7/11/231425Z
|
!FDC 3/4210 GLR PART 1 OF 2 ODP GAYLORD RGNL, GAYLORD, MI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES, NOTE: RWY 9: NAVAID 39 FT FROM DER, 115 FT
RIGHT OF CENTERLINE, 2 FT AGL/1331 FT MSL. NAVAID 39 FT FROM DER,
114 FT LEFT OF CENTERLINE, 2 FT AGL/1331 FT MSL. NAVAID 166 FT
FROM DER, 259 FT LEFT OF CENTERLINE, 5 FT AGL/1334 FT MSL. TREES
BEGINNING 855 FT FROM DER, 357 FT LEFT OF CENTERLINE, UP TO 1371 FT
MSL. NOTE: RWY 27: TREE 595 FT FROM DER, 622 FT LEFT OF
CENTERLINE, 1357 FT MSL. TREES BEGINNING 690 FT FROM DER, 630 FT
RIGHT OF CENTERLINE, UP TO 1369 FT MSL. TREE 788 FT FROM DER, 680
FT LEFT OF CENTERLINE, 1362 FT MSL. TREES BEGINNING 1142 FT FROM
DER, 707 FT LEFT OF CENTERLINE, UP TO 1373 FT MSL. TREES BEGINNING
1345 FT FROM DER, 232 FT RIGHT OF CENTERLINE, UP TO 1378 FT MSL.
TREES BEGINNING 2386 FT FROM DER, 332 FT RIGHT OF CENTERLINE, UP TO
1383 FT MSL. TREE 2469 FT FROM DER, 339 FT RIGHT OF CENTERLINE,
1387 FT MSL. TREES BEGINNING 2862 FT FROM DER, 233 FT LEFT OF
CENTERLINE, UP TO 1396 FT MSL. TREE 3074 FT FROM DER, 1160 FT LEFT
OF CENTERLINE, 1404 FT MSL. TREE 3112 FT FROM DER, 1274 FT LEFT OF
CENTERLINE, 1405 FT MSL. TREE 3206 FT FROM DER, 1141 FT LEFT OF
CENTERLINE, 1406 FT MSL. TREE 5366 FT FROM DER, 246 FT RIGHT OF
CENTERLINE, 1456 FT MSL. TREES BEGINNING 5381 FT FROM DER, 299 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2307111425-2507111425EST
END PART 1 OF 2
!FDC 3/4210 GLR PART 2 OF 2 ODP GAYLORD RGNL, GAYLORD, MI.
RIGHT OF CENTERLINE, UP TO 1457 FT MSL. NOTE: RWY 36: TRAVERSE WAY
50 FT FROM DER, 177 FT LEFT OF CENTERLINE, 1333 FT MSL. TREES
BEGINNING 420 FT FROM DER, 191 FT LEFT OF CENTERLINE, UP TO 1386 FT
MSL. TREE 627 FT FROM DER, 586 FT RIGHT OF CENTERLINE, 1374 FT
MSL. TREE 753 FT FROM DER, 547 FT RIGHT OF CENTERLINE, 1393 FT
MSL. TREES BEGINNING 794 FT FROM DER, 515 FT RIGHT OF CENTERLINE,
UP TO 79 FT AGL/1400 FT MSL. TREES BEGINNING 1145 FT FROM DER, 149
FT LEFT OF CENTERLINE, UP TO 1395 FT MSL. TREES BEGINNING 1370 FT
FROM DER, 481 FT RIGHT OF CENTERLINE, UP TO 1401 FT MSL. TREES
BEGINNING 1668 FT FROM DER, 659 FT LEFT OF CENTERLINE, UP TO 1396
FT MSL. TREE 1714 FT FROM DER, 887 FT RIGHT OF CENTERLINE, 1405 FT
MSL.
TREES BEGINNING 1735 FT FROM DER, 499 FT LEFT OF CENTERLINE, UP TO
1397 FT MSL. TREES BEGINNING 1740 FT FROM DER, 428 FT RIGHT OF
CENTERLINE, UP TO 1407 FT MSL. TREES BEGINNING 1828 FT FROM DER,
340 FT LEFT OF CENTERLINE, UP TO 1398 FT MSL. TREES BEGINNING 1935
FT FROM DER, 37 FT RIGHT OF CENTERLINE, UP TO 1410 FT MSL.
TREES BEGINNING 1958 FT FROM DER, 27 FT LEFT OF CENTERLINE, UP TO
1404 FT MSL. TREES BEGINNING 2491 FT FROM DER, 208 FT LEFT OF
CENTERLINE, UP TO 87 FT AGL/1407 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2307111425-2507111425EST
END PART 2 OF 2
|
