4/17/251357Z
|
!FDC 5/8033 CLS PART 1 OF 2 ODP CHEHALIS-CENTRALIA, CHEHALIS, WA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKE-OFF MINIMUMS RWY 16 400-2 3/4 OR STANDARD WITH MINIMUM CLIMB
OF 264 FT/NM TO 700.
NOTE: RWY 16: NAVAID 39 FT FROM DER, 115 FT LEFT OF CENTERLINE, 178
FT MSL. POLE, TREES BEGINNING 136 FT FROM DER, 13 FT LEFT OF
CENTERLINE, UP TO 49 FT AGL/233 FT MSL. TREES BEGINNING 597 FT FROM
DER, 11 FT RIGHT OF CENTERLINE, UP TO 241 FT MSL. TREES BEGINNING
1052 FT FROM DER, 203 FT LEFT OF CENTERLINE, UP TO 246 FT MSL. TREE
1309 FT FROM DER, 571 FT LEFT OF CENTERLINE, 248 FT MSL. TREES,
BUILDING BEGINNING 1392 FT FROM DER, 13 FT LEFT OF CENTERLINE, UP
TO 300 FT MSL. TREE 1573 FT FROM DER, 897 FT RIGHT OF CENTERLINE,
268 FT MSL. TREES, BUILDING BEGINNING 1668 FT FROM DER, 16 FT RIGHT
OF CENTERLINE, UP TO 298 FT MSL. TREES BEGINNING 2956 FT FROM DER,
563 FT RIGHT OF CENTERLINE, UP TO 303 FT MSL. TREES BEGINNING 3533
FT FROM DER, 22 FT RIGHT OF CENTERLINE, UP TO 305 FT MSL. TREE 3843
FT FROM DER, 44 FT LEFT OF CENTERLINE, 302 FT MSL. TREES BEGINNING
3915 FT FROM DER, 78 FT RIGHT OF CENTERLINE, UP TO 315 FT MSL.
TREES BEGINNING 4223 FT FROM DER, 394 FT LEFT OF CENTERLINE, UP TO
315 FT MSL. TREES BEGINNING 4612 FT FROM DER, 271 FT RIGHT OF
CENTERLINE, UP TO 328 FT MSL. TREE 1 NM FROM DER, 1599 FT RIGHT OF
ALL OTHER DATA REMAINS AS PUBLISHED. 2504171357-2704171357EST
END PART 1 OF 2
!FDC 5/8033 CLS PART 2 OF 2 ODP CHEHALIS-CENTRALIA, CHEHALIS, WA.
CENTERLINE, 344 FT MSL. TREE 1.8 NM FROM DER, 130 FT LEFT OF
CENTERLINE, 510 FT MSL. TREE 1.8 NM FROM DER, 776 FT RIGHT OF
CENTERLINE, 471 FT MSL. TREES BEGINNING 1.9 NM FROM DER, 770 FT
RIGHT OF CENTERLINE, UP TO 518 FT MSL. TREE 2.1 NM FROM DER, 2451
FT RIGHT OF CENTERLINE, 530 FT MSL. TREE 2.1 NM FROM DER, 912 FT
LEFT OF CENTERLINE, 536 FT MSL.
NOTE: RWY 34: NAVAID 10 FT FROM DER, 144 FT RIGHT OF CENTERLINE,
173 FT MSL. TREES BEGINNING 2016 FT FROM DER, 24 FT RIGHT OF
CENTERLINE, UP TO 317 FT MSL. TREE 2088 FT FROM DER, 210 FT LEFT OF
CENTERLINE, 228 FT MSL. TREES BEGINNING 2100 FT FROM DER, 176 FT
LEFT OF CENTERLINE, UP TO 236 FT MSL. TREES BEGINNING 2809 FT FROM
DER, 80 FT LEFT OF CENTERLINE, UP TO 254 FT MSL. TREES BEGINNING
3019 FT FROM DER, 6 FT LEFT OF CENTERLINE, UP TO 258 FT MSL.
BUILDING 1.1 NM FROM DER, 1968 FT LEFT OF CENTERLINE, 8 FT AGL/357
FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2504171357-2704171357EST
END PART 2 OF 2
|
