No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KCRQ
MC CLELLAN-PALOMAR
PublicPUB

3 miles SE of CARLSBAD, CA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
33° 07' 42"N 117° 16' 48"W
330' MSL
1330' MSL
14E
JET A, 100LL
SAN DIEGO (SAN)
LOS ANGELES
LOS ANGELES (ZLA)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

KCRQ FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 118.6

ATIS

ATIS
(760-438-2117)
 120.15

Clearance Delivery

CD/P
 134.85

Ground

GND/P
 121.8

Tower

LCL/P
 118.6

Terminal Area Forecast

No TAF is available for this location.
KCRQ
Domestic
1/15/251630Z !CRQ 01/011 CRQ NAV ILS RWY 24 LOC/DME U/S 2501151630-2501152355
1/7/251846Z !CRQ 01/003 CRQ SVC PCL RWY 06 PAPI U/S 2501071846-2502262359EST
12/17/242148Z !CRQ 12/010 CRQ NAV ILS RWY 24 GP U/S 2412172148-2501222359EST
Yes
0700-2200
COUNTY OF SAN DIEGO
1960 JOE CROSSON DRIVE
EL CAJON, CA 92020-1235
Phone: 619-956-4800
JOHN OTTO
2192 PALOMAR AIRPORT ROAD
CARLSBAD, CA 92011-4409
Phone: 760-431-4646
SAN DIEGO FSS (SAN)
Toll Free: 1-800-WX-BRIEF
CRQ
--
WHEN ATCT CLSD ACTVT HIRL RWY 06/24, PAPI RWYS 06 & 24, MALSR RWY 24 - CTAF.
N/A
No
Yes
Yes
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
High & Low Pressure
None
Air Freight
Air Ambulance
Avionics
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 06/24

4897 ft. x 150 ft.
ASPH
Good
GRVD
HIGH

110,000lbs
168,000lbs
248,000lbs
692,000lbs
  Runway 06 Runway 24
True Heading 79°259°
Traffic Pattern Left Right
Markings NPI PIR
Markings Condition GOOD GOOD
Latitude 33° 07' 37"N 33° 07' 46"N
Longitude 117° 17' 17"W 117° 16' 20"W
Elevation 330' 326'
Threshold Crossing Height 35 ft. AGL 54 ft. AGL
Visual Glide Path Angle 3° 3.2°
Visual Slope Indicator P4L P4L
Approach Lights MALSR
Centerline Lights No No
Runway End Identifier Lights No No

Runway H1

40 ft. x 50 ft.
CONC
Good
NONE
HIGH

--
--
--
--
  Runway H1 Runway
True Heading 74°254°
Traffic Pattern
Markings
Markings Condition GOOD
Latitude 33° 07' 41"N N/A
Longitude 117° 16' 21"W N/A
Elevation 316' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1ARPT HAS NOISE ABATEMENT PROCEDURES CONTACT AMGR 760-431-4646.
A110-10VOLUNTARY CURFEW: JETS 2200-0700 LCL, PROPS 0000-0600 LCL, EMERG, LIFEGUARD, AND LAW ENFORCEMENT EXCEPTED.
A110-11REQUEST JETS FLY THE ILS APPROACH.
A110-12LTD TRANSIENT TIE DOWN SPACE ON PUBLIC RAMP.
A110-13PPR FOR ALL MILITARY ACFT CALL AMGR (760) 431-4646.
A110-15RWY 24 HARD TO SEE 2 HRS PRIOR TO SS; DO NOT MISTAKE TWY A AS THE RWY.
A110-16NORTH SIDE RAMP LIMITED TO 12,500 LBS .
A110-17ALL ACFT MULT PRACTICE APCHS AND LNDGS DISCOURAGED 2200-0700 LCL.
A110-18RY 6/24 SOUTH VFR TFC PATTERN CLSD 2200-0700 LCL.
A110-19WHEN TWR CLSD ACFT MUST SELF-ANNOUNCE ON CTAF PRIOR TO LDG OR TKOF.
A110-2MULTIPLE APCHS BY LARGE ACFT (INCLUDING LARGE HEL) NOT AUTHORIZED.
A110-20TSNT PRKG LTD TO SML SNGL AND TWIN ENG ACFT WITH WINGSPANS UNDER 38 FT.
A110-21USE CAUTION REG THERMAL PLUMES IN THE VCNTY OF POWER PLANT APRXLY 2.7 NM WNW OF ARPT.
A110-22NO JET ACFT PRKG ALLOWED IN TSNT PRKG.
A110-23FOR CD WHEN ATCT CLSD CTC SOCAL APCH AT 800-448-3724.
A110-3NO JET ACFT TRNG DUE TO NOISE ABATEMENT AND TFC CONGESTION.
A110-4EXTENSIVE BIRD ACTIVITY IN VICINITY ESPECIALLY IN SPRING.
A110-7RWY 24 IS CALM WIND RWY.
A110-9POWER LINES 2 MILES W & SW.
MC CLELLAN-PALOMAR (ICAO: KCRQ, IATA: CRQ) is a public airport located in CARLSBAD, CA.
