No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KGKY
ARLINGTON MUNI
PublicPUB

4 miles S of ARLINGTON, TX
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
32° 39' 50"N 97° 05' 39"W
628' MSL
1628' MSL
06E
JET A, 100LL
FORT WORTH (FTW)
DALLAS-FT WORTH
FORT WORTH (ZFW)
4/17/25-5/15/25
KGKY VFR
1:53 AM CDT
Clear
10sm
68°F
60°F
30.06"Hg
Calm
AO2 SLP170 T02000156 $
METAR KGKY 140653Z AUTO 00000KT 10SM CLR 20/16 A3006 RMK AO2 SLP170 T02000156 $
+ Add Your Business

KGKY FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 128.625

ASOS

ASOS
817-557-0251
 127.375

Clearance Delivery

CD/P
 121.875

Ground

GND/P
 121.875

Tower

LCL/P
 128.625

Terminal Area Forecast

KGKY
Tue, 10/14 12:20 AM CDT
Tue, 10/14 1:00 AM CDT - Wed, 10/15 1:00 AM CDT
VFR
1:00 AM CDT - 1:00 AM CDT
Sky Clear
6sm
100° 5kts
TAF KGKY 140520Z 1406/1506 10005KT P6SM SKC
KGKY
EffectiveExpiresCategoryNOTAM
Domestic
9/3/25
1200Z
10/15/25
2359Z
!GKY 08/011 GKY OBST CRANE (ASN UNKNOWN) 324008N0970624W (.3NM NW GKY) UNKNOWN (180FT AGL) FLAGGED 2509031200-2510152359
4/26/25
1147Z
11/2/25
2337Z
!GKY 04/016 GKY AIRSPACE SEE FUZ 04/721 UAS DLY SR-SS
2504261147-2511022337
4/26/25
1147Z
11/2/25
2337Z
!GKY 04/015 GKY AIRSPACE SEE TTT 04/720 UAS DLY SR-SS
2504261147-2511022337
3/9/25
1246Z
11/2/25
2336Z
!GKY 03/011 GKY AIRSPACE SEE TTT 03/419 UAS DLY SR-SS
2503091246-2511022336
FDC
10/7/25
1430Z
10/14/25
2119Z
!FDC 5/6996 GKY SID ARLINGTON MUNI, ARLINGTON, TX.
KINGDOM FIVE DEPARTURE...
WICHITA FALLS TRANSITION: NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
SPS VOR OUT OF SERVICE. 2510071430-2510142119EST
10/1/25
1712Z
11/20/25
1712Z
!FDC 5/3898 GKY SID ARLINGTON MUNI, ARLINGTON, TX.
TEXOMA FIVE DEPARTURE...
OKMULGEE TRANSITION NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
OKM VOR/DME OUT OF SERVICE. 2510011712-2511201712EST
9/20/25
1700Z
!FDC 5/7339 GKY IAP ARLINGTON MUNI, ARLINGTON, TX.
RNAV (GPS) RWY 16, AMDT 1...
LNAV CAT A/B/C MDA 1220/HAT 592 ALL. VIS CAT C 1 3/4.
CIRCLING CAT A MDA 1280/HAA 652, CAT B/C MDA 1340/HAA 712. VIS CAT C 2.
DISREGARD TONNE FIX AND TONNE FIX ALTITUDE.
TEMPORARY CRANE, 920FT MSL, 5850FT NW OF RWY 16 (2023-ASW-14967-OE), TEMPORARY CRANE 807 MSL 1740FT SW OF RWY 16 (2024-ASW-940-NRA), TEMPORARY CRANE, 809 MSL, 1343FT WEST OF RWY 16 (2024-ASW-942-NRA), TEMPORARY CRANE, 979 MSL, 1.93 NM NW OF KGKY (2025-ASW-7959-OE), TEMPORARY CRANE, 902 MSL, 3.12 NM NE OF KGKY AIRPORT (2025-ASW-8720-OE).
2509201700-2511050134EST
9/20/25
1700Z
!FDC 5/7338 GKY IAP ARLINGTON MUNI, ARLINGTON, TX.
ILS OR LOC/DME RWY 34, AMDT 2D...
RNAV (GPS) RWY 34, AMDT 3D...
CIRCLING CAT A MDA 1280/HAA 652, CAT B/C MDA 1340/HAA 712. VIS CAT C 2.
TEMPORARY CRANE, 979 MSL 1.93 NM NW OF KGKY (2025-ASW-7959-OE), TEMPORARY CRANE, 920FT MSL, 1.39 NM NW OF KGKY AIRPORT(2023-ASW-14967-OE), TEMPORARY CRANE 807 MSL 3057FT NW OF GKY AIRPORT (2024-ASW-940-NRA), TEMPORARY CRANE, 809 MSL, 3340FT NW OF KGKY AIRPORT (2024-ASW-942-NRA), TEMPORARY CRANE, 902 MSL, 3.12 NM NE OF KGKY AIRPORT (2025-ASW-8720-OE).
2509201700-2511050134EST
9/17/25
0600Z
!FDC 5/5670 GKY IAP ARLINGTON MUNI, ARLINGTON, TX.
RNAV (GPS) RWY 16, AMDT 1...
LNAV CAT A/B/C MDA 1220/HAT 592 ALL. VIS CAT C 1 3/4.
CIRCLING CAT A MDA 1280/HAA 652, CAT B/C MDA 1340/HAA 712. VIS CAT C 2.
DISREGARD TONNE FIX AND TONNE FIX ALTITUDE.
TEMPORARY CRANE, 920FT MSL, 5850FT NW OF RWY 16 (2023-ASW-14967-OE), TEMPORARY CRANE 807 MSL 1740FT SW OF RWY 16 (2024-ASW-940-NRA), TEMPORARY CRANE, 809 MSL, 1343FT WEST OF RWY 16 (2024-ASW-942-NRA), TEMPORARY CRANE, 979 MSL, 1.93 NM NW OF KGKY (2025-ASW-7959-OE).
2509170600-2510232333EST
9/17/25
0600Z
!FDC 5/5669 GKY IAP ARLINGTON MUNI, ARLINGTON, TX.
ILS OR LOC/DME RWY 34, AMDT 2D...
RNAV (GPS) RWY 34, AMDT 3D...
CIRCLING CAT A MDA 1280/HAA 652, CAT B/C MDA 1340/HAA 712. VIS CAT C 2.
TEMPORARY CRANE, 979 MSL 1.93 NM NW OF KGKY (2025-ASW-7959-OE), TEMPORARY CRANE, 920FT MSL, 1.39 NM NW OF KGKY AIRPORT(2023-ASW-14967-OE), TEMPORARY CRANE 807 MSL 3057FT NW OF GKY AIRPORT (2024-ASW-940-NRA), TEMPORARY CRANE, 809 MSL, 3340FT NW OF KGKY AIRPORT (2024-ASW-942-NRA)..
2509170600-2510232333EST
8/11/25
1824Z
!FDC 5/5469 GKY SID ARLINGTON MUNI, ARLINGTON, TX.
BOTCH ONE DEPARTURE (RNAV)...
BRHMA TRANSITION: RUFFS TO KATZZ, MOCA 3500. ALIAN TRANSITION: FUMED TO ALIAN, MOCA 3200. CIKAN TRANSITION, DOSXX TRANSITION, WSTEX TRANSITION: LYNDE TO WSTEX, MOCA 3300.
ALL OTHER DATA REMAINS AS PUBLISHED. 2508111824-2603231824EST
5/2/25
1757Z
!FDC 5/5138 GKY SID ARLINGTON MUNI, ARLINGTON, TX.
KINGDOM FIVE DEPARTURE...
LUBBOCK TRANSITION, MILLSAP TRANSITION, WICHITA FALLS TRANSITION NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
MQP VORTAC OUT OF SERVICE. 2505021757-2512121757EST
5/2/25
1757Z
!FDC 5/5120 GKY SID ARLINGTON MUNI, ARLINGTON, TX.
WORTH ONE DEPARTURE...
ABILENE TRANSITION, CORONA TRANSITION, LUBBOCK TRANSITION, TEXICO TRANSITION: NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
MQP VORTAC OUT OF SERVICE. 2505021757-2512121757EST
5/2/25
1757Z
12/12/25
1757Z
!FDC 5/5112 GKY IAP ARLINGTON MUNI, ARLINGTON, TX.
ILS OR LOC/DME RWY 34, AMDT 2D...
PROCEDURE NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
MQP VORTAC OUT OF SERVICE. 2505021757-2512121757EST
3/13/25
1300Z
6/7/26
1218Z
!FDC 5/2687 GKY SID ARLINGTON MUNI, ARLINGTON, TX.
WORTH ONE DEPARTURE...
CORONA TRANSITION NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
CNX VORTAC OUT OF SERVICE. 2503131300-2606071218EST
2/28/25
2359Z
2/26/26
2359Z
!FDC 5/7929 GKY STAR ARLINGTON MUNICIPAL ARLINGTON,TX.
MOTZA1 ARRIVAL
DME REQUIRED ENTIRE ARRIVAL PROCEDURE

2502282359-2602262359
2/16/24
2112Z
2/15/26
2359Z
!FDC 4/6416 GKY STAR DODJE STAR NA OR ONLY USABLE FOR AIRCRAFT WITH
SUITABLE RNAV EQUIPMENT

2402162112-2602152359EST
2/9/24
1650Z
2/8/26
0559Z
!FDC 4/3192 GKY STAR ARLINGTON MUNICIPAL, ARLINGTON, TX
TRUUK TWO RNAV STAR...MOCA BTN BLECO AND TRUUK NOW 2200FT

2402091650-2602080559
Yes
ALL
CITY OF ARLINGTON
PO BOX 90231
ARLINGTON, TX 76004-3231
Phone: 817-459-5571
TRENT BALLARD
5000 S. COLLINS, STE 100
ARLINGTON, TX 76018-3231
Phone: 817-459-5571
FORT WORTH FSS (FTW)
Toll Free: 1-800-WX-BRIEF
GKY
--
MIRL RWY 16/34 PRESET MED INTST; HIGHER INTST BY ATCT REQ. WHEN ATCT CLSD ACTVT MALSR RWY 34 - CTAF.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Major
Major
Low Pressure
None
Avionics
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 16/34

6080 ft. x 100 ft.
CONC
Good
NONE
MED

60,000lbs
--
--
--
  Runway 16 Runway 34
True Heading 168°348°
Traffic Pattern Left Left
Markings NPI PIR
Markings Condition GOOD GOOD
Latitude 32° 40' 19"N 32° 39' 21"N
Longitude 97° 05' 47"W 97° 05' 32"W
Elevation 628' 597'
Threshold Crossing Height 42 ft. AGL 55 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSR
Centerline Lights
Runway End Identifier Lights Yes No
A110-1EXTSV HEL TFC WEST OF RWY.
ARLINGTON MUNI (ICAO: KGKY, IATA: GKY) is a public airport located in ARLINGTON, TX.
