KGRR
GERALD R FORD INTL
PublicPUB

6 miles SE of GRAND RAPIDS, MI
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
42° 52' 51"N 85° 31' 22"W
794' MSL
1794' MSL
06W
JET A, 100LL
LANSING (LAN)
CHICAGO
CHICAGO (ZAU)
10/31/24-11/28/24
KGRR VFR
6:53 AM EST
Few 25,000'
10sm
33°F
30°F
30.35"Hg
080° 5kts
AO2 SLP281 T00061011 10039 20006 58001
KGRR 091153Z 08005KT 10SM FEW250 01/M01 A3035 RMK AO2 SLP281 T00061011 10039 20006 58001
Add Your Business

KGRR FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 135.65

ATIS

ATIS
 118.725

Clearance Delivery

CD/P
 119.3

Emergency

EMERG
 121.5

Ground

GND/P
 121.8

Tower

LCL/P
 135.65

Terminal Area Forecast

KGRR
Sat, 11/9 6:20 AM EST
Sat, 11/9 7:00 AM EST - Sun, 11/10 7:00 AM EST
VFR
7:00 AM EST - 10:00 AM EST
Few 25,000'
6sm
090° 7kts
VFR
10:00 AM EST - 2:00 AM EST
Broken 25,000'
6sm
130° 9kts
VFR
2:00 AM EST - 5:00 AM EST
Light Showers and Rain
Broken 8,000'
6sm
130° 7kts
MVFR
5:00 AM EST - 6:00 AM EST
Light Showers and Rain
Overcast 2,400'
6sm
130° 7kts
MVFR
6:00 AM EST - 7:00 AM EST
Light Showers and Rain
Overcast 1,600'
6sm
140° 8kts
KGRR 091120Z 0912/1012 09007KT P6SM FEW250
   FM091500 13009KT P6SM BKN250
   FM100700 13007KT P6SM -SHRA BKN080
   FM101000 13007KT 6SM -SHRA OVC024
   FM101100 14008KT 6SM -SHRA OVC016
KGRR
Domestic
11/6/241500Z !GRR 11/051 GRR NAV ILS RWY 35 U/S 2411061500-2411062000
11/6/241430Z !GRR 11/054 GRR RWY 17/35 CLSD 2411061430-2411061730
11/6/241430Z !GRR 11/047 GRR RWY 35 PAPI U/S 2411061430-2411061700
11/6/241400Z !GRR 11/046 GRR RWY 17 PAPI U/S 2411061400-2411061730
11/6/241300Z !GRR 11/064 GRR TWY V CLSD 2411061300-2411071600
11/6/241300Z !GRR 11/061 GRR TWY K BTN TWY V AND AVFLIGHT APN CLSD 2411061300-2411071600
11/6/241023Z !GRR 11/063 GRR TWY V BTN TWY K AND UPS APN CLSD 2411061023-2411061300
11/6/241023Z !GRR 11/062 GRR TWY V BTN TWY B AND AIR CARRIER APN CLSD 2411061023-2411061300
11/6/240853Z !GRR 11/060 GRR RWY 17 FICON 5/5/5 50 PCT WET OBS AT 2411060853. 2411060853-2411061300
11/6/240852Z !GRR 11/059 GRR RWY 26L FICON 5/5/5 50 PCT WET OBS AT 2411060851. 2411060852-2411070852
11/6/240851Z !GRR 11/058 GRR RWY 26R FICON 5/5/5 50 PCT WET OBS AT 2411060851. 2411060851-2411070851
11/5/242325Z !GRR 11/053 GRR AIRSPACE SEE VIO 11/052 UAS 2411052325-2411062330
11/2/240850Z !GRR 11/012 GRR OBST TOWER LGT (ASR 1004467) 425915.00N0853726.00W (7.8NM NW GRR) 1269.7FT (500.0FT AGL) U/S 2411020850-2412020001
10/31/240959Z !GRR 10/172 GRR TWY D EDGE MARKINGS AT RWY 17/35 AND TWY A WEST SIDE
REMOVED 2410310959-2411302359
10/31/240958Z !GRR 10/171 GRR TWY J HOLD PAD FOR RWY 26R EDGE MARKINGS REMOVED 2410310958-2411302359
10/29/242100Z !GRR 10/148 GRR TWY D1 EDGE MARKINGS BTN FEDEX APN AND TWY D EAST SIDE REMOVED 2410292100-2411302359
10/24/241330Z !GRR 10/125 GRR RWY 26R RWY END ID LGT U/S 2410241330-2501092000EST
10/2/241928Z !GRR 10/014 GRR TWY F BTN NORTHERN JET APN AND TWY D CLSD 2410021928-2411082200
8/29/240530Z !GRR 08/275 GRR OBST TOWER LGT (ASR 1023922) 424633.00N0853258.00W (6.4NM S GRR) 1046.9FT (250.0FT AGL) U/S 2408290530-2412270530
5/15/240114Z !GRR 05/144 GRR OBST CRANE (ASN 2023-AGL-13076-NRA) 425310N0853142W (0.4NM NW GRR) 947FT (150FT AGL) FLAGGED AND LGTD 2405150114-2505312359
5/14/241630Z !GRR 05/140 GRR OBST CRANE (ASN 2024-AGL-198-NRA) 425229N0853227W (0.9NM WSW GRR) 906FT (116FT AGL) FLAGGED AND LGTD 2405141630-2411302359
4/15/241100Z !GRR 04/086 GRR OBST CRANE (ASN 2023-AGL-12740-NRA) 425315N0853045W (0.6NM NE GRR) 882FT (100FT AGL) FLAGGED AND LGTD 2404151100-2504271100
4/10/241100Z !GRR 04/085 GRR APRON AIR CARRIER APN WIP CONST LGTD AND BARRICADED 2404101100-2708012100
4/10/241100Z !GRR 04/084 GRR APRON AIR CARRIER APN CLSD N OF GATE A6 2404101100-2708012100
FDC
10/23/241909Z !FDC 4/3241 GRR IAP GERALD R FORD INTL, GRAND RAPIDS, MI.
ILS OR LOC RWY 26L, AMDT 21C...
GLGHR INT MINIMUMS (DUAL VOR RECEIVERS REQUIRED) CIRCLING CATS A/B MDA 1300/HAA 506. TEMPORARY CRANE 949 MSL 2767 N OF GRR AIRPORT (2023-AGL-13073-NRA).
2410231909-2506151909EST
10/23/241909Z !FDC 4/3234 GRR IAP GERALD R FORD INTL, GRAND RAPIDS, MI.
RNAV (GPS) RWY 17, AMDT 1C...
LNAV MDA 1260/HAA 472 ALL CATS, VIS CATS A/B RVR 5500, VIS CATS C/D 1 3/8. CIRCLING CATS A/B MDA 1300/HAA 506. VDP 1.30 NM TO RW17. TEMPORARY CRANE 949 MSL 2657FT W OF RWY 17 (2023-AGL-13073-NRA).
2410231909-2506151909EST
10/23/241909Z !FDC 4/3232 GRR IAP GERALD R FORD INTL, GRAND RAPIDS, MI.
ILS OR LOC RWY 8R, AMDT 6B...
RNAV (GPS) RWY 26L, AMDT 1C...
RNAV (GPS) RWY 26R, AMDT 1B...
RNAV (GPS) RWY 35, AMDT 1D...
RNAV (GPS) RWY 8L, AMDT 1B...
RNAV (GPS) RWY 8R, AMDT 1C...
VOR RWY 17, ORIG-F...
CIRCLING CATS A/B MDA 1300/HAA 506. TEMPORARY CRANE 949 MSL 2767 N OF GRR AIRPORT (2023-AGL-13073-NRA).
2410231909-2506151909EST
10/23/241909Z !FDC 4/3230 GRR IAP GERALD R FORD INTL, GRAND RAPIDS, MI.
ILS OR LOC RWY 35, AMDT 2B...
HONSE MINIMUMS (ADF OR DME REQUIRED) CIRCLING CATS A/B MDA 1300/HAA 506. TEMPORARY CRANE 949 MSL 2767 N OF GRR AIRPORT (2023-AGL-13073-NRA).
2410231909-2506151909EST
Yes
ALL
GERALD R FORD INTL ARPT AUTH
5500 44TH ST SE
GRAND RAPIDS, MI 49512
Phone: 616-233-6000
TORRANCE RICHARDSON
5500 44TH ST SE
GRAND RAPIDS, MI 49512
Phone: 616-233-6000
LANSING FSS (LAN)
Toll Free: 1-800-WX-BRIEF
GRR
--
WHEN ATCT CLSD ACTVT MALSR RWY 08R, 26L, & 35; REIL RWY 08L, 26R, & 17; HIRL RWY 08R/26L & 17/35; MIRL RWY 08L/26R - CTAF.
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
High Pressure
High Pressure
Air Freight
Air Ambulance
Avionics
Cargo Handling
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 08L/26R

5001 ft. x 100 ft.
ASPH
Good
GRVD
MED
45 /F/C/X/T
110,000lbs
160,000lbs
--
--
  Runway 08L Runway 26R
True Heading 81°261°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 42° 53' 20"N 42° 53' 27"N
Longitude 85° 32' 25"W 85° 31' 18"W
Elevation 786' 784'
Threshold Crossing Height 45 ft. AGL 33 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator V4L V4L
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes

Runway 08R/26L

10001 ft. x 150 ft.
CONC
Good
GRVD
HIGH
62 /R/B/W/T
--
190,000lbs
350,000lbs
--
  Runway 08R Runway 26L
True Heading 81°261°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 42° 52' 36"N 42° 52' 51"N
Longitude 85° 32' 32"W 85° 30' 19"W
Elevation 792' 789'
Threshold Crossing Height -- 73 ft. AGL
Visual Glide Path Angle -- 3°
Visual Slope Indicator -- P4L
Approach Lights MALSR MALSR
Centerline Lights No No
Runway End Identifier Lights No No

Runway 17/35

8501 ft. x 150 ft.
CONC
Good
GRVD
HIGH
60 /R/B/W/T
--
190,000lbs
350,000lbs
--
  Runway 17 Runway 35
True Heading 171°351°
Traffic Pattern
Markings NPI PIR
Markings Condition GOOD GOOD
Latitude 42° 53' 22"N 42° 51' 59"N
Longitude 85° 31' 09"W 85° 30' 52"W
Elevation 782' 789'
Threshold Crossing Height 50 ft. AGL 74 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4R
Approach Lights MALSR
Centerline Lights No No
Runway End Identifier Lights Yes No
A110-1TWY F NORTH OF TWY V, TWY J BTN TWY F & TWY J3 & TWY G CLSD TO AIRCRAFT OVER 100,000 LBS; TWY F SOUTH OF TWY V & TWY J EAST OF TWY F & WEST OF TWY J3 CLSD TO ACFT OVER 47,000 LBS.
A110-10TWY R NORTH OF TWY D, TWY Y NORTH OF TWY D, TWY Z NORTH OF TWY D AND TWY N ARE NON-MOVEMENT AREAS.
A110-11PUSHBACK ADVISORIES ON THE TERMINAL RAMP ARE NOT PRVDD BY ATC.
A110-14ARPT PSNL WILL MNT CTAF WHEN ATCT IS CLSD.
A110-15TWY Y 400 FT NORTH OF TWY D CLSD TO ACFT OVER 100,000 LBS.; TWY R NORTH OF TWY D CLSD TO ACFT OVER 175,000 LBS.
A110-16AIR CARRIER APRON CLOSED TO GA AIRCRAFT.
A110-17CTC FBO FOR THEIR HRS OF OPN.
A110-18FOR CD WHEN TWR CLSD CTC GREAT LAKES APCH AT 269-459-3344, WHEN APCH CLSD CTC CHICAGO ARTCC AT 630-906-8921.
A110-2BIRDS ON & INVOF ARPT.
A110-8NOISE ABATEMENT PROCEDURES: RY 08R DEP ON RY HEADING UNTIL REACHING THE HWY EAST OF ARPT; RY 26L ON APCH TO ARPT TURN FINAL AT HWY EAST OF ARPT.
A110-9PPR FOR ACFT WITH 171 FT WINGSPAN OR LARGER.
GERALD R FORD INTL (ICAO: KGRR, IATA: GRR) is a public airport located in GRAND RAPIDS, MI.
