| Domestic |
|
12/28/242306Z
|
!HWV 12/011 HWV OBST TOWER LGT (ASR 1003715) 405726.00N0725257.00W (8.2NM N HWV) 540.0FT (419.9FT AGL) U/S 2412282306-2506012359
|
|
12/19/241305Z
|
!HWV 12/008 HWV RWY 33 PAPI U/S 2412191305-2505012359
|
|
12/19/241305Z
|
!HWV 12/007 HWV RWY 15 PAPI U/S 2412191305-2505012359
|
|
12/11/241845Z
|
!HWV 12/005 HWV RWY 24 RWY END ID LGT U/S 2412111845-2506112111EST
|
|
12/3/241829Z
|
!HWV 12/002 HWV NAV ILS RWY 06 OM U/S 2412031829-2502282111EST
|
|
11/1/242120Z
|
!HWV 11/001 HWV RWY 15/33 N 290FT CLSD TO TKOF AND LDG DELCARED DIST: RWY 15 TORA 3932FT TODA 3932FT ASDA 3932FT LDA 3932FT. RWY 33 TORA 3932FT TODA 3932FT ASDA 3932FT LDA 3932FT. 2411012120-2505012359
|
| FDC |
|
1/3/251818Z
|
!FDC 5/0387 HWV IAP BROOKHAVEN, SHIRLEY, NY.
RNAV (GPS) RWY 15, ORIG-C...
STRAIGHT-IN MINIMUMS NA. CIRCLING RWY 6,15 NA AT NIGHT.
2501031818-2701031817EST
|
|
1/3/251739Z
|
!FDC 5/0374 HWV IAP BROOKHAVEN, SHIRLEY, NY.
ILS OR LOC RWY 6, AMDT 2D...
ADD NOTE: AUTOPILOT COUPLED APPROACH NA BELOW 490FT MSL.
2501031739-2701031739EST
|
|
9/18/231813Z
|
!FDC 3/1513 HWV PART 1 OF 3 ODP BROOKHAVEN, SHIRLEY, NY.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
NOTE: RWY 15: SOLAR PANELS BEGINNING 1 FT FROM DER, 251 FT RIGHT OF
CENTERLINE, UP TO 7 FT AGL/64 FT MSL.
SOLAR PANELS BEGINNING 1 FT FROM DER, 485 FT RIGHT OF CENTERLINE,
UP TO 7 FT AGL/66 FT MSL.
TREES BEGINNING 35 FT FROM DER, 407 FT LEFT OF CENTERLINE, UP TO 63
FT AGL/123 FT MSL.
TRAVERSE WAY 56 FT FROM DER, 493 FT RIGHT OF CENTERLINE, 76 FT MSL.
TREE 167 FT FROM DER, 469 FT LEFT OF CENTERLINE, 65 FT AGL/125 FT
MSL.
TREES BEGINNING 241 FT FROM DER, 231 FT LEFT OF CENTERLINE, UP TO
127 FT MSL.
TREES BEGINNING 446 FT FROM DER, 242 FT RIGHT OF CENTERLINE, UP TO
127 FT MSL.
TREES BEGINNING 2337 FT FROM DER, 334 FT LEFT OF CENTERLINE, UP TO
84 FT AGL/139 FT MSL.
TREE 2556 FT FROM DER, 616 FT RIGHT OF CENTERLINE, 133 FT MSL.
NOTE: RWY 24: ELECTRICAL SYSTEM 13 FT FROM DER, 124 FT LEFT OF
CENTERLINE, 3 FT AGL/71 FT MSL.
TERRAIN 42 FT FROM DER, 270 FT LEFT OF CENTERLINE, 72 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2309181813-2509181813EST
END PART 1 OF 3
!FDC 3/1513 HWV PART 2 OF 3 ODP BROOKHAVEN, SHIRLEY, NY.
TRAVERSE WAY, TERRAIN BEGINNING 55 FT FROM DER, 287 FT RIGHT OF
CENTERLINE, UP TO 73 FT MSL.
SOLAR PANELS BEGINNING 198 FT FROM DER, 503 FT RIGHT OF CENTERLINE,
UP TO 7 FT AGL/77 FT MSL.
TREE 785 FT FROM DER, 686 FT LEFT OF CENTERLINE, 137 FT MSL.
TREE, POLE BEGINNING 941 FT FROM DER, 425 FT LEFT OF CENTERLINE, UP
TO 67 FT AGL/138 FT MSL.
TREES BEGINNING 1099 FT FROM DER, 600 FT RIGHT OF CENTERLINE, UP TO
135 FT MSL.
TREES BEGINNING 1262 FT FROM DER, 199 FT RIGHT OF CENTERLINE, UP TO
140 FT MSL.
TREES BEGINNING 1314 FT FROM DER, 242 FT LEFT OF CENTERLINE, UP TO
141 FT MSL.
TREES BEGINNING 1655 FT FROM DER, 280 FT RIGHT OF CENTERLINE, UP TO
153 FT MSL.
TREES BEGINNING 1672 FT FROM DER, 635 FT LEFT OF CENTERLINE, UP TO
143 FT MSL.
TREES BEGINNING 1747 FT FROM DER, 215 FT LEFT OF CENTERLINE, UP TO
144 FT MSL.
TREES BEGINNING 1996 FT FROM DER, 165 FT LEFT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2309181813-2509181813EST
END PART 2 OF 3
!FDC 3/1513 HWV PART 3 OF 3 ODP BROOKHAVEN, SHIRLEY, NY.
145 FT MSL.
TREES BEGINNING 2090 FT FROM DER, 417 FT RIGHT OF CENTERLINE, UP TO
157 FT MSL.
TREE 3036 FT FROM DER, 288 FT LEFT OF CENTERLINE, 77 FT AGL/147 FT
MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2309181813-2509181813EST
END PART 3 OF 3
|
