| FDC |
|
4/28/251339Z
|
!FDC 5/2179 ECS IAP MONDELL FLD, NEWCASTLE, WY.
VOR RWY 32, AMDT 4A...
S-32 MDA 4980/802 HAT.
CIRCLING CATS A,B,C MDA 4980/HAA 802, CAT D MDA 5000/HAA 822.
TDZE 4178. APT ELEV 4178.
2504281339-2704281339EST
|
|
4/28/251339Z
|
!FDC 5/2178 ECS IAP MONDELL FLD, NEWCASTLE, WY.
RNAV (GPS) RWY 32, AMDT 1A...
LPV DA 4428/HAT 250. LNAV/VNAV DA 4618/HAT 440
LNAV MDA 4600/HAT 422
CIRCLING CATS A,B MDA 4700/HAA 522, CAT C MDA 4720/HAA 542, CAT D MDA 5000/HAA 822.
TDZE 4178. APT ELEV 4178.
2504281339-2704281339EST
|
|
4/28/251339Z
|
!FDC 5/2177 ECS IAP MONDELL FLD, NEWCASTLE, WY.
RNAV (GPS) RWY 14, AMDT 1A...
LPV DA 4419/HAT 250. LNAV/VNAV DA 4846/HAT 677. LNAV MDA 4920/HAT 751. CIRCLING CATS A,B,C MDA 4920/HAA 742 AND CAT D MDA 5000/HAA 822..
TDZE 4169. APT ELEV 4178.
2504281339-2704281339EST
|
|
5/30/231745Z
|
!FDC 3/3042 ECS PART 1 OF 2 ODP MONDELL FLD, NEWCASTLE, WY.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 4...
TAKEOFF OBSTACLE NOTES: RWY 14: LIGHT POLES 8 FT FROM DER, 77 FT
RIGHT OF CENTERLINE, 5 FT AGL/4179 FT MSL.
LIGHT POLE 8 FT FROM DER, 77 FT LEFT OF CENTERLINE, 3 FT AGL/4179
FT MSL.
TERRAIN 28 FT FROM DER, 328 FT LEFT OF CENTERLINE, 4188 FT MSL.
VEGETATION 80 FT FROM DER, 423 FT LEFT OF CENTERLINE, 3 FT AGL/4192
FT MSL.
TERRAIN, TRAVERSE WAY BEGINNING 131 FT FROM DER, 325 FT LEFT OF
CENTERLINE, UP TO 4194 FT MSL.
TRAVERSE WAYS, VEGETATION BEGINNING 314 FT FROM DER, 414 FT LEFT OF
CENTERLINE, UP TO 4205 FT MSL.
ANTENNA 1442 FT FROM DER, 880 FT LEFT OF CENTERLINE, 4244 FT MSL.
RWY 32: TERRAIN 59 FT FROM DER, 435 FT RIGHT OF CENTERLINE, 4176 FT
MSL.
TRAVERSE WAY, TERRAIN BEGINNING 188 FT FROM DER, 394 FT RIGHT OF
CENTERLINE, UP TO 4191 FT MSL.
TRAVERSE WAYS, TERRAINS, POLES, TRANSMISSION LINE BEGINNING 212 FT
FROM DER, 238 FT RIGHT OF CENTERLINE, UP TO 4205 FT MSL.
TERRAIN 5183 FT FROM DER, 1789 FT RIGHT OF CENTERLINE, 4310 FT MSL.
UP TO 4345 FT MSL. 2305301745-2505301745EST
END PART 1 OF 2
!FDC 3/3042 ECS PART 2 OF 2 ODP MONDELL FLD, NEWCASTLE, WY.
TERRAINS BEGINNING 5266 FT FROM DER, 1692 FT RIGHT OF CENTERLINE,
UP TO 4345 FT MSL. 2305301745-2505301745EST
END PART 2 OF 2
|
