KICKAPOO DOWNTOWN - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KCWC
ICAO KCWCIATA KIPLocal CWC
KICKAPOO DOWNTOWN
PublicPUB

3 miles S of WICHITA FALLS, TX, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
33° 51' 38"N 98° 29' 25"W
Elevation
1003' MSL
Pattern Alt
2003' MSL
Mag Variation
4°E
Declination
4°E
Fuel
JET A, 100LL
FSS
FORT WORTH (FTW)
Sectional
DALLAS-FT WORTH
ARTCC
FORT WORTH (ZFW)
Data Effective
2/19/26-3/19/26
KCWC VFR
9:35 PM CST
No Clouds
10sm
72°F
55°F
29.94"Hg
120° 7kts
AO2 T02200126 PWINO
METAR KCWC 040335Z AUTO 12007KT 10SM 22/13 A2994 RMK AO2 T02200126 PWINO
+ Add Your Business

KCWC FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

AWOS-3 119.625
(940) 766-2967

Common

CTAF 122.7
ACTVT REIL RWYS 17 & 35; MIRL RWY 17/35 - CTAF.
UNICOM 122.7

Clearance

Clearance Delivery 121.2

Approach

SHEPPARD APPROACH 120.4

Departure

SHEPPARD DEPARTURE 120.4

Center

SHEPPARD CENTER 133.5
LOW, APCH/DEP SVC PRVDD BY FORT WORTH ARTCC (ZFW) ON FREQS 133.5/350.35 (WICHITA FALLS RCAG) WHEN SHEPPARD APCH CLSD.

FAA A/FD Pages

Airport Minimums

Instrument Approach

Terminal Area Forecast

KSPS (7nm)
Tue, 3/3 5:20 PM CST
Tue, 3/3 6:00 PM CST - Wed, 3/4 6:00 PM CST
VFR
6:00 PM CST - 11:00 PM CST
Broken 12,000'
6sm
170° 9kts
VFR
11:00 PM CST - 5:00 AM CST
Broken 10,000'
Scattered 5,000'
6sm
VRB° 5kts
MVFR
5:00 AM CST - 6:00 PM CST
Overcast 1,500'
6sm
340° 9kts
TAF KSPS 032320Z 0400/0424 17009KT P6SM BKN120
   FM040500 VRB05KT P6SM SCT050 BKN100
   FM041100 34009KT P6SM OVC015
KCWC
EffectiveExpiresCategoryNOTAM
Domestic
2/24/26
1619Z
6/24/26
1619Z
!FTW 02/642 CWC OBST TOWER LGT (ASR 1259845) 334651.30N0982430.70W (6.3NM SE CWC) 1149.0FT (255.9FT AGL) U/S 2602241619-2606241619
2/23/26
2147Z
3/2/26
2359Z
!FTW 02/623 CWC SVC AUTOMATED WX BCST SYSTEM U/S 2602232147-2603022359
2/23/26
1500Z
5/23/26
2359Z
!FTW 02/602 CWC OBST TOWER LGT (ASR 1063706) 335241.00N0982649.00W (2.4NM ENE CWC) 1322.2FT (308.4FT AGL) U/S 2602231500-2605232359
1/3/26
0606Z
3/3/26
0606Z
!FTW 01/042 CWC OBST TOWER LGT (ASR 1048308) 334900.00N0981320.00W (13.7NM E CWC) 1267.1FT (393.0FT AGL) U/S 2601030606-2603030606
FDC
10/30/24
1733Z
!FDC 4/6207 CWC ODP KICKAPOO DOWNTOWN, WICHITA FALLS, TX.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 3...
TAKEOFF OBSTACLE NOTES: RWY 17, BUILDINGS, BEGINNING 186FT FROM DER, BEGINNING 416FT LEFT OF CENTERLINE, UP TO 21 AGL/UP TO 1023 MSL (2023-ASW-3045/3045/3086/9090-OE). ALL OTHER DATA REMAINS AS PUBLISHED. 2410301733-2610301733EST
No
0600-2000
CITY OF WICHITA FALLS
4515 JACKSBORO HWY
WICHITA FALLS, TX 76302
Phone: 940-855-3621
ANDREW HOLLEY
4515 OLD JACKSBORO HWY
WICHITA FALLS, TX 76302
Phone: 940-733-2327
FORT WORTH FSS (FTW)
Toll Free: 1-800-WX-BRIEF
FTW
--
ACTVT REIL RWYS 17 & 35; MIRL RWY 17/35 - CTAF.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Major
Major
None
None
Pilot Instruction
Aircraft Rental

Runway 17/35

4450 ft. x 75 ft.
CONC
Good
NONE
MED

30,000lbs
--
--
--
  Runway 17 Runway 35
True Heading 180°0°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 33° 52' 00"N 33° 51' 16"N
Longitude 98° 29' 25"W 98° 29' 26"W
Elevation 979' 1,003'
Threshold Crossing Height 37 ft. AGL 41 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes
A110-1DO NOT MISTAKE KICKAPOO DOWNTOWN FOR SHEPPARD AFB/WICHITA FALLS MUNI ARPT 7 MILES NORTH.
A110-2INTENSIVE JET TRAINER TFC 2300-3000 FT MSL WITHIN ALERT AREA A-636. REMAIN BLO 1800 FT MSL UNTIL IN RADAR CTC WITH APCH CTL FOR TFC ADVISORIES.
A110-4ANTS 2054 FT MSL 3.5 MI NW OF ARPT.
A110-5FOR CD CTC FORT WORTH ARTCC AT 817-858-7584.
A57-17OBSTN CLNC SLOPE 22:1 TO DSPLCD THR OVR 14 FT RD, 320 FT DSTC.
A57-35OBSTN CLNC SLOPE 37:1 TO DSPLCD THR.
A58-175 FT FENCE, 0-199 FT DSTC, 210 FT L.
A70-100LLFULL & SELF SERVE 100 LL & JET A
A81-APTACTVT REIL RWYS 17 & 35; MIRL RWY 17/35 - CTAF.
KICKAPOO DOWNTOWN (ICAO: KCWC, IATA: CWC) is a public airport located in WICHITA FALLS, TX, US.
