TOM B DAVID FLD - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KCZL
ICAO KCZLLocal CZL
TOM B DAVID FLD
PublicPUB

3 miles S of CALHOUN, GA, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
34° 27' 19"N 84° 56' 21"W
Elevation
656' MSL
Pattern Alt
1656' MSL
Mag Variation
5°W
Declination
5°W
Fuel
JET A (FSII), 100LL
FSS
MACON (MCN)
Sectional
ATLANTA
ARTCC
ATLANTA (ZTL)
Data Effective
2/19/26-3/19/26
KCZL VFR
10:55 PM EST
Broken 3,100'
10sm
57°F
55°F
30.29"Hg
140° 6kts
AO2
METAR KCZL 040355Z AUTO 14006KT 10SM BKN031 14/13 A3029 RMK AO2
+ Add Your Business

KCZL FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

AWOS-3PT 119.975
(706) 578-1205

Common

CTAF 122.8
ACTVT PAPI RWY 17 & 35; MIRL RWY 17/35 - CTAF. MIRL RWY 17/35 PRESET ON MED INTST DUSK - 2200, TO INCR INTST & ACTVT AFT 2200 - CTAF.
UNICOM 122.8

Center

ATLANTA CENTER 124.5
LOW, APCH/DEP SVC PRVDD BY ATLANTA ARTCC ON FREQS 124.5/270.325 (GADSDEN RCAG).

FAA A/FD Pages

Airport Minimums

Instrument Approach

Terminal Area Forecast

KRYY (31nm)
Tue, 3/3 6:41 PM EST
Tue, 3/3 7:00 PM EST - Wed, 3/4 7:00 PM EST
VFR
7:00 PM EST - 2:00 AM EST
Few 25,000'
6sm
120° 6kts
VFR
2:00 AM EST - 4:00 AM EST
Scattered 10,000'
Scattered 1,800'
6sm
100° 4kts
IFR
4:00 AM EST - 10:00 AM EST
Mist
Broken 800'
5sm
Calm
LIFR
Temporary 5:00 AM EST - 9:00 AM EST
Mist
Overcast 300'
2sm
Calm
IFR
10:00 AM EST - 12:00 PM EST
Overcast 1,500'
Broken 800'
6sm
140° 4kts
VFR
12:00 PM EST - 2:00 PM EST
Broken 4,000'
Scattered 1,500'
6sm
170° 6kts
VFR
2:00 PM EST - 7:00 PM EST
Scattered 15,000'
Scattered 4,000'
6sm
170° 6kts
TAF KRYY 032341Z 0400/0424 12006KT P6SM FEW250
   FM040700 10004KT P6SM SCT018 SCT100
   FM040900 00000KT 5SM BR BKN008
   TEMPO 0410/0414 2SM BR OVC003
   FM041500 14004KT P6SM BKN008 OVC015
   FM041700 17006KT P6SM SCT015 BKN040
   FM041900 17006KT P6SM SCT040 SCT150
KCZL
EffectiveExpiresCategoryNOTAM
Domestic
2/23/26
1209Z
5/24/26
0500Z
!MCN 02/614 CZL OBST TOWER LGT (ASR 1059018) 342210.40N0845651.90W (5.2NM S CZL) 1099.1FT (270.0FT AGL) U/S 2602231209-2605240500
No
NOV-MAR 0800-1800
APR-OCT 0800-2000
CALHOUN-GORDON CO ARPT AUTH
1957 HWY 41 S
CALHOUN, GA 30701
Phone: 706-602-8000
DWIGHT ALBRITTON
1957 HWY 41 S
CALHOUN, GA 30701
Phone: 706-602-8000
MACON FSS (MCN)
Toll Free: 1-800-WX-BRIEF
MCN
--
ACTVT PAPI RWY 17 & 35; MIRL RWY 17/35 - CTAF. MIRL RWY 17/35 PRESET ON MED INTST DUSK - 2200, TO INCR INTST & ACTVT AFT 2200 - CTAF.
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Major
Major
None
None
Air Ambulance
Pilot Instruction
Aircraft Rental
Annual Surveying

Runway 17/35

6034 ft. x 100 ft.
ASPH
Excellent
NONE
MED

15,000lbs
100,000lbs
100,000lbs
--
  Runway 17 Runway 35
True Heading 168°348°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 34° 27' 49"N 34° 26' 50"N
Longitude 84° 56' 28"W 84° 56' 14"W
Elevation 639' 656'
Threshold Crossing Height 44 ft. AGL 30 ft. AGL
Visual Glide Path Angle 3.5° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1SELF-SVC FUEL AVBL WITH CREDIT CARD.
A110-2DEER & WILDLIFE ON OR INVOF ARPT.
A110-3FOR CD CTC ATLANTA ARTCC AT 770-210-7692.
A57-35APCH SLOPE 20:1 TO DSPLCD THLD, TREES 2172 FT OUT, 318 LEFT.
A81-APTACTVT PAPI RWY 17 & 35; MIRL RWY 17/35 - CTAF. MIRL RWY 17/35 PRESET ON MED INTST DUSK - 2200, TO INCR INTST & ACTVT AFT 2200 - CTAF.
TOM B DAVID FLD (ICAO: KCZL, IATA: CZL) is a public airport located in CALHOUN, GA, US.
