11/28/23 1451Z | 11/28/25 1451Z | | !FDC 3/6253 FRG PART 1 OF 6 ODP REPUBLIC, FARMINGDALE, NY.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 7...
CHANGE TAKEOFF OBSTACLE NOTES TO READ:
NOTE: RWY 1: POLE 2 FT FROM DER, 451 FT LEFT OF CENTERLINE, 8 FT
AGL/83 FT MSL.
SIGNS BEGINNING 18 FT FROM DER, 140 FT RIGHT OF CENTERLINE, UP TO 3
FT AGL/83 FT MSL.
TREE, BUILDING BEGINNING 31 FT FROM DER, 319 FT RIGHT OF
CENTERLINE, UP TO 39 FT AGL/119 FT MSL.
POLE 70 FT FROM DER, 290 FT LEFT OF CENTERLINE, 9 FT AGL/85 FT MSL.
FENCE 73 FT FROM DER, 252 FT LEFT OF CENTERLINE, 11 FT AGL/88 FT
MSL.
TRAVERSE WAY, POLE BEGINNING 95 FT FROM DER, 268 FT LEFT OF
CENTERLINE, UP TO 91 FT MSL.
TREES, POLES, FENCE, TRAVERSE WAYS BEGINNING 115 FT FROM DER, 252
FT LEFT OF CENTERLINE, UP TO 25 FT AGL/101 FT MSL.
TREE, BUILDING BEGINNING 143 FT FROM DER, 268 FT RIGHT OF
CENTERLINE, UP TO 52 FT AGL/132 FT MSL.
TREE, FENCE BEGINNING 203 FT FROM DER, 334 FT RIGHT OF CENTERLINE,
UP TO 54 FT AGL/134 FTMSL.
TREES, POLES, FENCE, BUILDINGS, AGRICULTURAL EQUIPMENT BEGINNING
ALL OTHER DATA REMAINS AS PUBLISHED. 2311281451-2511281451EST
END PART 1 OF 6
!FDC 3/6253 FRG PART 2 OF 6 ODP REPUBLIC, FARMINGDALE, NY.
272 FT FROM DER, 10 FT RIGHT OF CENTERLINE, UP TO 64 FT AGL/144 FT
MSL.
BUILDINGS, TREES, POLES BEGINNING 667 FT FROM DER, 288 FT LEFT OF
CENTERLINE, UP TO 33 FT AGL/112 FT MSL.
TREE 915 FT FROM DER, 710 FT LEFT OF CENTERLINE, 54 FT AGL/140 FT
MSL.
TREES, POLES, TANK, UTILITY BUILDINGS, ELEVATOR BEGINNING 933 FT
FROM DER, 73 FT LEFT OF CENTERLINE, UP TO 56 FT AGL/142 FT MSL.
TREES BEGINNING 2024 FT FROM DER, 43 FT LEFT OF CENTERLINE, UP TO
59 FT AGL/145 FT MSL.
TERRAIN, WATER TOWER, TANK BEGINNING 4390 FT FROM DER, 1432 FT LEFT
OF CENTERLINE, UP TO 200 FT AGL/296 FT MSL.
TERRAIN BEGINNING 4948 FT FROM DER, 1798 FT RIGHT OF CENTERLINE, UP
TO 305 FT MSL.
NOTE: RWY 14: SIGN, LIGHT POLES BEGINNING 12 FT FROM DER, 115 FT
LEFT OF CENTERLINE, UP TO 3 FT AGL/63 FT MSL.
LIGHT POLES, TERRAIN BEGINNING 30 FT FROM DER, ON CENTERLINE, UP TO
4 FT AGL/63 FT MSL.
TRAVERSE WAYS, FENCE BEGINNING 115 FT FROM DER, 501 FT LEFT OF
CENTERLINE, UP TO 74 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2311281451-2511281451EST
END PART 2 OF 6
!FDC 3/6253 FRG PART 3 OF 6 ODP REPUBLIC, FARMINGDALE, NY.
TRAVERSE WAYS, TREES, POLES, SIGN, TERRAIN BEGINNING 44 FT FROM
DER, 204 FT RIGHT OF CENTERLINE, UP TO 73 FT AGL/246 FT MSL.
TREES, TRAVERSE WAY, POLES, TERRAIN BEGINNING 440 FT FROM DER, 7 FT
LEFT OF CENTERLINE, UP TO UP TO 100 FT MSL/243 FT MSL.
NOTE: RWY 19: FENCE 15 FT FROM DER, 451 FT LEFT OF CENTERLINE, 7 FT
AGL/68 FT MSL.
WALL, LIGHT POLES, POLE, FENCE BEGINNING 22 FT FROM DER, 115 FT
LEFT OF CENTERLINE, UP TO 13 FT AGL/74 FT MSL.
SIGN, LIGHT POLES BEGINNING 26 FT FROM DER, 115 FT RIGHT OF
CENTERLINE, UP TO 2 FT AGL/65 FT MSL.
SIGN 158 FT FROM DER, 520 FT RIGHT OF CENTERLINE, 19 FT AGL/82 FT
MSL.
TREES, WALLS, POLES BEGINNING 180 FT FROM DER, 489 FT LEFT OF
CENTERLINE, UP TO 42 FT AGL/100 FT MSL.
SIGN, BUILDINGS BEGINNING 489 FT FROM DER, 401 FT RIGHT OF
CENTERLINE, UP TO 43 FT AGL/102 FT MSL.
TREE 766 FT FROM DER, 520 FT LEFT OF CENTERLINE, 46 FT AGL/106 FT
MSL.
TREES BEGINNING 776 FT FROM DER, 610 FT LEFT OF CENTERLINE, UP TO
48 FT AGL/108 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2311281451-2511281451EST
END PART 3 OF 6
!FDC 3/6253 FRG PART 4 OF 6 ODP REPUBLIC, FARMINGDALE, NY.
POLES, TREES BEGINNING 792 FT FROM DER, 207 FT RIGHT OF CENTERLINE,
UP TO 49 FT AGL/111 FT MSL.
TREES BEGINNING 818 FT FROM DER, 509 FT LEFT OF CENTERLINE, UP TO
54 FT AGL/113 FT MSL.
TREES, POLES, ELECTRICAL SYSTEMS BEGINNING 1149 FT FROM DER, 62 FT
LEFT OF CENTERLINE, UP TO 58 FT AGL/116 FT MSL.
POLES BEGINNING 1220 FT FROM DER, 49 FT RIGHT OF CENTERLINE, UP TO
53 FT AGL/113 FT MSL.
POLES, TREES, ELECTRICAL SYSTEM BEGINNING 1290 FT FROM DER, 193 FT
RIGHT OF CENTERLINE, UP TO 56 FT AGL/115 FT MSL.
TREE 1448 FT FROM DER, 877 FT RIGHT OF CENTERLINE, 59 FT AGL/117 FT
MSL.
TREES, ELECTRICAL SYSTEM, POLE BEGINNING 1449 FT FROM DER, 5 FT
RIGHT OF CENTERLINE, UP TO 63 FT AGL/119 FT MSL.
TREES BEGINNING 1636 FT FROM DER, 88 FT RIGHT OF CENTERLINE, UP TO
66 FT AGL/122 FT MSL.
TREES, POLES, TERRAIN BEGINNING 1649 FT FROM DER, 553 FT LEFT OF
CENTERLINE, UP TO 71 FT AGL/250 FT MSL.
TOWER, TERRAIN BEGINNING 2865 FT FROM DER, 317 FT RIGHT OF
CENTERLINE, UP TO 84 FT AGL/246 MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2311281451-2511281451EST
END PART 4 OF 6
!FDC 3/6253 FRG PART 5 OF 6 ODP REPUBLIC, FARMINGDALE, NY.
NOTE: RWY 32: SIGN 12 FT FROM DER, 401 FT LEFT OF CENTERLINE, 4 FT
AGL/79 FT MSL.
SIGN 17 FT FROM DER, 240 FT LEFT OF CENTERLINE, 5 FT AGL/80 FT MSL.
POLE, VEGETATION BEGINNING 20 FT FROM DER, 242 FT RIGHT OF
CENTERLINE, UP TO 11 FT AGL/84 FT MSL.
TRAVERSE WAY, TREE, POLES, VEGETATION, LIGHT POLES, FENCE BEGINNING
32 FT FROM DER, ON CENTERLINE, UP TO 89 FT MSL.
FENCES BEGINNING 91 FT FROM DER, 474 FT LEFT OF CENTERLINE, UP TO 7
FT AGL/83 FT MSL.
TRAVERSE WAYS, FENCES BEGINNING 140 FT FROM DER, 343 FT LEFT OF
CENTERLINE, UP TO 93 FT MSL.
VEGETATION, TRAVERSE WAY BEGINNING 183 FT FROM DER, 254 FT RIGHT OF
CENTERLINE, UP TO 18 FT AGL/91 FT MSL.
TREES, VEGETATION, POLES, LIGHT POLES, TRAVERSE WAYS, SIGN
BEGINNING 236 FT FROM DER, ON CENTERLINE, UP TO 43 FT AGL/119 FT
MSL.
TRAVERSE WAYS, SIGNS, POLE, TREE, LIGHT POLES BEGINNING 243 FT FROM
DER, 27 FT LEFT OF CENTERLINE, UP TO 95 FT MSL.
POLES, TRAVERSE WAYS, TREES, BUILDINGS BEGINNING 329 FT FROM DER, 1
FT LEFT OF CENTERLINE, UP TO 30 FT AGL/103 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2311281451-2511281451EST
END PART 5 OF 6
!FDC 3/6253 FRG PART 6 OF 6 ODP REPUBLIC, FARMINGDALE, NY.
TREES, BUILDING BEGINNING 599 FT FROM DER, 209 FT LEFT OF
CENTERLINE, UP TO 38 FT AGL/104 FT MSL.
TREES, BUILDING BEGINNING 705 FT FROM DER, 26 FT LEFT OF
CENTERLINE, UP TO 52 FT AGL/118 FT MSL.
TREES, POLES, TERRAIN BEGINNING 1086 FT FROM DER, 19 FT RIGHT OF
CENTERLINE, UP TO 60 FT AGL/378 FT MSL.
TREES, POLES, BUILDINGS, TERRAIN BEGINNING 1154 FT FROM DER, 10 FT
LEFT OF CENTERLINE, UP TO 106 FT AGL/338 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2311281451-2511281451EST
END PART 6 OF 6
|
