No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KCMY
SPARTA/FORT MC COY
PublicPUB

3 miles NE of SPARTA, WI
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
43° 57' 31"N 90° 44' 16"W
839' MSL
1839' MSL
00E
JET A+, CILI, 100LL
GREEN BAY (GRB)
CHICAGO
CHICAGO (ZAU)
4/17/25-5/15/25
KCMY VFR
3:55 AM CDT
Clear
10sm
38°F
37°F
30.30"Hg
Calm
AO2 SLP266 T00310028 52005
METAR KCMY 140855Z AUTO 00000KT 10SM CLR 03/03 A3030 RMK AO2 SLP266 T00310028 52005
+ Add Your Business

KCMY FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 124.6

ASOS

ASOS
 119.775

Emergency

EMERG
 121.5

Ground

GND/P
 123.625

Tower

LCL/P
 124.6

Other

OPS
RANGE INFO
 128.725
RANGE CTL
 30.05
RANGE CTL
 41.35
RANGE CTL
 134.1

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KVOK (21nm)
Tue, 10/14 4:00 AM CDT
Tue, 10/14 4:00 AM CDT - Wed, 10/15 10:00 AM CDT
VFR
4:00 AM CDT - 12:00 AM CDT
Scattered 15,000'
6sm
30.30"Hg
VRB° 6kts
MVFR
Becoming 12:00 AM CDT - 7:00 AM CDT
Light Showers and Rain
Overcast 5,000'
4.97sm
30.30"Hg
060° 9kts
VFR
Becoming 7:00 AM CDT - 10:00 AM CDT
Broken 7,000'
6sm
30.32"Hg
VRB° 6kts
TAF KVOK 140900Z 1409/1515 VRB06KT 9999 SCT150 QNH3030INS
   BECMG 1505/1506 06009KT 8000 -SHRA OVC050 QNH3031INS
   BECMG 1512/1513 VRB06KT 9999 NSW BKN070 QNH3033INS TX14/1421Z TN07/1411Z
KCMY
EffectiveExpiresCategoryNOTAM
Domestic
10/9/25
1700Z
10/9/25
1945Z
!CMY 10/004 CMY AIRSPACE SEE ZAU 10/024 AIRDROP 2510091700-2510091945
10/8/25
1700Z
10/8/25
1945Z
!CMY 10/003 CMY AIRSPACE SEE ZAU 10/025 AIRDROP 2510081700-2510081945
9/30/25
1917Z
12/31/25
2359Z
!CMY 09/033 CMY NAV NDB U/S 2509301917-2512312359
9/29/25
1434Z
12/26/25
2200Z
!CMY 09/032 CMY TWY D1 CLSD 2509291434-2512262200
9/29/25
1433Z
11/3/25
2200Z
!CMY 09/027 CMY SVC AUTOMATED WX BCST SYSTEM 119.775 U/S USE 124.6 2509291433-2511032200
9/29/25
1432Z
10/17/25
2200Z
!CMY 09/029 CMY TWY D EDGE LGT U/S 2509291432-2510172200
9/29/25
1432Z
12/26/25
2200Z
Runway!CMY 09/028 CMY RWY 01 PAPI U/S 2509291432-2512262200
9/29/25
1431Z
10/17/25
2200Z
!CMY 09/031 CMY TWY A BTN RWY 01/19 AND TWY C CLSD 2509291431-2510172200
9/29/25
1431Z
10/17/25
2100Z
!CMY 09/030 CMY TWY C CLSD 2509291431-2510172100
9/25/25
2257Z
12/25/25
2359Z
!CMY 09/024 CMY OBST TOWER LGT (ASR 1034243) 434801.50N0905401.80W (11.8NM SW CMY) 1657.8FT (299.9FT AGL) U/S 2509252257-2512252359
7/26/25
1112Z
12/1/25
2359Z
!CMY 07/029 CMY OBST POWER LINE LGT (ASN 2012-AGL-11500-OE) 435617N0903619W (5.8NM ESE CMY) 1334FT (77FT AGL) U/S 2507261112-2512012359
7/26/25
1112Z
12/1/25
2359Z
!CMY 07/028 CMY OBST POWER LINE LGT (ASN 2012-AGL-11499-OE) 435617N0903625W (5.8NM ESE CMY) 1277FT (105FT AGL) U/S 2507261112-2512012359
7/26/25
1111Z
12/1/25
2359Z
!CMY 07/027 CMY OBST POWER LINE LGT (ASN 2012-AGL-10095-OE) 435617N0903630W (5.7NM ESE CMY) 1240FT (107FT AGL) U/S 2507261111-2512012359
7/26/25
1110Z
12/1/25
2359Z
!CMY 07/026 CMY OBST POWER LINE LGT (ASN 2012-AGL-10094-OE) 435617N0903635W (5.7NM ESE CMY) 1210FT (84FT AGL) U/S 2507261110-2512012359
7/26/25
1110Z
12/1/25
2359Z
!CMY 07/025 CMY OBST POWER LINE LGT (ASN 2012-AGL-10093-OE) 435617N0903641W (5.6NM ESE CMY) 1195FT (89FT AGL) U/S 2507261110-2512012359
7/26/25
1109Z
12/1/25
2359Z
!CMY 07/024 CMY OBST POWER LINE LGT (ASN 2012-AGL-11498-OE) 435617N0903647W (5.5NM ESE CMY) 1190FT (105FT AGL) U/S 2507261109-2512012359
7/26/25
1109Z
12/1/25
2359Z
!CMY 07/023 CMY OBST POWER LINE LGT (ASN 2012-AGL-10091-OE) 435617N0903652W (5.5NM ESE CMY) 1194FT (84FT AGL) U/S 2507261109-2512012359
7/26/25
1108Z
12/1/25
2359Z
!CMY 07/022 CMY OBST POWER LINE LGT (ASN 2012-AGL-10090-OE) 435617N0903658W (5.4NM ESE CMY) 1196FT (80FT AGL) U/S 2507261108-2512012359
7/26/25
1107Z
12/1/25
2359Z
!CMY 07/021 CMY OBST POWER LINE LGT (ASN 2012-AGL-10089-OE) 435617N0903703W (5.3NM ESE CMY) 1184FT (80FT AGL) U/S 2507261107-2512012359
7/26/25
1106Z
12/1/25
2359Z
!CMY 07/020 CMY OBST POWER LINE LGT (ASN 2012-AGL-10088-OE) 435617N0903707W (5.3NM ESE CMY) 1180FT (85FT AGL) U/S 2507261106-2512012359
FDC
10/2/25
1145Z
!FDC 5/4831 CMY IAP SPARTA/FORT MC COY, SPARTA, WI.
RNAV (GPS) RWY 29, AMDT 2...
LPV DA NA. LNAV/VNAV DA NA. VDP NA. TEMPORARY CONSTRUCTION EQUIPMENT 867 MSL APCH END RWY 29 (2024-AGL-6138-NRA).
2510021145-2511071142EST
9/16/25
1840Z
!FDC 5/5186 CMY IAP SPARTA/FORT MC COY, SPARTA, WI.
RNAV (GPS) RWY 11, AMDT 1B...
LPV AND LNAV/VNAV MINIMUMS NA, VDP NA.
CHART NOTE: STRAIGHT-IN RWY 11 NA AT NIGHT, CIRCLING RWY 11, 19 NA AT NIGHT.
CHANGE NOTE TO READ: RWY 11 HELICOPTER VISIBILITY REDUCTION BELOW 1 SM NOT AUTHORIZED.
2509161840-2709161840EST
Military
9/29/25
1439Z
10/17/25
2100Z
AerodromeAERODROME AERODROME JET A SELF SERVICE FUEL NOT AVAILABLE. ROTARY WING COLD REFUEL AVAILABLE REQUEST 24 HOURS PRIOR. CALL OPS DESK 502-898-4107/3598
8/21/25
1450Z
11/14/25
2200Z
AerodromeAERODROME OBSTACLE CRANE 440103N0904121W (4NM NE KCMY) 1012FT (142FT AGL) FLAGGED. BOOM WILL BE LOWERED COB EACH DAILY.
Yes
MON-FRI 1400-2200Z++
EXCP FEDERAL HOLS.
U S ARMY
COMMANDER
FORT MC COY, WI 54656
Phone: 608-388-4207
JAMES HUBBARD
ATTN:AMIM-MCO-A
FORT MC COY, WI 54656
Phone: 608-388-4207
GREEN BAY FSS (GRB)
Toll Free: 1-800-WX-BRIEF
CMY
--
WHEN TWR CLSD, MIRL RWY 11/29 PRESET TO LOW SS-SR; TO INCR INTST MIRL RWY 11/29; ACTVT REIL RWY 11 & 29; MIRL RWY 01/19 - CTAF.
N/A
Yes - Lighted
No
No
Tie-Down
No
None
None
None
None
Pilot Instruction

Runway 01/19

3032 ft. x 95 ft.
ASPH
Good
NONE
MED
41 /F/A/W/T
--
--
--
--
  Runway 01 Runway 19
True Heading 15°195°
Traffic Pattern
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 43° 57' 11"N 43° 57' 40"N
Longitude 90° 44' 22"W 90° 44' 11"W
Elevation 839' 826'
Threshold Crossing Height 45 ft. AGL 45 ft. AGL
Visual Glide Path Angle 3.5° 3.5°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway 11/29

4697 ft. x 100 ft.
ASPH
Good
NONE
MED
54 /R/B/W/T
--
--
--
--
  Runway 11 Runway 29
True Heading 112°292°
Traffic Pattern
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 43° 57' 44"N 43° 57' 27"N
Longitude 90° 44' 46"W 90° 43' 46"W
Elevation 822' 832'
Threshold Crossing Height 42 ft. AGL 43 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes
A110-11RWY 01, 11, 29 NSTD SAFETY AREA BYD EACH END DUE TO TERRAIN GRADE AND FENCING. NSTD NORTH LATERAL CLEARANCE RWY 11/29; SEE KCMY AP/1 FOR FURTHER INFORMATION..
A110-13EXTSV VFR ASSAULT STRIP TFC EAST OF RY 11/29.
A110-14INTENSE PARADROP OPS INVOF 3.5 NM EAST-NORTHEAST OF AFLD YEAR ROUND.
A110-16RSTD: ARFF SVC AVBL UPON REQ WITH 72 HR NTC, INDEX B SVC AVBL H24. 72 HR NTC FOR REQ C502-898-2508/3553, WITH REQ.
A110-17FOR CD WHEN ATCT CLSD CTC CHICAGO ARTCC AT 630-906-8921.
A110-2OCCASIONAL WILDGAME & BIRDS ON & INVOF ARPT.
A110-324 HR PPR RQRD BY ALL FOR SVC AFTER 2200Z++ AND WKENDS; C502-898-4107; CLSD FEDERAL HOL AND OTHER TIMES BY NOTAM; R/W HOT PIT AVBL TO TRAINED AIRCREWS ONLY. FOR FURTHER FUEL AND TRAINING REQUIREMENTS REFER TO AP1.
A110-4FICONS NOT MONITORED AFT HRS.
A110-5SNOW REMOVAL EQUIP OPRS MONITOR CTAF WHEN ATCT CLOSED.
A110-6SUPPLEMENTARY LGTD WINDCONES RY 11 & 01.
A110-7RAPIDLY RISING TERRAIN 1 NM NORTHWEST TO NORTHEAST OF ARPT.
A110-8ACFT C130 AND LRGR, 180 DEG TURNS ALLOWED ONLY ON CONC SFC AT EAST AND WEST ENDS OF RWY 11/29 AND SOUTH END RWY 01/19 CONC SFC.
A110-9R6901B 500 YDS DEP END RY 11.
SPARTA/FORT MC COY (ICAO: KCMY, IATA: CMY) is a public airport located in SPARTA, WI.
