KESC
DELTA COUNTY
PublicPUB

2 miles SW of ESCANABA, MI
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
45° 43' 22"N 87° 05' 37"W
609' MSL
1609' MSL
05W
JET A, 100LL
GREEN BAY (GRB)
GREEN BAY
MINNEAPOLIS (ZMP)
7/11/24-8/8/24
KESC LIFR
5:56 AM EDT
Fog
Overcast 200'
0.25sm
52°F
52°F
29.97"Hg
Calm
AO2 SLP151 T01110111 $
KESC 190956Z AUTO 00000KT 1/4SM FG OVC002 11/11 A2997 RMK AO2 SLP151 T01110111 $
Add Your Business

KESC FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

AWOS-3PT

AWOS-3PT
906-786-9001
 121.425

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KSAW (39nm)
Thu, 9/19 3:02 AM EDT
Thu, 9/19 3:00 AM EDT - Fri, 9/20 2:00 AM EDT
LIFR
3:00 AM EDT - 9:00 AM EDT
Fog
Obscured
0.25sm
190° 5kts
LIFR
9:00 AM EDT - 10:00 AM EDT
Mist
Broken 300'
1sm
190° 5kts
VFR
10:00 AM EDT - 1:00 PM EDT
Few 19,000'
6sm
190° 6kts
VFR
1:00 PM EDT - 2:00 AM EDT
Few 17,000'
6sm
190° 12kts
KSAW 190702Z 1907/2006 19005KT 1/4SM FG VV002
   FM191300 19005KT 1SM BR BKN003
   FM191400 19006KT P6SM FEW190
   FM191700 19012KT P6SM FEW170
KESC
Domestic
9/7/241223Z !ESC 09/010 ESC RWY 01 RWY END ID LGT U/S 2409071223-2409301230
7/9/242056Z !ESC 07/038 ESC OBST TOWER LGT (ASR 1006722) 454821.00N0871015.00W (6.0NM NNW ESC) 1153.9FT (398.0FT AGL) U/S 2407092056-2411092359
7/9/242046Z !ESC 07/037 ESC OBST TOWER LGT (ASR 1006721) 454817.00N0871015.00W (5.9NM NNW ESC) 1153.9FT (398.0FT AGL) U/S 2407092046-2411092359
3/22/241336Z !ESC 03/033 ESC OBST TOWER LGT (ASR 1200100) 455101.90N0870212.70W (8.1NM NNE ESC) 941.6FT (223.1FT AGL) U/S 2403221336-2409192359
No
0600-2130
FOR SVC CALL ARPT OPS 906-420-1591.
DELTA COUNTY
310 LUDINGTON ST
ESCANABA, MI 49829-4057
Phone: 906-789-5100
ROBERT RANSTADLER
DELTA COUNTY AIRPORT, 3300 AIRPORT RD
ESCANABA, MI 49829-1057
Phone: 906-217-7593
GREEN BAY FSS (GRB)
Toll Free: 1-800-WX-BRIEF
ESC
--
ACTVT MALSR RWY 10; REIL RWY 01 & 28; PAPI RWY 28, 01, & 19; HIRL RWY 10/28; MIRL RWY 01/19 - CTAF.
N/A
Yes - Lighted
Yes
Yes
Hangar
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
1
Major
Major
High & Low Pressure
None
Pilot Instruction
Aircraft Rental

Runway 01/19

5016 ft. x 100 ft.
ASPH
Good
PFC
MED
79 /F/A/X/T
40,000lbs
60,000lbs
--
--
  Runway 01 Runway 19
True Heading 1°181°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 45° 43' 06"N 45° 43' 56"N
Longitude 87° 05' 12"W 87° 05' 11"W
Elevation 592' 607'
Threshold Crossing Height 27 ft. AGL 42 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes

Runway 10/28

6498 ft. x 150 ft.
ASPH
Good
PFC
HIGH
80 /F/A/X/T
80,000lbs
120,000lbs
210,000lbs
--
  Runway 10 Runway 28
True Heading 91°271°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 45° 43' 15"N 45° 43' 14"N
Longitude 87° 06' 43"W 87° 05' 11"W
Elevation 609' 593'
Threshold Crossing Height -- 53 ft. AGL
Visual Glide Path Angle -- 3°
Visual Slope Indicator -- P4R
Approach Lights MALSR
Centerline Lights No No
Runway End Identifier Lights No Yes
A110-4FLD CONDS UNMON 2130-0600.
A110-5FOR CD IF UNA TO CTC ON FSS FREQ, CTC MINNEAPOLIS ARTCC AT 651-463-5588.
A110-7BIRDS ON & INVOF ARPT.
DELTA COUNTY (ICAO: KESC, IATA: ESC) is a public airport located in ESCANABA, MI.
