10/15/25 1452Z | 5/27/26 1452Z | | !FDC 5/1113 HTS PART 1 OF 2 ODP TRI-STATE/MILTON J FERGUSON FLD,
HUNTINGTON, WV.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKE-OFF MINIMUMS: RWY 30: STANDARD WITH MINIMUM CLIMB OF 206 FT/NM
TO 1800.
TAKEOFF OBSTACLE NOTES: NOTE: RWY 12: TREES BEGINNING 137 FT FROM
DER, 263 FT LEFT OF CENTERLINE, UP TO 846 FT MSL. TREE 396 FT FROM
DER, 214 FT RIGHT OF CENTERLINE, 847 FT MSL. TREES BEGINNING 512 FT
FROM DER, 35 FT RIGHT OF CENTERLINE, UP TO 848 FT MSL. TREE 718 FT
FROM DER, 233 FT LEFT OF CENTERLINE, 849 FT MSL. TREES BEGINNING
1231 FT FROM DER, 751 FT RIGHT OF CENTERLINE, UP TO 879 FT MSL.
TREE 2381 FT FROM DER, 194 FT LEFT OF CENTERLINE, 897 FT MSL. TREE
2400 FT FROM DER, 285 FT LEFT OF CENTERLINE, 900 FT MSL. TREES
BEGINNING 2406 FT FROM DER, 390 FT LEFT OF CENTERLINE, UP TO 902 FT
MSL. TREES BEGINNING 2524 FT FROM DER, 333 FT LEFT OF CENTERLINE,
UP TO 903 FT MSL.
TAKEOFF OBSTACLE NOTES: NOTE: RWY 30: TREE 76 FT FROM DER, 352 FT
RIGHT OF CENTERLINE, 833 FT MSL. TREE 189 FT FROM DER, 488 FT RIGHT
OF CENTERLINE, 834 FT MSL. TREE 247 FT FROM DER, 538 FT LEFT OF
CENTERLINE, 847 FT MSL. TREE 270 FT FROM DER, 558 FT RIGHT OF
CENTERLINE, 849 FT MSL. TREES BEGINNING 363 FT FROM DER, 498 FT
LEFT OF CENTERLINE, UP TO 852 FT MSL.
2510151452-2605271452EST
END PART 1 OF 2
!FDC 5/1113 HTS PART 2 OF 2 ODP TRI-STATE/MILTON J FERGUSON FLD,
HUNTINGTON, WV.
TREE 529 FT FROM DER, 586 FT RIGHT OF CENTERLINE, 857 FT MSL. TREE
960 FT FROM DER, 716 FT LEFT OF CENTERLINE, 862 FT MSL.
TREES BEGINNING 1093 FT FROM DER, 679 FT LEFT OF CENTERLINE, UP TO
881 FT MSL. TREE 1187 FT FROM DER, 699 FT RIGHT OF CENTERLINE, 870
FT MSL. TREE 1430 FT FROM DER, 790 FT RIGHT OF CENTERLINE, 877 FT
MSL. TREES BEGINNING 1453 FT FROM DER, 604 FT RIGHT OF CENTERLINE,
UP TO 888 FT MSL. TREES BEGINNING 1737 FT FROM DER, 352 FT RIGHT OF
CENTERLINE, UP TO 913 FT MSL. TREES BEGINNING 2829 FT FROM DER, 247
FT LEFT OF CENTERLINE, UP TO 900 FT MSL. TREE 2897 FT FROM DER, 518
FT LEFT OF CENTERLINE, 902 FT MSL. TREE 3015 FT FROM DER, 126 FT
LEFT OF CENTERLINE, 905 FT MSL. TREES BEGINNING 3016 FT FROM DER,
48 FT RIGHT OF CENTERLINE, UP TO 916 FT MSL. TREE 3049 FT FROM DER,
499 FT LEFT OF CENTERLINE, 907 FT MSL. TREES BEGINNING 3168 FT FROM
DER, 181 FT RIGHT OF CENTERLINE, UP TO 944 FT MSL. TREES BEGINNING
3399 FT FROM DER, 30 FT LEFT OF CENTERLINE, UP TO 921 FT MSL. TREE
4590 FT FROM DER, 1211 FT RIGHT OF CENTERLINE, 945 FT MSL.
2510151452-2605271452EST
END PART 2 OF 2
|
