KHEF
MANASSAS RGNL/HARRY P DAVIS FLD
PublicPUB

28 miles WSW of WASHINGTON, DC
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
38° 43' 16"N 77° 30' 54"W
192' MSL
1192' MSL
10W
JET A, 100LL
LEESBURG (DCA)
WASHINGTON
WASHINGTON (ZDC)
4/17/25-5/15/25
KHEF VFR
6:56 AM EDT
Clear
8sm
63°F
63°F
29.96"Hg
160° 4kts
AO2 SLP148 T01720172
KHEF 241056Z 16004KT 8SM CLR 17/17 A2996 RMK AO2 SLP148 T01720172
+ Add Your Business

KHEF FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 133.1

ATIS

ATIS
703-361-6160
 125.175

Clearance Delivery

CD/P
 120.2

Ground

GND/P
 121.8

Tower

LCL/P
 133.1

Terminal Area Forecast

KIAD (13nm)
Sun, 8/24 4:56 AM EDT
Sun, 8/24 5:00 AM EDT - Mon, 8/25 8:00 AM EDT
VFR
5:00 AM EDT - 6:00 AM EDT
Overcast 5,000'
6sm
160° 7kts
VFR
6:00 AM EDT - 12:00 PM EDT
Showers in vicinity
Broken 14,000'
6sm
180° 5kts
VFR
12:00 PM EDT - 11:00 PM EDT
Broken 7,000'
6sm
170° 4kts
MVFR
4:00 PM EDT - 8:00 PM EDT
Light Thunderstorm and Rain
Overcast 2,500'
6sm
Calm
VFR
11:00 PM EDT - 8:00 AM EDT
Broken 5,000'
6sm
VRB° 3kts
KIAD 240856Z 2409/2512 16007KT P6SM OVC050
   FM241000 18005KT P6SM VCSH BKN140
   FM241600 17004KT P6SM BKN070
   PROB30 2420/2424 6SM -TSRA OVC025CB
   FM250300 VRB03KT P6SM BKN050
KHEF
Domestic
5/24/251000Z !HEF 05/042 HEF OBST CRANE (ASN 2024-AEA-13647-OE) 384511N0773110W (1.9NM N HEF) 481FT (262FT AGL) FLAGGED AND LGTD 2505241000-2505252300
5/21/251400Z !HEF 05/046 HEF NAV ILS RWY 16L LOC/GP U/S 2505211400-2505211800
5/18/250312Z !HEF 05/039 HEF OBST TOWER LGT (ASN 2022-AEA-9225-OE) 384436N0773038W (1.4NM NE HEF) 342FT (132FT AGL) U/S 2505180312-2507020311
5/9/251822Z !HEF 05/026 HEF APRON NORTHWEST APN WIP CONST ADJ W SIDE 2505091822-2508012200
5/8/252055Z !HEF 05/025 HEF OBST TOWER LGT (ASR 1016980) 384326.40N0771719.90W (10.5NM E HEF) 582.7FT (279.9FT AGL) U/S 2505082055-2506082359
5/8/251412Z !HEF 05/024 HEF OBST CRANE (ASN 2024-AEA-9396-OE) 384339N 0773149W (0.8NM NW HEF ) 308FT (125FT AGL) FLAGGED DLY SR-SS 2505081412-2508082200
5/8/251401Z !HEF 05/022 HEF OBST CRANE (ASN 2025-AEA-1979-OE) 384637N0773321W (3.8NM NNW HEF) 441FT (180FT AGL) FLAGGED AND LGTD 2505081401-2508112200
5/8/251400Z !HEF 05/021 HEF OBST CRANE (ASN 2025-AEA-2755-OE) 384635N0773327W (3.9NM NNW HEF) 465FT (200FT AGL) FLAGGED 2505081400-2508082200
9/4/241842Z !HEF 09/009 HEF AIRSPACE SEE FDC 4/1783, 4/1789, 4/9433 ZDC SECURITY INSTRUCTIONS 2409041842-PERM
9/4/241825Z !HEF 09/006 HEF AIRSPACE SEE FDC 4/2565 ZDC SECURITY INSTRUCTIONS 2409041825-PERM
5/3/241500Z !HEF 05/016 HEF AIRSPACE UAS WI AN AREA DEFINES AS 384507.50N0773205.00W (1.7NM NW HEF ) TO 384452.40N0773247.10W (1.1NM NW HEF) TO 384416.40N0773238.60W (1.1NM NW HEF) TO 384438.90N0773135.40W (.7NM N HEF) TO POINT OF ORIGIN SFC-200FT AGL MON-FRI 1500-1700 2405031500-2605031700
FDC
5/21/252030Z !FDC 5/3630 HEF SID MANASSAS RGNL/HARRY P DAVIS FIELD, Washington, DC.
ARSENAL FIVE DEPARTURE...
MARTINSBURG TRANSITION, WOOLY TRANSITION DME REQUIRED EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
AML VOR OUT OF SERVICE. 2505212030-2505272330EST
4/29/251639Z !FDC 5/3056 HEF SID MANASSAS RGNL/HARRY P DAVIS FLD, WASHINGTON, DC.
ARSENAL FIVE DEPARTURE...
GORDONSVILLE TRANSITION NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
GVE VOR OUT OF SERVICE. 2504291639-2508051639EST
4/9/251330Z !FDC 5/4230 HEF IAP MANASSAS RGNL/HARRY P DAVIS FLD, WASHINGTON, DC.
ILS OR LOC RWY 16L, ORIG-A...
S-LOC 16L MDA 760/HAT 568 ALL CATS. VISIBILITY CAT C/D 1 1/4. CIRCLING CAT A/B MDA 760/HAA 568. TEMPORARY CRANE 498FT MSL 2.66 NORTHWEST OF RWY 16L (2024-AEA-12031 THRU 12034-OE). TEMPORARY CRANE 431FT MSL 1.45NM NORTH OF RWY 16L (2024-AEA-2973-OE).
2504091330-2609211329EST
4/8/251758Z !FDC 5/3782 HEF IAP MANASSAS RGNL/HARRY P DAVIS FLD, WASHINGTON, DC.
RNAV (GPS) RWY 16R, AMDT 2...
LNAV/VNAV DA 737/HAT 551 ALL CATS. VISIBILITY ALL CATS 1 5/8. LNAV MDA 760/HAT 574 ALL CATS. VISIBILITY CAT C/D 1 1/4. VDP 1.63NM TO RW16R. CIRCLING CAT A/B MDA 760/HAA 568. TEMPORARY CRANE 498FT MSL 2.26NM NORTHWEST OF RWY 16R (2024-AEA-12031 THRU 12034-OE). TEMPORARY CRANE 413FT MSL 1.37NM NORTH OF RWY 16L (2024-AEA-2962 THRU 2965-OE). TEMPORARY CRANE 431FT MSL 1.52NM NORTH OF RWY 16L (2024-AEA-2973-OE).
2504081758-2609211757EST
4/8/251757Z !FDC 5/3780 HEF IAP MANASSAS RGNL/HARRY P DAVIS FLD, WASHINGTON, DC.
RNAV (GPS) RWY 16L, AMDT 2...
LNAV/VNAV DA 736/HAT 544 ALL CATS. VISIBILITY ALL CATS 1 1/8. LNAV MDA 760/HAT 568 ALL CATS. VISIBILITY CAT C/D 1 1/4. CIRCLING CAT A/B MDA 760/HAA 568. VDP 1.60NM TO RW16L. FOR INOPERATIVE ALS, INCREASE LNAV CAT C/D VISIBILITY TO 1 5/8. TEMPORARY CRANE 498FT MSL 2.66NM NORTHWEST OF RWY 16L (2024-AEA-12031 THRU 12034-OE). TEMPORARY CRANE 413FT MSL 1.37NM NORTH OF RWY 16L (2024-AEA-2962 THRU 2965-OE). TEMPORARY CRANE 431FT MSL 1.45NM NORTH OF RWY 16L (2024-AEA-2973-OE).
2504081757-2609211756EST
3/31/252002Z !FDC 5/0098 HEF SID MANASSAS RGNL/HARRY P DAVIS FLD, WASHINGTON, DC.
ARSENAL FIVE DEPARTURE...
TAKE-OFF MINIMUMS: RWY 34L, 300-2 OR STANDARD WITH MINIMUM CLIMB OF 247FT PER NM TO 485. RWY 34R, 300-2 OR STANDARD WITH MINIMUM CLIMB OF 241FT PER NM TO 483. TEMPORARY CRANE 1.75NM FROM DER, 166FT RIGHT OF CENTERLINE, 183FT AGL/413FT MSL (2024-AEA-2963-OE). TEMPORARY CRANE 1.67NM FROM DER, 657FT LEFT OF CENTERLINE, 143FT AGL/431FT MSL (2024-AEA-2972-OE). TEMPORARY CRANE 1.75NM FROM DER, 166FT RIGHT OF CENTERLINE, 143FT AGL/431FT MSL (2024-AEA-2973-OE).
ALL OTHER DATA REMAINS AS PUBLISHED. 2503312002-2603302001EST
3/31/251959Z !FDC 5/0097 HEF ODP MANASSAS RGNL/HARRY P DAVIS FLD, WASHINGTON, DC.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 4A...
TAKE-OFF MINIMUMS: RWY 34L, 300-2 OR STANDARD WITH MINIMUM CLIMB OF 247FT PER NM TO 485. RWY 34R, 300-2 OR STANDARD WITH MINIMUM CLIMB OF 241FT PER NM TO 483. TEMPORARY CRANE 1.75NM FROM DER, 166FT RIGHT OF CENTERLINE, 183FT AGL/413FT MSL (2024-AEA-2963-OE). TEMPORARY CRANE 1.67NM FROM DER, 657FT LEFT OF CENTERLINE, 143FT AGL/431FT MSL (2024-AEA-2972-OE). TEMPORARY CRANE 1.75NM FROM DER, 166FT RIGHT OF CENTERLINE, 143FT AGL/431FT MSL (2024-AEA-2973-OE).
ALL OTHER DATA REMAINS AS PUBLISHED. 2503311959-2603301950EST
2/21/252300Z !FDC 5/5389 HEF STAR MANASSAS RGNL, MANASSAS, VA TRSTN FOUR ARRIVAL
THHMP TRANSITION ATC ASSIGNED ONLY.
2502212300-2512242300
1/6/251925Z !FDC 5/0774 HEF IAP MANASSAS RGNL/HARRY P DAVIS FLD, WASHINGTON, DC.
RNAV (GPS) RWY 16R, AMDT 2...
LNAV/VNAV DA 682/HAT 496 ALL CATS. LNAV MDA 680/HAT 494 ALL CATS.
2501061925-2701061925EST
1/6/251925Z !FDC 5/0773 HEF IAP MANASSAS RGNL/HARRY P DAVIS FLD, WASHINGTON, DC.
RNAV (GPS) RWY 16L, AMDT 2...
LNAV/VNAV DA 642/HAT 450 ALL CATS. LNAV MDA 680/HAT 488 ALL CATS.
2501061925-2701061925EST
4/30/241703Z !FDC 4/6760 HEF IAP MANASSAS RGNL/HARRY P DAVIS FLD, WASHINGTON, DC.
RNAV (GPS) RWY 34R, AMDT 3A...
CIRCLING CAT A MDA 720/HAA 528.
2404301703-2604301703EST
11/27/231807Z !FDC 3/5479 HEF IAP MANASSAS RGNL/HARRY P DAVIS FLD, WASHINGTON, DC.
RNAV (GPS) RWY 34L, ORIG...
PROCEDURE NA AT NIGHT.
CHANGE HELICOPTER VISIBILITY REDUCTION NOTE TO READ: RWY 34L HELICOPTER VISIBILITY REDUCTION BELOW 1 SM NA.
VDP NA.
2311271807-2511271807EST
Yes
0630-2230
CITY OF MANASSAS
10600 HARRY J. PARRISH BOULEVARD
MANASSAS, VA 20110
Phone: 703-361-1882
JUAN RIVERA
10600 HARRY J. PARRISH BOULEVARD
MANASSAS, VA 20110
Phone: 703-361-1882
LEESBURG FSS (DCA)
Toll Free: 1-800-WX-BRIEF
HEF
--
WHEN ATCT CLSD ACTVT MALSR RWY 16L; MALSF RWY 34R; REILS RWY 16R & 34L; HIRL RWY 16L/34R, MIRL RWY 16R/34L - CTAF.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
Landing Rights Airport
NOT an Airport of Entry
Major
Major
Low Pressure
High & Low Pressure
Avionics
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 16L/34R

6200 ft. x 100 ft.
ASPH
Good
GRVD
HIGH

50,000lbs
140,000lbs
--
--
  Runway 16L Runway 34R
True Heading 151°331°
Traffic Pattern Right
Markings PIR NPI
Markings Condition GOOD GOOD
Latitude 38° 43' 40"N 38° 42' 46"N
Longitude 77° 31' 08"W 77° 30' 29"W
Elevation 192' 177'
Threshold Crossing Height 55 ft. AGL 40 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSR MALSF
Centerline Lights
Runway End Identifier Lights No No

Runway 16R/34L

3715 ft. x 75 ft.
ASPH
Excellent
NONE
MED

30,000lbs
--
--
--
  Runway 16R Runway 34L
True Heading 151°331°
Traffic Pattern Right Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 38° 43' 36"N 38° 43' 04"N
Longitude 77° 31' 16"W 77° 30' 53"W
Elevation 186' 175'
Threshold Crossing Height 54 ft. AGL 43 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes
A110-1BIRDS & DEER ON & INVOF ARPT.
A110-3HELICOPTER OPS OVER RESIDENTIAL AREAS BLW 1000 FT SHOULD BE AVOIDED; CTC AMGR 703-361-1882 FOR INFO.
A110-5US CUSTOMS AVBL MON-SUN 1000-0400Z. CALL COMMAND CENTER 703-661-2800 FOR APNTMT. 24 HR NOTICE RQRD. ALL WKEND FLIGHTS MUST BE ARNGD BFR 1700 LOCAL ON FRI BFR.
A110-6FOR CD WHEN ATCT IS CLSD CTC POTOMAC APCH AT 866-709-4993.
A110-7TRML APN FOR TSNT AND US CUST PRKG.
A110-8TWY B SAFETY AREA WID 44 FT LATERALLY EAST SIDE FM TWY E TO TWY G.
MANASSAS RGNL/HARRY P DAVIS FLD (ICAO: KHEF, IATA: HEF) is a public airport located in WASHINGTON, DC.
