No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KDMN
DEMING MUNI
PublicPUB

2 miles SE of DEMING, NM
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
32° 15' 45"N 107° 43' 08"W
4314' MSL
5314' MSL
10E
JET A-1+, 100LL
ALBUQUERQUE (ABQ)
ALBUQUERQUE
ALBUQUERQUE (ZAB)
7/11/24-8/8/24
KDMN VFR
4:53 AM MDT
Clear
10sm
58°F
39°F
30.01"Hg
270° 6kts
AO2 SLP090 T01440039
KDMN 191053Z AUTO 27006KT 10SM CLR 14/04 A3001 RMK AO2 SLP090 T01440039
Add Your Business

KDMN FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

ASOS

ASOS
575-544-4347
 118.525

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KDMN
Wed, 9/18 11:31 PM MDT
Thu, 9/19 12:00 AM MDT - Fri, 9/20 12:00 AM MDT
VFR
12:00 AM MDT - 1:00 PM MDT
Sky Clear
6sm
280° 6kts
VFR
1:00 PM MDT - 8:00 PM MDT
Few 25,000'
6sm
220° 10kts
VFR
8:00 PM MDT - 12:00 AM MDT
Scattered 25,000'
6sm
270° 6kts
KDMN 190531Z 1906/2006 28006KT P6SM SKC
   FM191900 22010KT P6SM FEW250
   FM200200 27006KT P6SM SCT250
KDMN
Domestic
9/17/241150Z !DMN 09/003 DMN OBST TOWER LGT (ASR 1022751) 321505.00N1074528.00W (2.1NM WSW DMN) 4544.0FT (246.1FT AGL) U/S 2409171150-2410172359
5/22/241252Z !DMN 05/007 DMN RWY 26 PAPI UNUSABLE 2405221252-2411222111EST
No
0700-1800
AFT HR - 575-494-2311.
CITY OF DEMING
PO BOX 706
DEMING, NM 88031
Phone: 575-546-8848
AZUCENA VARGAS
PO BOX 706
DEMING, NM 88031
Phone: 575-546-8848
ALBUQUERQUE FSS (ABQ)
Toll Free: 1-800-WX-BRIEF
DMN
--
ACTVT PAPI RWY 04, 08, 22, 26; MIRL RWY 08/26 - CTAF. 1730-2230 PAPI RWY 04, 08, 22, 26; MIRL RWY 08/26 PRESET LOW INTST; INCR INTST - CTAF.
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
7
3
1
0
0
0
None
None
None
None
Air Ambulance

Runway 04/22

5675 ft. x 60 ft.
ASPH
Good
NONE
MED
7 /F/D/X/T
12,000lbs
--
--
--
  Runway 04 Runway 22
True Heading 52°232°
Traffic Pattern Left Left
Markings NPI BSC
Markings Condition GOOD GOOD
Latitude 32° 15' 24"N 32° 15' 59"N
Longitude 107° 43' 53"W 107° 43' 01"W
Elevation 4,311' 4,303'
Threshold Crossing Height 44 ft. AGL 44 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 08/26

8018 ft. x 75 ft.
ASPH
Good
NONE
MED
9 /F/D/X/T
20,000lbs
--
--
--
  Runway 08 Runway 26
True Heading 90°270°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD FAIR
Latitude 32° 15' 47"N 32° 15' 47"N
Longitude 107° 43' 42"W 107° 42' 09"W
Elevation 4,314' 4,288'
Threshold Crossing Height 43 ft. AGL 40 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1HEL ARR & DEP E; RMN N OF SEGMENTED CIRCLE.
A110-2INTXN TKOF NA.
A110-3FOR CD IF UNA TO CTC ON FSS FREQ, CTC ALBUQUERQUE ARTCC AT 505-856-4561.
DEMING MUNI (ICAO: KDMN, IATA: DMN) is a public airport located in DEMING, NM.
