KFNL
NORTHERN COLORADO RGNL
PublicPUB

9 miles SE of FORT COLLINS/LOVELAND, CO
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
40° 27' 07"N 105° 00' 41"W
5020' MSL
6020' MSL
09E
JET A, 100LL
DENVER (DEN)
CHEYENNE
DENVER (ZDV)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

KFNL FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 118.4

ATIS

ATIS
970-669-9187
 135.075

AWOS-3PT

AWOS-3PT
970-669-9187
 135.075

Ground

GND/P
 121.65

Tower

LCL/P
 118.4

Terminal Area Forecast

No TAF is available for this location.
KFNL
Domestic
1/15/251500Z !FNL 01/027 FNL NAV ILS RWY 33 U/S 2501151500-2501151800
12/29/240646Z !FNL 12/011 FNL OBST TOWER LGT (ASR 1024111) 404050.00N1045634.00W (14.1NM NNE FNL) 6000.0FT (647.0FT AGL) U/S 2412290646-2502120645
12/11/241557Z !FNL 12/004 FNL OBST CRANE (ASN 2023-ANM-5194-OE) 402502N1045950W (2.2NM SSE FNL) 5272FT (300FT AGL) LGTD 2412111557-2503140100
11/3/241500Z !FNL 11/003 FNL RWY 15 RIGHT TFC PATTERN DLY 1500-0100 2411031500-2503020100
11/3/241500Z !FNL 11/002 FNL RWY 06/24 CLSD EXC TAX DLY 1500-0100 2411031500-2503090100
FDC
1/15/251700Z !FDC 5/3357 FNL SID NORTHERN COLORADO RGNL, FORT COLLINS/LOVELAND, CO.
ROCKIES SIX DEPARTURE...
RED TABLE TRANSITION NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS.
DOVE CREEK TRANSITION,MONTROSE TRANSITION DME REQUIRED EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
DBL VOR/DME OUT OF SERVICE. 2501151700-2501221711EST
1/13/251900Z !FDC 5/2662 FNL SID NORTHERN COLORADO RGNL, FORT COLLINS/LOVELAND, CO.
PLAINS ONE DEPARTURE...
CABET TRANSITION DME REQUIRED EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS.
GOODLAND TRANSITION NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
GLD VORTAC OUT OF SERVICE. 2501131900-2501202300EST
1/4/251419Z !FDC 5/0434 FNL SID NORTHERN COLORADO RGNL, FORT COLLINS/LOVELAND, CO.
PLAINS ONE DEPARTURE...
GARDEN CITY TRANSITION NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
GCK VOR OUT OF SERVICE. 2501041419-2502041419EST
12/30/242055Z !FDC 4/1987 FNL IAP NORTHERN COLORADO RGNL, FORT COLLINS/LOVELAND, CO.
RNAV (GPS) RWY 33, AMDT 2...
LNAV/VNAV DA 5640/HAT 620 ALL CATS, VIS 1 3/8 ALL CATS. LNAV MDA 5740/HAT 720 ALL CATS, VIS CAT C/D 1 5/8. CIRCLING MDA 5740/HAA 720 ALL CATS, VIS CAT C 2. DISREGARD STEPDOWN FIX JUDET AND ALTITUDE 5620. FOR INOP ALS, INCREASE LNAV/VNAV ALL CATS VISIBILITY TO 1 3/4 SM AND LNAV VISIBILITY CAT C/D TO 2 SM. TEMPORARY CRANE 5272 MSL 1.5NM S OF RWY 33 (2023-ANM-5194-OE). TEMPORARY CRANE 5205FT MSL 3822FT NE OF RWY 33 (2023-ANM-2831-NRA). TEMPORARY CRANE 5132FT MSL 1.10NM SOUTH OF RWY 33 (2024-ANM-7591-OE).
2412302055-2508112053EST
11/25/242122Z !FDC 4/8826 FNL IAP NORTHERN COLORADO RGNL, FORT COLLINS/LOVELAND, CO.
ILS OR LOC RWY 33, AMDT 7...
S-LOC 33 MDA 5580/HAT 560 ALL CATS, VIS CAT C/D 1 1/8. CIRCLING CAT A MDA 5580/HAA 560. CIRCLING CAT B/C MDA 5640/HAA 620, VIS CAT C 1 3/4. VDP AT 20.91 DME DISTANCE VDP TO THLD 1.34 NM. TEMPORARY CRANE 5272 MSL 1.5NM S OF RWY 33 (2023-ANM-5194-OE). TEMPORARY CRANE 5205FT MSL 3822FT NE OF RWY 33 (2023-ANM-2831-NRA).
2411252122-2503252122EST
11/25/242122Z !FDC 4/8822 FNL IAP NORTHERN COLORADO RGNL, FORT COLLINS/LOVELAND, CO.
VOR -A, AMDT 7C...
CIRCLING CAT A MDA 5580/HAA 560, CIRCLING CAT B/C MDA 5640/HAA 620, VIS CAT C 1 3/4. WHEN LOCAL ALTIMETER SETTING NOT RECEIVED, USE DENVER INTL ALTIMETER SETTING AND INCREASE ALL MDAS 160 FEET AND VISIBILITY CAT C/D 3/4 SM. TEMPORARY CRANE 5272 MSL 2.1NM SE OF FNL AIRPORT (2023-ANM-5194-OE). TEMPORARY CRANE 5205FT MSL 3822FT NE OF RWY 33 (2023-ANM-2831-NRA).
2411252122-2503252122EST
11/25/242118Z !FDC 4/8820 FNL ODP NORTHERN COLORADO RGNL, FORT COLLINS/LOVELAND, CO.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 5A...
TAKE-OFF MINIMUMS: RWY 15, 300-1 3/4 OR STANDARD WITH MINIMUM CLIMB OF 281FT PER NM TO 5500, EXCEPT WHEN ADVISED BY ATCT THAT THIS CRANE IS DOWN. TEMPORARY CRANE 5272 MSL 1.5NM S OF RWY 33 (2023-ANM-5194-OE). ALL OTHER DATA REMAINS AS PUBLISHED. 2411252118-2503252118EST
11/25/242118Z !FDC 4/8818 FNL SID NORTHERN COLORADO RGNL, FORT COLLINS/LOVELAND, CO.
DENVER TWO DEPARTURE...
ECHOO ONE DEPARTURE (RNAV)...
MRSHH TWO DEPARTURE (RNAV)...
PIKES TWO DEPARTURE...
PLAINS ONE DEPARTURE...
ROCKIES SIX DEPARTURE...
SKYEE ONE DEPARTURE (RNAV)...
WNGSS ONE DEPARTURE (RNAV)...
YELLOWSTONE FOUR DEPARTURE...
TAKE-OFF MINIMUMS: RWY 15, 300-1 3/4 OR STANDARD WITH MINIMUM CLIMB OF 281FT PER NM TO 5500, EXCEPT WHEN ADVISED BY ATCT THAT THIS CRANE IS DOWN. TEMPORARY CRANE 5272 MSL 1.5NM S OF RWY 33 (2023-ANM-5194-OE). ALL OTHER DATA REMAINS AS PUBLISHED. 2411252118-2503252118EST
6/18/241324Z !FDC 4/0434 FNL SID NORTHERN COLORADO RGNL, FORT COLLINS/LOVELAND, CO.
ROCKIES SIX DEPARTURE...
DOVE CREEK TRANSITION AND MONTROSE TRANSITION NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
MTJ VOR/DME OUT OF SERVICE.
2406181324-2501281324EST
Yes
ALL
SVC - 130.575 OR 970-667-2574.
FORT COLLINS & LOVELAND
4900 EARHART ROAD
LOVELAND, CO 80538
Phone: 970-962-2850
DAVID RUPPEL
4900 EARHART ROAD
LOVELAND, CO 80538
Phone: 970-962-2852
DENVER FSS (DEN)
Toll Free: 1-800-WX-BRIEF
FNL
--
DUSK-DAWN: ACTVT MALSR RWY 33; REIL RWY 15; PAPI RWY 33; HIRL RWY 15/33; TWY LGTS - CTAF. PAPI RWY 15 ON CONSLY.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
None
High & Low Pressure
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales
Annual Surveying

Runway 06/24

2189 ft. x 40 ft.
ASPH
Good
NONE


--
--
--
--
  Runway 06 Runway 24
True Heading 71°251°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 40° 27' 10"N 40° 27' 18"N
Longitude 105° 00' 41"W 105° 00' 14"W
Elevation 4,993' 4,991'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights No No

Runway 15/33

8500 ft. x 100 ft.
ASPH
Good
GRVD
HIGH
49 /F/C/W/T
50,000lbs
65,000lbs
130,000lbs
--
  Runway 15 Runway 33
True Heading 160°340°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 40° 27' 44"N 40° 26' 25"N
Longitude 105° 01' 03"W 105° 00' 26"W
Elevation 4,977' 5,020'
Threshold Crossing Height 54 ft. AGL 52 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSR
Centerline Lights
Runway End Identifier Lights Yes No
A110-4RSCD UNMON 0500-1300Z++
A110-6FOR CD CTC DENVER APCH AT 303-342-1916.
A110-7RWY 24 THLD NOT VISIBLE BY TWR.
NORTHERN COLORADO RGNL (ICAO: KFNL, IATA: FNL) is a public airport located in FORT COLLINS/LOVELAND, CO.
