Data Effective
2/19/26-3/19/26
KETB (12nm) VFR
3:55 AM CST
Clear
10sm
27°F
27°F
30.20"Hg
Calm
AO2
METAR KETB 040955Z AUTO 00000KT 10SM CLR M03/M03 A3020 RMK AO2
+ Add Your Business

KHXF FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 123.0
ACTVT REIL RWY 9 & 27 - CTAF. MIRL RWY 09/27 PRESET TO LOW SS-SR, TO INCR INTST & ACTVT - CTAF.
UNICOM 123.0

Arrival

GOPAC STAR 126.5

Approach

MILWAUKEE APPROACH 125.35

Departure

MILWAUKEE DEPARTURE 125.35

FAA A/FD Pages

Airport Minimums

Departure Procedures

Arrival Procedures

Instrument Approach

Terminal Area Forecast

KUES (20nm)
Wed, 3/4 2:33 AM CST
Wed, 3/4 3:00 AM CST - Thu, 3/5 12:00 AM CST
IFR
Temporary 3:00 AM CST - 7:00 AM CST
Mist
Broken 1,000'
2sm
Calm
MVFR
3:00 AM CST - 9:00 AM CST
Mist
Scattered 1,000'
5sm
Calm
MVFR
9:00 AM CST - 11:00 AM CST
Broken 1,000'
6sm
Calm
VFR
11:00 AM CST - 7:00 PM CST
Scattered 2,000'
6sm
VRB° 4kts
VFR
7:00 PM CST - 9:00 PM CST
Broken 9,000'
6sm
Calm
MVFR
9:00 PM CST - 10:00 PM CST
Broken 3,000'
6sm
Calm
MVFR
10:00 PM CST - 12:00 AM CST
Broken 1,700'
6sm
Calm
TAF KUES 040833Z 0409/0506 00000KT 5SM BR SCT010
   TEMPO 0409/0413 2SM BR BKN010
   FM041500 00000KT P6SM BKN010
   FM041700 VRB04KT P6SM SCT020
   FM050100 00000KT P6SM BKN090
   FM050300 00000KT P6SM BKN030
   FM050400 00000KT P6SM BKN017
KHXF
EffectiveExpiresCategoryNOTAM
Domestic
2/18/26
1513Z
3/4/26
2359Z
!GRB 02/433 HXF OBST TOWER LGT (ASR 1050090) 432918.50N0882146.60W (8.4NM NE HXF) 1419.9FT (370.1FT AGL) U/S 2602181513-2603042359
No
UNATNDD
CITY OF HARTFORD
109 N. MAIN
HARTFORD, WI 53027
Phone: 262-673-8263
TIM PUESTOW
109 N MAIN
HARTFORD, WI 53027
Phone: 262-673-8225
GREEN BAY FSS (GRB)
Toll Free: 1-800-WX-BRIEF
GRB
--
ACTVT REIL RWY 9 & 27 - CTAF. MIRL RWY 09/27 PRESET TO LOW SS-SR, TO INCR INTST & ACTVT - CTAF.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
None
None
None
None
Glider Service
Pilot Instruction
Aircraft Rental
Glider Towing

Runway 09/27

3401 ft. x 75 ft.
ASPH
Excellent
NONE
MED

8,000lbs
--
--
--
  Runway 09 Runway 27
True Heading 91°271°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition FAIR FAIR
Latitude 43° 21' 02"N 43° 21' 02"N
Longitude 88° 23' 46"W 88° 22' 60"W
Elevation 1,051' 1,070'
Threshold Crossing Height 40 ft. AGL 40 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes

Runway 18/36

2231 ft. x 196 ft.
TURF
Good
NONE


--
--
--
--
  Runway 18 Runway 36
True Heading 185°5°
Traffic Pattern Left Left
Markings
Markings Condition
Latitude 43° 21' 08"N 43° 20' 46"N
Longitude 88° 23' 27"W 88° 23' 29"W
Elevation 1,070' 1,036'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No
A110-2GLIDER & ULTRALIGHT ACTVTY ON ARPT.
A110-5(A23) RIGHT TFC PAT ULTRALIGHT & GLIDER ACFT.
A110-6FOR CD CTC CHICAGO ARTCC AT 630-906-8921.
A15TPUESTOW@HARTFORD.WI.GOV.
A30A-18SLIGHT DOWNHILL SLOPE.
A30A-36+78 FT WATER TWR 3885 FT FM APCH END.
A42-18_MARKMKD WITH ORANGE & WHITE WOODEN A-FRAMES.
A42-36_MARKMKD WITH ORANGE & WHITE WOODEN A-FRAMES.
A70-100LL24 HR FUEL AVBL WITH CREDIT CARD.
A81-APTACTVT REIL RWY 9 & 27 - CTAF. MIRL RWY 09/27 PRESET TO LOW SS-SR, TO INCR INTST & ACTVT - CTAF.
E147TPA: 500 FT AGL ULTRALIGHTS.
HARTFORD MUNI (ICAO: KHXF, IATA: HXF) is a public airport located in HARTFORD, WI, US.
