6/20/241833Z
|
!FDC 4/1200 HUF PART 1 OF 4 ODP TERRE HAUTE RGNL, TERRE HAUTE, IN.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG-A...
TAKEOFF OBSTACLE NOTES: RWY 5, NAVAID 10 FT FROM DER, 149 FT LEFT
OF CENTERLINE, 4 FT AGL/584 FT MSL.
LIGHT POLE, TERRAIN BEGINNING 10 FT FROM DER, 150 FT RIGHT OF
CENTERLINE, UP TO 4 FT AGL/585 FT MSL.
POLES BEGINNING 969 FT FROM DER, 673 FT RIGHT OF CENTERLINE, UP TO
37 FT AGL/621 FT MSL.
TREES BEGINNING 2260 FT FROM DER, 842 FT LEFT OF CENTERLINE, UP TO
652 FT MSL.
TREES BEGINNING 2389 FT FROM DER, 689 FT LEFT OF CENTERLINE, UP TO
659 FT MSL.
TREE 2955 FT FROM DER, 1231 FT LEFT OF CENTERLINE, 662 FT MSL.
TREE 3249 FT FROM DER, 648 FT LEFT OF CENTERLINE, 665 FT MSL.
TREES BEGINNING 3275 FT FROM DER, 259 FT LEFT OF CENTERLINE, UP TO
677 FT MSL.
TREES BEGINNING 3506 FT FROM DER, 108 FT LEFT OF CENTERLINE, UP TO
682 FT MSL.
RWY 14, LIGHT POLE 40 FT FROM DER, 115 FT LEFT OF CENTERLINE, 3 FT
AGL/591 FT MSL.
TREES BEGINNING 2581 FT FROM DER, 1030 FT LEFT OF CENTERLINE, UP TO
2406201833-2606201833EST
END PART 1 OF 4
!FDC 4/1200 HUF PART 2 OF 4 ODP TERRE HAUTE RGNL, TERRE HAUTE, IN.
665 FT MSL.
TREE 2960 FT FROM DER, 1262 FT LEFT OF CENTERLINE, 666 FT MSL.
TREES BEGINNING 3015 FT FROM DER, 1159 FT LEFT OF CENTERLINE, UP TO
687 FT MSL.
TRANSMISSION LINE 3100 FT FROM DER, 1205 FT RIGHT OF CENTERLINE, 89
FT AGL/672 FT MSL.
TRANSMISSION LINE 3351 FT FROM DER, 387 FT RIGHT OF CENTERLINE, 100
FT AGL/680 FT MSL.
RWY 23, TREE 1875 FT FROM DER, 527 FT RIGHT OF CENTERLINE, 625 FT
MSL.
RWY 32, LIGHT POLE 40 FT FROM DER, 115 FT LEFT OF CENTERLINE, 3 FT
AGL/570 FT MSL.
NAVAID, LIGHT POLE BEGINNING 40 FT FROM DER, 79 FT RIGHT OF
CENTERLINE, UP TO 3 FT AGL/571 FT MSL.
TREE 397 FT FROM DER, 520 FT LEFT OF CENTERLINE, 56 FT AGL/616 FT
MSL.
TREES, POLES, TRANSMISSION LINE BEGINNING 983 FT FROM DER, 313 FT
LEFT OF CENTERLINE, UP TO 63 FT AGL/623 FT MSL.
TREE 2154 FT FROM DER, 811 FT LEFT OF CENTERLINE, 628 FT MSL.
TREES BEGINNING 2384 FT FROM DER, 461 FT LEFT OF CENTERLINE, UP TO
2406201833-2606201833EST
END PART 2 OF 4
!FDC 4/1200 HUF PART 3 OF 4 ODP TERRE HAUTE RGNL, TERRE HAUTE, IN.
658 FT MSL.
TREE 2875 FT FROM DER, 774 FT RIGHT OF CENTERLINE, 644 FT MSL.
TREES BEGINNING 2926 FT FROM DER, 146 FT RIGHT OF CENTERLINE, UP TO
667 FT MSL.
TREES BEGINNING 2955 FT FROM DER, 32 FT LEFT OF CENTERLINE, UP TO
664 FT MSL.
LIGHT POLE, TREES BEGINNING 3380 FT FROM DER, 52 FT LEFT OF
CENTERLINE, UP TO 128 FT AGL/692 FT MSL.
TREES BEGINNING 3493 FT FROM DER, 1137 FT RIGHT OF CENTERLINE, UP
TO 670 FT MSL.
TREES BEGINNING 3542 FT FROM DER, 1174 FT RIGHT OF CENTERLINE, UP
TO 674 FT MSL.
TREES BEGINNING 3666 FT FROM DER, 714 FT RIGHT OF CENTERLINE, UP TO
675 FT MSL.
TREES BEGINNING 3826 FT FROM DER, 1385 FT RIGHT OF CENTERLINE, UP
TO 678 FT MSL.
TREES BEGINNING 4490 FT FROM DER, 1198 FT RIGHT OF CENTERLINE, UP
TO 685 FT MSL.
TREES BEGINNING 4635 FT FROM DER, 341 FT RIGHT OF CENTERLINE, UP TO
698 FT MSL.
2406201833-2606201833EST
END PART 3 OF 4
!FDC 4/1200 HUF PART 4 OF 4 ODP TERRE HAUTE RGNL, TERRE HAUTE, IN.
TREE 5340 FT FROM DER, 995 FT RIGHT OF CENTERLINE, 702 FT MSL.
TREES BEGINNING 5341 FT FROM DER, 851 FT RIGHT OF CENTERLINE, UP TO
145 FT AGL/707 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED.
2406201833-2606201833EST
END PART 4 OF 4
|
