KDMN
DEMING MUNI
PublicPUB

2 miles SE of DEMING, NM
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
32° 15' 45"N 107° 43' 08"W
4314' MSL
5314' MSL
10E
JET A-1+, 100LL
ALBUQUERQUE (ABQ)
ALBUQUERQUE
ALBUQUERQUE (ZAB)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

KDMN FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

ASOS

ASOS
575-544-4347
 118.525

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

No TAF is available for this location.
KDMN
Domestic
1/18/251600Z !DMN 01/010 DMN AIRSPACE UAS WI AN AREA DEFINED AS .1NM RADIUS OF 321644N1074657W (2.4NM W DMN) SFC-500FT AGL DLY 1600-2200 2501181600-2501232200
1/10/251522Z !DMN 01/009 DMN OBST TOWER LGT (ASR 1238289) 321442.00N1075726.10W (12.2NM W DMN) 4687.0FT (252.0FT AGL) U/S 2501101522-2504100500
1/5/250114Z !DMN 01/004 DMN OBST TOWER LGT (ASR 1040494) 321429.00N1073610.00W (6.1NM ESE DMN) 4445.5FT (161.7FT AGL) U/S 2501050114-2502042359
1/3/250256Z !DMN 01/002 DMN OBST TOWER LGT (ASR 1005162) 321644.40N1074657.70W (3.4NM WNW DMN) 4719.2FT (354.0FT AGL) U/S 2501030256-2503032359
12/10/240135Z !DMN 12/005 DMN OBST TOWER LGT (ASR 1022751) 321505.00N1074528.00W (2.1NM WSW DMN) 4544.0FT (246.1FT AGL) U/S 2412100135-2502282359
11/22/241309Z !DMN 11/015 DMN RWY 26 PAPI UNUSABLE 2411221309-2505222111EST
No
0700-1800
AFT HR - 575-494-2311.
CITY OF DEMING
PO BOX 706
DEMING, NM 88031
Phone: 575-546-8848
AZUCENA VARGAS
PO BOX 706
DEMING, NM 88031
Phone: 575-546-8848
ALBUQUERQUE FSS (ABQ)
Toll Free: 1-800-WX-BRIEF
DMN
--
ACTVT PAPI RWY 04, 08, 22, 26; MIRL RWY 08/26 - CTAF. 1730-2230 PAPI RWY 04, 08, 22, 26; MIRL RWY 08/26 PRESET LOW INTST; INCR INTST - CTAF.
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
Air Ambulance

Runway 04/22

5675 ft. x 60 ft.
ASPH
Good
NONE
MED
7 /F/D/X/T
12,000lbs
--
--
--
  Runway 04 Runway 22
True Heading 52°232°
Traffic Pattern Left Left
Markings NPI BSC
Markings Condition GOOD GOOD
Latitude 32° 15' 24"N 32° 15' 59"N
Longitude 107° 43' 53"W 107° 43' 01"W
Elevation 4,311' 4,303'
Threshold Crossing Height 44 ft. AGL 44 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 08/26

8018 ft. x 75 ft.
ASPH
Good
NONE
MED
9 /F/D/X/T
20,000lbs
--
--
--
  Runway 08 Runway 26
True Heading 90°270°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD FAIR
Latitude 32° 15' 47"N 32° 15' 47"N
Longitude 107° 43' 42"W 107° 42' 09"W
Elevation 4,314' 4,288'
Threshold Crossing Height 43 ft. AGL 40 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1HEL ARR & DEP E; RMN N OF SEGMENTED CIRCLE.
A110-2INTXN TKOF NA.
A110-3FOR CD IF UNA TO CTC ON FSS FREQ, CTC ALBUQUERQUE ARTCC AT 505-856-4561.
DEMING MUNI (ICAO: KDMN, IATA: DMN) is a public airport located in DEMING, NM.
