KEFD
ELLINGTON
PublicPUB

15 miles SE of HOUSTON, TX
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
29° 36' 26"N 95° 09' 31"W
32' MSL
632' MSL
05E
JET A, 100LL
FORT WORTH (FTW)
HOUSTON
HOUSTON (ZHU)
10/31/24-11/28/24
KEFD MVFR
5:54 AM CST
Overcast 1,200'
10sm
66°F
63°F
29.91"Hg
330° 12kts
Gusts 18kts
KEFD 091154Z 33012G18KT 10SM OVC012 19/17 A2991
Add Your Business

KEFD FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Terminal Area Forecast

KEFD
Sat, 11/9 4:25 AM CST
Sat, 11/9 4:00 AM CST - Sun, 11/10 4:00 AM CST
MVFR
4:00 AM CST - 2:00 AM CST
Mist
Overcast 2,000'
5.59sm
29.88"Hg
VRB° 6kts
LIFR
Temporary 6:00 AM CST - 9:00 AM CST
Light Thunderstorm and Rain
Overcast 300'
4.97sm
VRB° 25kts
Gusts 35kts
LIFR
Becoming 2:00 AM CST - 4:00 AM CST
Mist
Broken 300'
4.97sm
29.91"Hg
VRB° 6kts
TAF AMD KEFD 091025Z 0910/1010 VRB06KT 9000 BR OVC020 QNH2987INS
   TEMPO 0912/0915 VRB25G35KT 8000 -TSRA OVC003CB
   BECMG 1008/1009 VRB06KT 8000 BR BKN003 QNH2992INS TX27/0921Z TN20/0910Z
KEFD
Domestic
10/31/241334Z !EFD 10/023 EFD RWY 04/22 EDGE MARKINGS NOT STD 2410311334-2412312300
10/31/241333Z !EFD 10/022 EFD RWY 04/22 CL MARKINGS NOT STD 2410311333-2412312300
10/30/241722Z !EFD 10/021 EFD OBST TOWER LGT (ASR 1042982) 294118.80N0951023.80W (4.6NM NW EFD) UNKNOWN (303FT AGL) U/S 2410301722-2411252359
10/11/241751Z !EFD 10/002 EFD NAV ILS RWY 22 GP NOT MNT 2410111751-2411202000EST
9/28/241214Z !EFD 09/021 EFD RWY 35L PAPI U/S 2409281214-2412312359
9/28/241213Z !EFD 09/020 EFD NAV ILS RWY 35L U/S 2409281213-2412312359
4/20/231546Z !EFD 04/017 EFD AIRSPACE SEE ZHU 04/460 UAS 2304201546-2503102359
FDC
11/6/241500Z !FDC 4/9592 EFD SID ELLINGTON, HOUSTON, TX.
INDUSTRY ONE DEPARTURE...
LAREDO TRANSITION NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
LRD VORTAC OUT OF SERVICE. 2411061500-2411130247EST
10/1/241350Z !FDC 4/2841 EFD SID ELLINGTON, HOUSTON, TX.
PALACIOS THREE DEPARTURE...
DEPARTURE PROCEDURE NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
THX VORTAC OUT OF SERVICE. 2410011350-2505131350EST
9/16/241341Z !FDC 4/5906 EFD SID ELLINGTON, HOUSTON, TX.
PALACIOS THREE DEPARTURE...
DEPARTURE PROCEDURE NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
PSX VORTAC OUT OF SERVICE. 2409161341-2411271341EST
7/30/241329Z !FDC 4/9805 EFD SID ELLINGTON, HOUSTON, TX.
LEONA FOUR DEPARTURE...
ARDMORE TRANSITION NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
ADM VORTAC OUT OF SERVICE. 2407301329-2412181329EST
5/14/241428Z !FDC 4/3515 EFD SID ELLINGTON, HOUSTON, TX.
CRIED ONE DEPARTURE...
DEPARTURE PROCEDURE NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
CQY VOR OUT OF SERVICE. 2405141428-2506251428EST
5/14/241428Z !FDC 4/3514 EFD SID ELLINGTON, HOUSTON, TX.
LEONA FOUR DEPARTURE...
BONHAM TRANSITION NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
CQY VOR OUT OF SERVICE. 2405141428-2506251428EST
4/30/242359Z !FDC 4/5020 EFD STAR ELLINGTON, HOUSTON, TX. HUDZY FOUR ARR... SWB
TRANSITION N/A EXC FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH
GPS, SWB VOR U/S 2404302359-2504302359
4/12/241648Z !FDC 4/0230 EFD SID ELLINGTON, HOUSTON, TX.
HOODO SEVEN DEPARTURE (RNAV)...
DEPARTURE PROCEDURE GPS REQUIRED,
LEV VORTAC OUT OF SERVICE. 2404121648-2504231648EST
Military
11/7/241500Z !KEFD M0241/24 EFD UNMANNED ACFT WITHIN AREA DEFINED AS 5NM RADIUS OF EFD EFD092016 (9NM SE T41) 2411071500-2411071930
11/6/241500Z !KEFD M0240/24 EFD UNMANNED ACFT WITHIN AREA DEFINED AS 5NM RADIUS OF EFD EFD092016 (9NM SE T41) 2411061500-2411061930
11/2/242107Z RWY 04 DEPARTURE END BAK-14 IS OUT OF SERVICE.
11/2/242107Z RWY 35L DEPARTURE END BAK-14 IS OUT OF SERVICE.
Yes
ALL
CITY OF HOUSTON
16930 JFK BLVD
HOUSTON, TX 77032
Phone: 281-233-3000
ARTURO MACHUCA
BLDG 510 ELLINGTON FIELD
HOUSTON, TX 77034
Phone: 713-847-4200
FORT WORTH FSS (FTW)
Toll Free: 1-800-WX-BRIEF
EFD
Sunset to Sunrise
--
N/A
Yes - Lighted
No
No
Tie-Down
Landing Rights Airport
0
0
0
0
0
0
Major
Major
Low Pressure
Low Pressure
Cargo Handling
Pilot Instruction
Aircraft Rental

Runway 04/22

8001 ft. x 150 ft.
CONC
Good
GRVD
HIGH
110/R/B/W/T
100,000lbs
164,000lbs
300,000lbs
668,000lbs
  Runway 04 Runway 22
True Heading 44°224°
Traffic Pattern Right
Markings NPI PIR
Markings Condition GOOD GOOD
Latitude 29° 35' 53"N 29° 36' 51"N
Longitude 95° 09' 47"W 95° 08' 44"W
Elevation 26' 30'
Threshold Crossing Height 50 ft. AGL 50 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 17L/35R

4609 ft. x 75 ft.
CONC
Fair
NONE

12 /R/C/W/T
24,000lbs
63,000lbs
145,000lbs
300,000lbs
  Runway 17L Runway 35R
True Heading 179°359°
Traffic Pattern Right
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 29° 37' 06"N 29° 36' 21"N
Longitude 95° 09' 22"W 95° 09' 21"W
Elevation 31' 30'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 17R/35L

9001 ft. x 150 ft.
CONC
Good
GRVD
HIGH
120/R/B/W/T
100,000lbs
190,000lbs
590,000lbs
800,000lbs
  Runway 17R Runway 35L
True Heading 179°359°
Traffic Pattern Right
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 29° 37' 06"N 29° 35' 37"N
Longitude 95° 09' 52"W 95° 09' 50"W
Elevation 32' 28'
Threshold Crossing Height 48 ft. AGL 32 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSF MALSF
Centerline Lights Yes Yes
Runway End Identifier Lights
A110-1TWY B UNLGTD EAST OF RY 17R/35L; DALGT USE ONLY.
A110-11NMRS BIRDS ON AND INVOF ARPT ALL QUADRANTS.
A110-23RWY 17R ARRESTING BARRIERS 1500 FT LCTD IN SAFETY AREA 14 INCH LIP EACH SIDE OF RWY.
A110-24RWY 35L ARRESTING BARRIERS 1849 FT LCTD IN SAFETY AREA 14 INCH LIP EACH SIDE OF RWY.
A110-29FLUID: LHOX HPOX
A110-30SEE FLIP AP/1 SUPPLEMENTARY ARPT RMK.
A110-31CAUTION: NMRS SMALL ACFT WITH EXTV TRNG IN AREA OF ARPT.
A110-35NS ABTMT: NOISE SENSITIVE AREAS S AND E OF FLD. JET ACFT RSTD TO STR-IN FULL STOP LDG ONLY BTN 2200-0700 DLY, 2200-1300 SUN. ON DEP JET ACFT MIN USE OF AFTER BURNERS AND CLIMB RWY HDG TO 1000 PRIOR TO TURNS OR REJOIN.
A110-38CG: MIN 24 HR PPR EXC CG MSN. C713-578-3000.
A110-39STREET LGTS LCTD 700 FT EAST OF RWY 17R APCH MAY BE MISTAKEN FOR APCH LGTS.
A110-4BE ALERT FOR MIL ACFT AT 1600 MSL MAKING OVHD APCHS.
A110-41MISC: PRK RAMP CAP TDT710.
A110-48ANG: ANG RAMP CLSD TO ALL ACFT EXEC OFFL BUS ONLY. 24 HRS PPR, CTC BASE OPS, 1200-2130Z++ TUE-FRI, CLSD WKEND & HOL. DSN 454-2142, C281-929-2142. COMD POST AVBL 24 HR, DSN 454-2716, C281-929-2716. ALL OTHER TRAN ACFT CTC FBO 281-484-6551.
A110-49RWY 04 ARRESTING BARRIERS 1563 FT LCTD IN SAFETY AREA 14 INCH LIP EACH SIDE OF RWY.
A110-50RWY 22 ARRESTING BARRIERS 1496 FT LCTD IN SAFETY AREA 14 INCH LIP EACH SIDE OF RWY.
A110-52SERVICE - AGEAR: POTENTIAL FOR TAIL HOOK SKIP ON RWY 17R/35L AND RWY 04/22 DUE TO CNTLN LGT WITHIN 200' OF RWY A-G. AGEAR: A-GEAR LGTD MRK PLACEMENT EXCEEDS 75' FR RWY EDGE.
A110-53ARPT CLSD TO ACFT WITH WINGSPAN 171 FT OR GREATER EXCEPT 24 HRS PPR 281-433-1612.
A110-54SERVICE-FUEL: A++ (MIL).
A110-55ANG OPS COMD POST 288.5.
A110-56ANG: BASH PHASE II COND JUN-SEP FOR MIGRATORY BIRDS. BASH PHASE I OCT-MAY.
A110-57JASU: 1(-95) 1(-86) 1(JETEX5).
A110-58UAS OPS WI ELLINGTON CLASS D ASP, OPR HRS VARY.
A110-59PPR FOR UNSCHEDULED AIR CARRIER OPS, CTC 281-433-1612.
A110-60RWY 17L-35R AND TWY B EAST OF RWY 17R-35L NOT AVBL FOR AIR CARRIER ACFT.
A110-61NSTD AFLD MRK ON ANG ACFT PRK APN.
A110-770 FT AGL TANKS LCTD 1400 FT NE OF RY 17R APCH.
A110-9RWY 17L/35R BTWN TWYS C & G - DUAL PURPOSE RWY/TWY WITH TWY LGTS.
ELLINGTON (ICAO: KEFD, IATA: EFD) is a public airport located in HOUSTON, TX.
