No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KHIO
PORTLAND-HILLSBORO
PublicPUB

15 miles SW of PORTLAND, OR
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
45° 32' 32"N 122° 57' 03"W
208' MSL
1208' MSL
16E
JET A, 100LL
MC MINNVILLE (MMV)
SEATTLE
SEATTLE (ZSE)
4/17/25-5/15/25
KHIO VFR
11:53 PM PDT
Clear
10sm
52°F
43°F
30.22"Hg
300° 5kts
AO2 SLP233 T01110061
KHIO 030653Z AUTO 30005KT 10SM CLR 11/06 A3022 RMK AO2 SLP233 T01110061
+ Add Your Business

KHIO FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 119.3

ATIS

ATIS
 127.65

Ground

GND/P
 121.7

Tower

LCL/P
 119.3
LCL/S
 132.8

Terminal Area Forecast

KHIO
Mon, 6/2 10:20 PM PDT
Mon, 6/2 11:00 PM PDT - Tue, 6/3 11:00 PM PDT
VFR
11:00 PM PDT - 2:00 PM PDT
Sky Clear
6sm
310° 4kts
VFR
2:00 PM PDT - 11:00 PM PDT
Few 4,000'
6sm
320° 12kts
Gusts 20kts
KHIO 030520Z 0306/0406 31004KT P6SM SKC
   FM032100 32012G20KT P6SM FEW040
KHIO
Domestic
5/20/251446Z !HIO 05/041 HIO RWY 31L PAPI U/S 2505201446-2506062000EST
5/16/250356Z !HIO 05/038 HIO RWY 13R PAPI HIGH INTST U/S 2505160356-2507242000EST
5/8/251400Z !HIO 05/014 HIO RWY 20 PAPI U/S THU FRI MON TUE WED 1400-2300 2505081400-2509222300
11/22/241500Z !HIO 11/023 HIO OBST CRANE (2024-ANM-7083-OE) 455531N1229093W (1.76M ENE APCH END RWY 20) 391FT (177FT AGL) FLAGGED AND LGTD FRI MON TUE WED THU 1500-2300 2411221500-2506302300
6/17/241400Z !HIO 06/010 HIO OBST CRANE (2024-ANM-3222-OE) 453305N1225514W (6500FT ENE APCH END RWY 20) 416FT (200FT AGL) FLAGGED AND LGTD 2406171400-2506172000
FDC
5/20/251828Z !FDC 5/3447 HIO IAP PORTLAND-HILLSBORO, PORTLAND, OR.
ILS OR LOC RWY 13R, AMDT 11A...
ALTERNATE MINIMUMS NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
BTG VORTAC UNMONITORED. 2505201828-2506201828EST
5/16/251435Z !FDC 5/1878 HIO IAP PORTLAND-HILLSBORO, PORTLAND, OR.
ILS OR LOC RWY 13R, AMDT 11A...
JIKIM FIX MINIMUMS (DUAL VOR RECEIVERS REQUIRED): CIRCLING CATS A/B MDA 860/HAA 652, CAT C MDA 880/HAA 672, VIS CAT C 1 3/4. TEMPORARY CRANE 460FT MSL 4730FT N OF HIO AIRPORT (2022-ANM-3071-OE), TEMPORARY CRANE 501FT MSL 1.3NM E OF HIO AIRPORT (2023-ANM-6214-OE), TEMPORARY CRANE 380 MSL 1.0NM NE OF HIO AIRPORT (2024-ANM-89-OE), TEMPORARY CRANES UP TO 383 MSL BEGINNING 3700FT NE OF HIO AIRPORT (2024-ANM-791 THRU 794-OE).
2505161435-2508041435EST
5/16/251435Z !FDC 5/1877 HIO IAP PORTLAND-HILLSBORO, PORTLAND, OR.
RNAV (GPS) RWY 13R, AMDT 3...
RNAV (GPS) RWY 31L, AMDT 1A...
CIRCLING CATS A/B MDA 860/HAA 652, CAT C MDA 880/HAA 672, VIS CAT C 1 3/4. TEMPORARY CRANE 460FT MSL 4730FT N OF HIO AIRPORT (2022-ANM-3071-OE), TEMPORARY CRANE 501FT MSL 1.3NM E OF HIO AIRPORT (2023-ANM-6214-OE), TEMPORARY CRANE 380 MSL 1.0NM NE OF HIO AIRPORT (2024-ANM-89-OE), TEMPORARY CRANES UP TO 383 MSL BEGINNING 3700FT NE OF HIO AIRPORT (2024-ANM-791 THRU 794-OE).
2505161435-2508041435EST
4/29/252202Z !FDC 5/3437 HIO ODP PORTLAND-HILLSBORO, PORTLAND, OR.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 7A...
DEPARTURE PROCEDURE NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
UBG VOR OUT OF SERVICE. 2504292202-2506292202EST
4/29/252202Z !FDC 5/3436 HIO IAP PORTLAND-HILLSBORO, PORTLAND, OR.
ILS OR LOC RWY 13R, AMDT 11A...
MISSED APPROACH: CLIMB TO 1000 THEN CLIMBING LEFT TURN TO 4000 ON HEADING 120 AND BTG VORTAC R-175 TO CANBY/BTG 27.24 DME AND HOLD. (DME REQUIRED) CONTINUE CLIMB-IN-HOLD TO 4000,
UBG VOR OUT OF SERVICE. 2504292202-2506292202EST
4/29/252202Z !FDC 5/3435 HIO SID PORTLAND-HILLSBORO, PORTLAND, OR.
CANBY TWO DEPARTURE...
DME REQUIRED EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
UBG VOR OUT OF SERVICE. 2504292202-2506292202EST
4/29/252202Z !FDC 5/3434 HIO SID PORTLAND-HILLSBORO, PORTLAND, OR.
FARMINGTON SEVEN DEPARTURE...
SCAPO SEVEN DEPARTURE...
DEPARTURE PROCEDURE NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
UBG VOR OUT OF SERVICE. 2504292202-2506292202EST
4/29/252202Z !FDC 5/3430 HIO IAP PORTLAND-HILLSBORO, PORTLAND, OR.
NDB-B, AMDT 3A...
MISSED APPROACH: CLIMBING LEFT TURN TO 4000 ON HEADING 120 AND BTG VORTAC R-175 TO CANBY BTG 27.24 DME AND HOLD (DME REQUIRED) CONTINUE CLIMB-IN-HOLD TO 4000,
UBG VOR OUT OF SERVICE. 2504292202-2506292202EST
3/5/251400Z !FDC 5/7995 HIO SID PORTLAND-HILLSBORO, PORTLAND, OR.
CANBY TWO DEPARTURE...
FARMINGTON SEVEN DEPARTURE...
SCAPO SEVEN DEPARTURE...
TAKEOFF MINIMUMS: RWY 2, 300-1. ADD TAKEOFF OBSTACLE NOTE: RWY2, TEMPORARY CRANE, 2037FT FROM DER, 940FT LEFT OF CENTERLINE, 170FT AGL/383FT MSL (2024-ANM-794-OE), TEMPORARY CRANE, 2173FT FROM DER, 1033FT LEFT OF CENTERLINE, 170FT AGL/379FT MSL (2024-ANM-791-OE), TEMPORARY CRANE, 3014FT FROM DER, 12FT LEFT OF CENTERLINE, 170FT AGL/383FT MSL (2024-ANM-793-OE), TEMPORARY CRANE, 3182FT FROM DER, 132FT LEFT OF CENTERLINE, 170FT AGL/382FT MSL (2024-ANM-792-OE). ALL OTHER DATA REMAINS AS PUBLISHED. 2503051400-2510241400EST
3/5/251400Z !FDC 5/7994 HIO ODP PORTLAND-HILLSBORO, PORTLAND, OR.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 7A...
TAKEOFF MINIMUMS: RWY 2, 300-1. ADD TAKEOFF OBSTACLE NOTE: RWY2, RWY2, TEMPORARY CRANE, 2037FT FROM DER, 940FT LEFT OF CENTERLINE, 170FT AGL/383FT MSL (2024-ANM-794-OE), TEMPORARY CRANE, 2173FT FROM DER, 1033FT LEFT OF CENTERLINE, 170FT AGL/379FT MSL (2024-ANM-791-OE), TEMPORARY CRANE, 3014FT FROM DER, 12FT LEFT OF CENTERLINE, 170FT AGL/383FT MSL (2024-ANM-793-OE), TEMPORARY CRANE, 3182FT FROM DER, 132FT LEFT OF CENTERLINE, 170FT AGL/382FT MSL (2024-ANM-792-OE). ALL OTHER DATA REMAINS AS PUBLISHED. 2503051400-2510241400EST
Yes
0600-2200
THE PORT OF PORTLAND
BOX 3529
PORTLAND, OR 97208
Phone: 503-944-7000
STEPHEN M. NAGY
THE PORT OF PORTLAND, BOX 3529
PORTLAND, OR 97208
Phone: 503-460-4119
MC MINNVILLE FSS (MMV)
Toll Free: 1-800-WX-BRIEF
HIO
--
WHEN ATCT CLSD ACTVT MALSR RWY 13R; PAPI RWY 02 & PAPI RWY 20 - CTAF.
N/A
Yes - Lighted
No
Yes
Hanger, Tie-Down
Landing Rights Airport
NOT an Airport of Entry
Major
Major
Low Pressure
High & Low Pressure
Air Freight
Air Ambulance
Avionics
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 02/20

3820 ft. x 75 ft.
ASPH
Good
NONE
MED
20 /F/C/X/T
54,000lbs
74,000lbs
139,000lbs
--
  Runway 02 Runway 20
True Heading 39°219°
Traffic Pattern Right Left
Markings BSC BSC
Markings Condition FAIR FAIR
Latitude 45° 32' 03"N 45° 32' 32"N
Longitude 122° 57' 07"W 122° 56' 33"W
Elevation 204' 208'
Threshold Crossing Height 39 ft. AGL 38 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 13L/31R

3600 ft. x 60 ft.
ASPH
Excellent
NONE
MED
10 /F/D/Y/T
28,000lbs
--
--
--
  Runway 13L Runway 31R
True Heading 144°324°
Traffic Pattern Right
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 45° 33' 00"N 45° 32' 31"N
Longitude 122° 57' 24"W 122° 56' 53"W
Elevation 201' 206'
Threshold Crossing Height 27 ft. AGL 26 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 13R/31L

6600 ft. x 150 ft.
ASPH
Good
NONE
HIGH

50,000lbs
70,000lbs
110,000lbs
--
  Runway 13R Runway 31L
True Heading 143°323°
Traffic Pattern Left Left
Markings PIR NPI
Markings Condition GOOD GOOD
Latitude 45° 32' 59"N 45° 32' 06"N
Longitude 122° 57' 34"W 122° 56' 39"W
Elevation 200' 198'
Threshold Crossing Height 49 ft. AGL 51 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSR
Centerline Lights
Runway End Identifier Lights Yes
A110-1BE ALERT FOR BIRD ACTIVITY IN VICINITY NOV-MAY.
A110-10NIGHTTIME TOUCH AND GOES ARE DISCOURAGED 0600-1400Z++.
A110-11RWY 2-20 HAS 150' X 75' PAVED BLAST PADS AT BOTH ENDS
A110-12RWY 13R-31L HAS 200' X 150' PAVED BLAST PADS AT BOTH ENDS
A110-13GLIDER OPS 5NM NORTHWEST DURING DALGT HOURS MAR-OCT
A110-14BE ALERT EXTV HELICOPTER TRAINING OPERATIONS TO TWY A, TWY B, TWY D.
A110-15FOR CD WHEN TWR CLSD CTC PORTLAND APCH AT 503-493-7545.
A110-2CSTMS AVBL 2000-0400Z++ 503-693-1069, OTHERWISE CSTMS FLT NOTIFICATION SVC (ADCUS) AVBL; ADVANCE COORDINATION REQ 503-326-3230.
A110-3NOISE ABATEMENT PROCEDURES IN EFFECT CALL 503-460-4100 OR 800-938-6647.
A110-4RY 13R RUN-UP AREA NOT VISIBLE FROM ATCT.
A110-6RY 31L IS PREFERRED RY FOR NOISE ABATEMENT.
A110-7NOISE SENSITIVE AREAS BORDER ARPT WEST, SOUTH AND EAST.
A110-8FEE-BASED CSTMS FACILITY: $60 SINGLE-ENGINE, $175 TWIN-ENGINE, $500 TURBINE.
A110-9AVOID LOW-LEVEL OVERFLIGHTS OF RESIDENTIAL AREAS WHENEVER POSSIBLE.
PORTLAND-HILLSBORO (ICAO: KHIO, IATA: HIO) is a public airport located in PORTLAND, OR.
