KEWR
NEWARK LIBERTY INTL
PublicPUB

3 miles S of NEWARK, NJ
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
40° 41' 33"N 74° 10' 07"W
18' MSL
1018' MSL
13W
JET A, 100LL
NEW YORK (ISP)
NEW YORK
NEW YORK (ZNY)
4/17/25-5/15/25
KEWR VFR
3:51 AM EST
Broken 12,000'
Few 7,500'
10sm
43°F
21°F
29.88"Hg
250° 10kts
AO2 PK WND 27028/0753 SLP116 T00611061 51017 $
METAR KEWR 270851Z 25010KT 10SM FEW075 BKN120 06/M06 A2988 RMK AO2 PK WND 27028/0753 SLP116 T00611061 51017 $
+ Add Your Business

KEWR FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Terminal Area Forecast

KEWR
Thu, 11/27 3:30 AM EST
Thu, 11/27 3:00 AM EST - Fri, 11/28 7:00 AM EST
VFR
3:00 AM EST - 11:00 AM EST
Scattered 5,000'
6sm
270° 14kts
Gusts 23kts
VFR
11:00 AM EST - 5:00 PM EST
Broken 5,000'
6sm
270° 17kts
Gusts 29kts
VFR
5:00 PM EST - 10:00 PM EST
Scattered 15,000'
Few 5,000'
6sm
260° 15kts
Gusts 22kts
VFR
10:00 PM EST - 7:00 AM EST
Scattered 5,000'
6sm
250° 11kts
Gusts 16kts
TAF KEWR 270830Z 2708/2812 27014G23KT P6SM SCT050
   FM271600 27017G29KT P6SM BKN050
   FM272200 26015G22KT P6SM FEW050 SCT150
   FM280300 25011G16KT P6SM SCT050
KEWR
EffectiveExpiresCategoryNOTAM
Domestic
11/26/25
0145Z
11/26/25
1400Z
!EWR 11/348 EWR APRON TERMINAL A RAMP TXL A12 WEST OF TXL F3 CLSD 2511260145-2511261400
11/25/25
2053Z
12/5/25
2359Z
!EWR 11/345 EWR TWY G, E, C, N, V, CC RWY ENTRANCE LGT FOR RWY 04L/22R U/S 2511252053-2512052359
11/25/25
1335Z
12/31/25
2000Z
!EWR 11/341 EWR TWY F CLSD 2511251335-2512312000
11/22/25
0452Z
!EWR 11/301 EWR NAV ILS RWY 11 LOC/GP/DME U/S 2511220452-2512022359EST
11/21/25
1621Z
1/31/26
2300Z
Runway!EWR 11/292 EWR RWY 22R RWY END ID LGT NOT STD 2511211621-2601312300
11/16/25
1526Z
12/31/25
2359Z
!EWR 11/244 EWR TWY BB SHOULDER MARKINGS BTN RWY 04L/22R AND TWY B WEST SIDE REMOVED 2511161526-2512312359
11/16/25
1525Z
12/31/25
2359Z
!EWR 11/243 EWR TWY L SHOULDER MARKINGS BTN RWY 04L/22R AND TWY R WEST SIDE REMOVED 2511161525-2512312359
11/16/25
1524Z
12/31/25
2359Z
!EWR 11/242 EWR TWY M SHOULDER MARKINGS BTN RWY 04L/22R AND TWY R WEST SIDE REMOVED 2511161524-2512312359
11/16/25
1521Z
12/31/25
2359Z
!EWR 11/241 EWR TWY C SHOULDER MARKINGS BTN RWY 04L/22R AND TWY B WEST SIDE REMOVED 2511161521-2512312359
11/16/25
1521Z
12/31/25
2359Z
!EWR 11/240 EWR TWY V SHOULDER MARKINGS BTN RWY 04L/22R AND TWY B WEST SIDE REMOVED 2511161521-2512312359
11/12/25
1649Z
5/12/26
2359Z
!EWR 11/203 EWR TWY A8 HLDG PSN MARKINGS BTN TWY A AND TERMINAL A RAMP NOT STD 2511121649-2605122359
11/9/25
0723Z
6/30/26
1000Z
!EWR 11/164 EWR TWY L, M, Y SHOULDER MARKINGS AT RWY 04L/22R WEST SIDE NOT STD 2511090723-2606301000
11/2/25
0838Z
5/29/26
2359Z
!EWR 11/024 EWR TWY C TWY DIRECTION SIGN WEST SIDE FOR RWY 04L/22R LGT U/S 2511020838-2605292359
11/2/25
0837Z
5/29/26
2359Z
!EWR 11/023 EWR TWY N HLDG PSN SIGN NORTHWEST SIDE FOR RWY 04L/22R LGT U/S 2511020837-2605292359
11/2/25
0835Z
5/30/26
2359Z
!EWR 11/022 EWR TWY N TWY DIRECTION SIGN WEST SIDE FOR RWY 04L/22R LGT U/S 2511020835-2605302359
11/2/25
0353Z
5/29/26
2359Z
!EWR 11/021 EWR TWY CC SHOULDER MARKINGS SOUTHWEST SIDE NOT STD 2511020353-2605292359
11/2/25
0352Z
5/29/26
2359Z
!EWR 11/020 EWR TWY BB SHOULDER MARKINGS NORTHWEST SIDE NOT STD 2511020352-2605292359
11/2/25
0347Z
5/30/26
2359Z
!EWR 11/019 EWR TWY P EDGE MARKINGS BTN TWY V AND TWY CC WEST SIDE REMOVED 2511020347-2605302359
10/23/25
1642Z
12/31/25
2300Z
!EWR 10/326 EWR TWY A LOCATION SIGN BTN TWY RN AND TWY RG MISSING 2510231642-2512312300
10/23/25
1639Z
12/31/25
2300Z
!EWR 10/325 EWR TWY RG RWY LOCATION SIGN BTN TWY A AND TERMINAL C RAMP MISSING 2510231639-2512312300
10/23/25
1636Z
12/31/25
2300Z
!EWR 10/324 EWR TWY RG TWY DIRECTION SIGN BTN TWY A AND TERMINAL C RAMP MISSING 2510231636-2512312300
10/23/25
1629Z
12/31/25
2300Z
!EWR 10/322 EWR TWY A LOCATION SIGN BTN TWY RG AND TERMINAL C RAMP MISSING 2510231629-2512312300
10/18/25
1733Z
12/31/25
2359Z
!EWR 10/246 EWR TWY BB SHOULDER MARKINGS BTN TWY B AND RWY 04L/22R REMOVED 2510181733-2512312359
10/18/25
1731Z
12/31/25
2359Z
!EWR 10/245 EWR TWY CC BTN TWY B AND RWY 04L/22R SOUTH EDGE IRREGULAR SFC 2510181731-2512312359
10/18/25
1729Z
12/31/25
2359Z
!EWR 10/244 EWR TWY CC EDGE MARKINGS BTN TWY B AND RWY 04L/22R SOUTH SIDE REMOVED 2510181729-2512312359
10/18/25
1727Z
12/31/25
2359Z
!EWR 10/243 EWR TWY BB BTN TWY B AND RWY 04L/22R IRREGULAR SFC 2510181727-2512312359
10/18/25
1725Z
12/31/25
2359Z
!EWR 10/242 EWR TWY AA SHOULDER MARKINGS BTN TWY B AND APCH END RWY 04L NOT MARKED 2510181725-2512312359
10/18/25
1721Z
12/31/25
2359Z
!EWR 10/241 EWR TWY BB HLDG PSN SIGN SOUTH SIDE BTN TWY B AND RWY 04L/22R MISSING 2510181721-2512312359
10/18/25
1719Z
12/31/25
2359Z
!EWR 10/240 EWR TWY BB HLDG PSN MARKINGS BTN RWY 04L/22R AND TWY B NOT STD 2510181719-2512312359
10/16/25
1333Z
4/16/26
2359Z
!EWR 10/206 EWR TWY CC CL MARKINGS BTN TWY A AND TWY B NOT STD 2510161333-2604162359
10/8/25
1738Z
10/8/26
2359Z
!EWR 10/099 EWR TWY Z HLDG PSN MARKINGS FOR ILS BTN TWY S AND TWY Z5 REMOVED 2510081738-2610082359
10/8/25
1100Z
12/17/27
1100Z
!EWR 10/075 EWR OBST RIG (ASN 2025-AEA-2303-OE) 404215N0740905W (1.1NM NE EWR) 165FT (157FT AGL) FLAGGED AND LGTD 2510081100-2712171100
10/8/25
1100Z
12/11/25
2000Z
!EWR 10/074 EWR OBST CRANE (ASN 2024-AEA-4028-OE) 404207N0741129W (1.2NM WNW EWR) 87FT (76FT AGL) FLAGGED AND LGTD 2510081100-2512112000
10/7/25
1246Z
12/17/27
1100Z
!EWR 10/076 EWR OBST CRANE (ASN 2025-AEA-2348-OE) 404211N0740905W (1.0NM NE EWR) 126FT (117FT AGL) FLAGGED AND LGTD 2510071246-2712171100
10/5/25
1314Z
1/30/26
1800Z
!EWR 10/043 EWR NAV GBAS STS NOT MNT 2510051314-2601301800
10/2/25
1726Z
11/30/25
2359Z
!EWR 10/018 EWR AD AP BIRD ACT INCREASED MIGRATORY 2510021726-2511302359
9/21/25
0857Z
12/31/25
2359Z
Runway!EWR 09/369 EWR RWY 22R CL LGT U/S 2509210857-2512312359
9/21/25
0857Z
12/31/25
2359Z
Runway!EWR 09/368 EWR RWY 04L CL LGT U/S 2509210857-2512312359
7/25/25
1905Z
7/31/26
2359Z
!EWR 07/322 EWR AIRSPACE UAS WI AN AREA DEFINED AS 2NM RADIUS OF 404000N0741232W (2NM SW EWR) SFC-200FT AGL 2507251905-2607312359
7/25/25
1000Z
10/16/26
2100Z
!EWR 07/303 EWR OBST RIG (ASN 2025-AEA-1955-NRA) 404216N0741129W (1.2NM NW EWR) 116FT (100FT AGL) FLAGGED AND LGTD 2507251000-2610162100
7/14/25
1243Z
1/14/26
2359Z
!EWR 07/190 EWR OBST BLDG LGT (ASN 2022-AEA-17053-OE) 404406N0741034W (2.6NM N EWR) 472FT (445FT AGL) U/S 2507141243-2601142359
7/14/25
1243Z
1/14/26
2359Z
!EWR 07/189 EWR OBST BLDG LGT (ASN 2022-AEA-17052-OE) 404406N0741034W (2.6NM N EWR) 472FT (445FT AGL) U/S 2507141243-2601142359
7/14/25
1242Z
1/14/26
2359Z
!EWR 07/188 EWR OBST BLDG LGT (ASN 2022-AEA-17051-OE) 404406N0741034W (2.6NM N EWR) 494FT (467FT AGL) U/S 2507141242-2601142359
7/14/25
1242Z
1/14/26
2359Z
!EWR 07/187 EWR OBST BLDG LGT (ASN 2022-AEA-17050-OE) 404407N0741035W (2.6NM N EWR) 452FT (425FT AGL) U/S 2507141242-2601142359
7/14/25
1241Z
1/14/26
2359Z
!EWR 07/186 EWR OBST BLDG LGT (ASN 2022-AEA-17049-OE) 404407N0741035W (2.6NM N EWR) 452FT (425FT AGL) U/S 2507141241-2601142359
6/2/25
0142Z
12/31/25
2359Z
!EWR 06/040 EWR TWY AA IN PAVEMENT RWY GUARD LGT BTN TWY B AND TWY P U/S 2506020142-2512312359
6/2/25
0136Z
12/31/25
2359Z
!EWR 06/038 EWR TWY V CL LGT U/S 2506020136-2512312359
6/2/25
0117Z
12/31/25
2359Z
!EWR 06/035 EWR TWY BB CL LGT BTN TWY B AND TWY P U/S 2506020117-2512312359
FDC
11/25/25
1503Z
!FDC 5/1486 EWR SID NEWARK LIBERTY INTL, NEWARK, NJ.
DEVIL ONE DEPARTURE...
NEWARK FIVE DEPARTURE...
DIXIE TRANSITION, WHITE TRANSITION: NOTE: FIX NECCK AND COL VOR/DME ARE COLLOCATED AND EITHER CAN BE UTILIZED.
ALL OTHER DATA REMAINS AS PUBLISHED. 2511251503-2711251503EST
11/24/25
1738Z
!FDC 5/1111 EWR SID NEWARK LIBERTY INTL, NEWARK, NJ.
PORTT FOUR DEPARTURE (RNAV)...
ELIOT TRANSITION: FENLY TO ELIOT MOCA 2700.
ALL OTHER DATA REMAINS AS PUBLISHED. 2511241738-2711241738EST
9/8/25
1353Z
!FDC 5/9348 EWR SID NEWARK LIBERTY INTL, NEWARK, NJ.
NEWARK FIVE DEPARTURE...
NOTE: PARKE DEPARTURE VIA BWZ R-250 NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
BWZ VOR/DME OUT OF SERVICE. 2509081353-2604201353EST
9/4/25
1347Z
!FDC 5/8085 EWR IAP NEWARK LIBERTY INTL, NEWARK, NJ.
ILS OR LOC RWY 22L, AMDT 14...
ILS RWY 22L (SA CAT I), AMDT 14 ...
ILS RWY 22L ( CAT II AND III), AMDT 14...
MISSED APPROACH: CLIMB TO 500 THEN CLIMBING RIGHT TURN TO 3000 ON HEADING 225 AND JFK VOR/DME R-265 TO KILMA INT/JFK 30.17 DME AND HOLD,
ARD VOR OUT OF SERVICE. 2509041347-2604161347EST
9/4/25
1347Z
!FDC 5/8084 EWR IAP NEWARK LIBERTY INTL, NEWARK, NJ.
ILS OR LOC RWY 22R, AMDT 7...
MISSED APPROACH: CLIMB TO 3000 ON HEADING 219 AND JFK VOR/DME R-265 TO KILMA INT/JFK 30.17 DME AND HOLD,
ARD VOR OUT OF SERVICE. 2509041347-2604161347EST
9/4/25
1347Z
4/16/26
1347Z
!FDC 5/8079 EWR IAP NEWARK LIBERTY INTL, Newark, NJ.
COPTER ILS/DME RWY 22L, ORIG-D...
PROCEDURE NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
ARD VOR OUT OF SERVICE. 2509041347-2604161347EST
8/1/25
1418Z
!FDC 5/9417 EWR IAP NEWARK LIBERTY INTL, NEWARK, NJ.
ILS OR LOC RWY 22R, AMDT 7...
S-LOC 22R: MDA 520/HAT 510 ALL CATS. VIS CATS A/B RVR 2400, VIS CATS C/D RVR 5500.
2508011418-2708011418EST
7/11/25
1513Z
!FDC 5/6935 EWR SID NEWARK LIBERTY INTL, NEWARK, NJ.
NEWARK FIVE DEPARTURE...
COATE, NEWEL DEPARTURES: NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS.
DEPARTING RWY 4L/R: ELIOT AND ZIMMZ DEPARTURES: NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS, SAX VORTAC OUT OF SERVICE. 2507111513-2602201513EST
7/11/25
1513Z
2/20/26
1513Z
!FDC 5/6934 EWR SID NEWARK LIBERTY INTL, NEWARK, NJ.
LIBERTY FIVE DEPARTURE...
COATE, ELIOT, ZIMMZ, NEWEL DEPARTURES: NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS, SAX VORTAC OUT OF SERVICE. 2507111513-2602201513EST
6/12/25
1853Z
!FDC 5/3556 EWR IAP NEWARK LIBERTY INTL, NEWARK, NJ.
COPTER ILS Y OR LOC Y RWY 4L, AMDT 2...
MISSED APPROACH: CLIMB TO 520, THEN CLIMBING RIGHT TURN TO 2000 DIRECT TYNIE AND ON TRACK 015 TO NEBTE, CROSS NEBTE AT OR BELOW 2000, THEN CLIMBING LEFT TURN TO 3000 ON TRACK 313 TO FLYRS AND HOLD.
2506121853-2706151853EST
6/12/25
1842Z
!FDC 5/3550 EWR IAP NEWARK LIBERTY INTL, NEWARK, NJ.
RNAV (RNP) Z RWY 4R, AMDT 1 ...
ALTERNATE MINIMUMS NA 2506121842-2706151842EST
6/12/25
1806Z
!FDC 5/3513 EWR IAP NEWARK LIBERTY INTL, NEWARK, NJ.
ILS OR LOC RWY 11, AMDT 3...
NOTE: AUTOPILOT COUPLED APPROACH NA BELOW 350FT.
DISREGARD PROFILE NOTE: VGSI AND ILS GLIDEPATH NOT COINCIDENT (VGSI ANGLE 3.08/TCH 58).
2506121806-2706151805EST
6/4/25
1452Z
1/14/26
1452Z
!FDC 5/8778 EWR IAP NEWARK LIBERTY INTL, NEWARK, NJ.
GLS RWY 22L, AMDT 1A...
GLS RWY 22R, AMDT 2...
ILS OR LOC RWY 22L, AMDT 14...
ILS OR LOC RWY 22R, AMDT 7...
RNAV (GPS) RWY 22R, AMDT 2...
RNAV (GPS) W RWY 29, ORIG-A...
RNAV (GPS) Z RWY 22L, AMDT 3...
RNAV (RNP) Y RWY 22L, AMDT 1A...
RNAV (RNP) Y RWY 29, AMDT 1E...
STADIUM VISUAL RWY 29, AMDT 3...
ILS RWY 22L (SA CAT I), AMDT 14...
ILS RWY 22L (CAT II-III), AMDT 14...
NOTE: CAUTION, DEPARTING TEB RWY 24 TRAFFIC CLIMBING TO 1500' MSL.
2506041452-2601141452EST
5/9/25
1303Z
!FDC 5/8290 EWR IAP NEWARK LIBERTY INTL, NEWARK, NJ.
RNAV (GPS) RWY 4L, AMDT 3...
LNAV/VNAV CAT D DA 555/HAT 545. VISIBILITY CAT D 1 1/8.
LNAV MDA 740/HAT 730 ALL CATS. VISIBILITY CAT C/D 1 5/8. VDP 1.97NM TO RW4L.
PERMANENT CRANE 428FT MSL 2.73 NM SOUTH OF RWY 4R (34-082748 (4D)). PERMANENT CRANE 428FT MSL 1.32 NM SOUTHEAST OF RWY 4R (34-081539 (4D)).
2505091303-2705091303EST
5/7/25
1244Z
!FDC 5/7069 EWR IAP NEWARK LIBERTY INTL, NEWARK, NJ.
COPTER ILS Y OR LOC Y RWY 4L, AMDT 2...
H-LOC 4L MDA 740/HAT 730. VDP AT I-EWR 3.52 DME; DISTANCE VDP TO THLD 1.97 NM.
PERMANENT CRANE 428FT MSL 2.34 NM SOUTHWEST OF RWY 4L (34-082748).
2505071244-2705071244EST
5/7/25
1243Z
!FDC 5/7066 EWR IAP NEWARK LIBERTY INTL, NEWARK, NJ.
ILS OR LOC RWY 4R, AMDT 14...
S-LOC 4R MDA 740/HAT 729 ALL CATS. VISIBILITY CAT C/D 1 5/8.
SIDESTEP RWY 4L MDA 740/HAT 730 ALL CATS. VISIBILITY CAT C 1 5/8, CAT D 1 3/4.
VDP AT I-EZA 3.11 DME; DISTANCE VDP TO THLD 2.09 NM.
FOR INOPERATIVE ALS, INCREASE S-LOC 4R CAT C/D TO 2 SM, INCREASE SIDESTEP 4L CAT C TO 2 SM.
PERM CRANE 428FT MSL 2.73 NM SOUTH OF RWY 4R (34-082748).
2505071243-2705071243EST
4/28/25
1313Z
!FDC 5/2169 EWR IAP NEWARK LIBERTY INTL, NEWARK, NJ.
RNAV (GPS) Y RWY 4R, AMDT 2...
LNAV MDA 740/HAT 729 ALL CATS. VISIBILITY CAT C/D 1 5/8. VDP 2.09NM TO RW4R. PERMANENT CRANE 428FT MSL 2.73 NM SOUTH OF RWY 4R (34-082748 (4D)).
2504281313-2704271313EST
4/28/25
1308Z
!FDC 5/2166 EWR IAP NEWARK LIBERTY INTL, NEWARK, NJ.
ILS Z OR LOC Z RWY 4L, AMDT 16...
S-LOC 4L MDA 740/HAT 730 ALL CATS. VISIBILITY CAT C/D 1 5/8. SIDESTEP 4R MDA 740/HAT 729 ALL CATS. VISIBILITY CAT C 1 5/8, CAT D 1 3/4. VDP AT I-EWR 3.52 DME; DISTANCE VDP TO THLD 1.97NM. FOR INOPERATIVE ALS, INCREASE S-LOC 4L CAT C/D TO 2 SM, INCREASE SIDESTEP 4R CAT C TO 2 SM. PERMANENT CRANE 428FT MSL 2.34NM SOUTHWEST OF RWY 4L (34-082748).
2504281308-2704271308EST
3/12/25
1819Z
!FDC 5/2311 EWR IAP NEWARK LIBERTY INTL, NEWARK, NJ.
RNAV (RNP) Z RWY 29, ORIG-G...
RNP 0.30 DA 630/HAT 620 ALL CATS. *RNP 0.30 DA 589/HAT 579 ALL CATS. *RNP 0.30 VISIBIITY ALL CATS 1 5/8. *MISSED APPROACH REQUIRES MINIMUM CLIMB OF 340 FEET PER NM TO 800. PERM CRANE (34-000846) 439FT MSL (4A) 404104.88N/0740905.09W. PERM CRANE (34-083039) 242FT MSL (4D) 404123.55N/0740811.43W.
2503121819-2703111814EST
3/11/25
1943Z
!FDC 5/1803 EWR IAP NEWARK LIBERTY INTL, NEWARK, NJ.
RNAV (RNP) Y RWY 29, AMDT 1E...
RNP 0.30 DA 625/HAT 615 ALL CATS. **RNP 0.30 DA 583/HAT 573 ALL CATS. **MISSED APPROACH REQUIRES MINIMUM CLIMB OF 417 FEET PER NM TO 800. PERM CRANE (34-082940) 428FT MSL (4A) 404106.36N/0740908.96W.
2503111943-2703111939EST
12/5/24
1430Z
!FDC 4/2166 EWR IAP NEWARK LIBERTY INTL, NEWARK, NJ.
RNAV (GPS) X RWY 29, ORIG-C...
LNAV MDA 560/HAT 550 ALL CATS. VISIBILITY CAT C/D 1 5/8.
PERM CRANE (34-000846) 439FT MSL (4A) 404104.88N/0740905.09W.
2412051430-2612051430EST
Yes
ALL
PORT AUTHORITY OF NY & NJ
4 WTC 150 GREENWICH ST, 18TH FLOOR
NEW YORK, NY 10006
Phone: 212-435-3720
AIDAN O'DONNELL
BUILDING #1- CONRAD ROAD
NEWARK, NJ 07114
Phone: 973-961-6161
NEW YORK FSS (ISP)
Toll Free: 1-800-WX-BRIEF
EWR
--
--
N/A
Yes - Lighted
No
Yes
Hangar
Landing Rights Airport
NOT an Airport of Entry
Major
Major
High Pressure
None
Air Freight
Cargo Handling

Runway 04L/22R

11000 ft. x 150 ft.
ASPH CONC
Excellent
GRVD
HIGH

--
210,000lbs
520,000lbs
1,000,000lbs
  Runway 04L Runway 22R
True Heading 26°206°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 40° 40' 31"N 40° 42' 09"N
Longitude 74° 10' 46"W 74° 09' 44"W
Elevation 10' 8'
Threshold Crossing Height 77 ft. AGL 66 ft. AGL
Visual Glide Path Angle 3.1° 3.1°
Visual Slope Indicator P4L P4L
Approach Lights MALSR MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights Yes

Runway 04R/22L

9999 ft. x 150 ft.
ASPH
Excellent
GRVD
HIGH

--
210,000lbs
520,000lbs
1,000,000lbs
  Runway 04R Runway 22L
True Heading 26°206°
Traffic Pattern Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 40° 40' 39"N 40° 42' 08"N
Longitude 74° 10' 27"W 74° 09' 31"W
Elevation 11' 9'
Threshold Crossing Height 71 ft. AGL 60 ft. AGL
Visual Glide Path Angle 2.95° 3°
Visual Slope Indicator P4L P4L
Approach Lights ALSF2 ALSF2
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 11/29

6725 ft. x 150 ft.
ASPH
Excellent
GRVD
HIGH

--
210,000lbs
520,000lbs
1,000,000lbs
  Runway 11 Runway 29
True Heading 95°275°
Traffic Pattern Left Left
Markings PIR NPI
Markings Condition GOOD GOOD
Latitude 40° 42' 10"N 40° 42' 04"N
Longitude 74° 10' 51"W 74° 09' 24"W
Elevation 18' 10'
Threshold Crossing Height 60 ft. AGL 60 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4R
Approach Lights
Centerline Lights Yes Yes
Runway End Identifier Lights Yes Yes

Runway H1

54 ft. x 54 ft.
ASPH
Excellent
NONE
PERI

--
--
--
--
  Runway H1 Runway
True Heading 100°280°
Traffic Pattern
Markings NPI
Markings Condition GOOD
Latitude 40° 42' 16"N N/A
Longitude 74° 10' 05"W N/A
Elevation 8' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-10RWY 4R & 4L DEP USE UPPER ANT FOR ATC COM.
A110-11HIGH VOLUME OF LOW LEVEL HEL TFC ARR AND DEP HELO KEARNY HELI (65NJ) LCTD 3.5 MILES NE OF ARPT.
A110-12RWY STATUS LIGHTS IN OPR.
A110-14CPDLC DEPARTURE CLEARANCE SERVICE AVAILABLE.
A110-17ADG IV ACFT RSTR FM PSG TWY Z3 ON Z.
A110-18TWY Z EAST OF TWY U ACFT SPEED RSTR OF 17 KTS/20 MPH MAX FOR ALL ACFT WITH WINGSPANS IN EXCESS OF 171 FT.
A110-2FLOCKS OF BIRDS ON & INVOF ARPT.
A110-20ALL TWYS SURROUNDING "BALLPARK" PRKG AREA (TWY Y BTN TWY S AND TWY U, TWY S BTN TWY Y AND TWY K, TWAY K BTN TWY S AND TWY B, TWY B BTN TWY K AND TWY U, AND TWY U BTN TWY B AND TWY Y) ACFT SPEED RSTR OF 17KTS/20MPH FOR ALL AFCT WITH WINGSPANS IN EXCESS OF 171 FT.
A110-21TWY EE BTN RWY 4R-22L AND RWY 11-29 CLSD TO AFCT WITH WINGSPANS IN EXCESS OF 171 FT.
A110-23TWY Y BTN RM AND TWY U, SPEED RESTRICTION OF 17KT (20MPH).
A110-25TWY Z5 CLSD TO ACFT WITH WINGSPANS IN EXCESS OF 118 FT.
A110-26TWY A BTN TWY AA AND RAMP CLSD TO ACFT WITH WINGSPANS IN EXCESS OF 171 FT.
A110-27TWY A11 W OF TWY A ACFT SPD RSTR OF 17 KTS/20 MPH MAX FOR ALL ACFT WITH WINGSPANS IN EXCESS OF 171 FT.
A110-28ACFT WITH WINGSPANS IN EXCESS OF 118 FEET PROHIBITED FROM TURNING S ON TWY R FROM TWY B1.
A110-29DURNG ATC ZERO EVENTS; ARPT OPS WILL MNT 118.3 AND PROVIDE EMERG NOTIFICATIONS TO ARFF.
A110-3NOISE RSTR CALL 212-435-3784 DRG NML BUS HRS.
A110-30WHEN RWY 04R/L IN USE, ACFT PRKG AT TRML A CAN EXP TO ENTER RAMP VIA TWY A8, UNLESS ADZD BY ATC.
A110-31WHEN RWY 22L/R IN USE, ACFT PRKG AT TRML A CAN EXP TO ENTER RAMP VIA TWY A10 OR A12, UNLESS ADZD BY ATC.
A110-4PARA-SAIL & BANNER TOWING OPS 1000 FT & BLO IN UPPER & LOWER NY BAYS INCLUDING ROCKAWAY INLET INDEF.
A110-8TWY Z BTN TWY Z2 & Z4 CLSD TO ACFT WITH WINGSPANS IN EXCESS OF 171 FT.
NEWARK LIBERTY INTL (ICAO: KEWR, IATA: EWR) is a public airport located in NEWARK, NJ.
