KCIU
CHIPPEWA COUNTY INTL
PublicPUB

15 miles S of SAULT STE MARIE, MI
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
46° 15' 03"N 84° 28' 21"W
799' MSL
1599' MSL
07W
JET A, 100LL
GREEN BAY (GRB)
LAKE HURON
MINNEAPOLIS (ZMP)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

KCIU FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
123.0 123.0

AWOS-3PT

AWOS-3PT
906-495-1156
 127.575

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

No TAF is available for this location.
KCIU
Domestic
1/15/251032Z !CIU 01/387 CIU TWY E FICON PATCHY COMPACTED SN AND 1/4IN DRY SN 40FT WID REMAINDER COMPACTED SN OBS AT 2501151032. 2501151032-2501152330
1/15/251031Z !CIU 01/386 CIU RWY 16 FICON 4/4/4 100 PCT 1/8IN DRY SN 125FT WID REMAINDER 8IN DRY SN OVER COMPACTED SN OBS AT 2501151031. 2501151031-2501152330
1/15/251031Z !CIU 01/385 CIU TWY B FICON COMPACTED SN AND 1/4IN DRY SN 40FT WID REMAINDER 3IN DRY SN OVER COMPACTED SN OBS AT 2501151031. 2501151031-2501152330
1/15/251030Z !CIU 01/384 CIU TWY A FICON PATCHY COMPACTED SN AND 1/4IN DRY SN 40FT WID REMAINDER 4IN DRY SN OVER COMPACTED SN OBS AT 2501151030. 2501151030-2501152330
1/15/251029Z !CIU 01/383 CIU RWY 10 FICON 3/3/3 100 PCT 1/8IN DRY SN 50FT WID REMAINDER COMPACTED SN OBS AT 2501151029. 2501151029-2501152330
11/29/242234Z !CIU 11/091 CIU OBST TOWER LGT (ASR 1277488) 462132.30N0844727.10W (14.7NM WNW CIU) 1299.9FT (402.9FT AGL) U/S 2411292234-2503292234
11/21/241746Z !CIU 11/008 CIU TWY E BTN APCH END RWY 16 AND APCH END RWY 10 CLSD 2411211746-2504150300
11/21/241745Z !CIU 11/007 CIU TWY B1 BTN RWY 16/34 AND TWY B CLSD 2411211745-2504150300
FDC
1/11/250207Z !FDC 5/2457 CIU IAP CHIPPEWA COUNTY INTL, SAULT STE MARIE, MI.
ILS OR LOC RWY 16, AMDT 8G...
TACAN ONLY EQUIPPED AIRCRAFT: PROCEDURE NA, EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS.,
SSM DME OUT OF SERVICE. 2501110207-2501170207EST
No
0600-1800
CHIPPEWA COUNTY ECON DEV CORP
5019 W AIRPORT DR
KINCHELOE, MI 49788-1643
Phone: 906-495-5631
TAMI L BESEAU
5019 W AIRPORT DR
KINCHELOE, MI 49788-1643
Phone: 906-495-5631
GREEN BAY FSS (GRB)
Toll Free: 1-800-WX-BRIEF
CIU
--
ACTVT MALSR RWY 16; REIL RWY 34, 10, & 28; PAPI RWY 16, 34, 10, & 28; HIRL RWY 16/34; MIRL RWY 10/28 - CTAF. REIL & PAPI RWY 34 OPR CONSLY DEC-MAR; PAPI RWY 10 & 28 OPR CONSLY DRG DALGT HRS.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
None

Runway 10/28

5001 ft. x 75 ft.
ASPH
Good
GRVD
MED

55,000lbs
88,000lbs
155,000lbs
--
  Runway 10 Runway 28
True Heading 90°270°
Traffic Pattern
Markings NPI NPI
Markings Condition FAIR FAIR
Latitude 46° 15' 18"N 46° 15' 18"N
Longitude 84° 29' 03"W 84° 27' 52"W
Elevation 792' 799'
Threshold Crossing Height 40 ft. AGL 40 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes

Runway 16/34

7203 ft. x 150 ft.
ASPH CONC
Fair
GRVD
HIGH

120,000lbs
215,000lbs
369,000lbs
855,000lbs
  Runway 16 Runway 34
True Heading 150°330°
Traffic Pattern Right
Markings PIR PIR
Markings Condition FAIR FAIR
Latitude 46° 15' 23"N 46° 14' 21"N
Longitude 84° 28' 41"W 84° 27' 50"W
Elevation 798' 793'
Threshold Crossing Height 57 ft. AGL 41 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSR
Centerline Lights No No
Runway End Identifier Lights No Yes
A110-1BIRDS ON & INVOF ARPT.
A110-3EXP SNOW REMOVAL ACT DLY DEC-MAR.
A110-5VEHICLE TESTING INPR DRG WINTER MONTHS ON SECTIONS OF CLSD/ABNDD PARL TWY, SE OF APCH END RWY 34. AREA MAY BE PLOWED TO BARE SFC BUT UNAVBL FOR ARR OR DEP.
A110-6FICONS UNMON 2100-0700.
A110-7FOR CD IF UNA TO CTC ON FSS FREQ, CTC MINNEAPOLIS ARTCC AT 651-463-5588.
CHIPPEWA COUNTY INTL (ICAO: KCIU, IATA: CIU) is a public airport located in SAULT STE MARIE, MI.
