No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KCIN
ARTHUR N NEU
PublicPUB

4 miles SE of CARROLL, IA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
42° 02' 48"N 94° 47' 19"W
1204' MSL
2204' MSL
02E
JET A, 100LL
FORT DODGE (FOD)
OMAHA
MINNEAPOLIS (ZMP)
10/31/24-11/28/24
KCIN VFR
5:35 AM CST
Broken 11,000'
Broken 7,500'
Broken 6,500'
10sm
46°F
45°F
30.08"Hg
120° 10kts
AO2
KCIN 091135Z AUTO 12010KT 10SM BKN065 BKN075 BKN110 08/07 A3008 RMK AO2
Add Your Business

KCIN FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

AWOS-3

AWOS-3
712-792-2306
 118.025

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KFOD (41nm)
Sat, 11/9 5:20 AM CST
Sat, 11/9 6:00 AM CST - Sun, 11/10 6:00 AM CST
VFR
6:00 AM CST - 9:00 AM CST
Overcast 15,000'
6sm
110° 8kts
MVFR
9:00 AM CST - 12:00 PM CST
Light Showers and Rain
Overcast 4,000'
4sm
130° 12kts
Gusts 22kts
MVFR
12:00 PM CST - 2:00 PM CST
Light Showers and Rain
Overcast 2,500'
4sm
130° 13kts
Gusts 23kts
IFR
2:00 PM CST - 2:00 AM CST
Overcast 800'
6sm
130° 13kts
Gusts 23kts
IFR
2:00 AM CST - 6:00 AM CST
Light Showers and Rain
Overcast 800'
5sm
170° 6kts
KFOD 091120Z 0912/1012 11008KT P6SM OVC150
   FM091500 13012G22KT 4SM -SHRA OVC040
   FM091800 13013G23KT 4SM -SHRA OVC025
   FM092000 13013G23KT P6SM OVC008
   FM100800 17006KT 5SM -SHRA OVC008
KCIN
Domestic
11/5/240456Z !CIN 11/003 CIN OBST TOWER LGT (ASR 1017878) 420721.00N0945656.00W (8.5NM WNW CIN) 1782.8FT (442.9FT AGL) U/S 2411050456-2501062359
11/4/241046Z !CIN 11/002 CIN OBST TOWER LGT (ASR 1016904) 420209.00N0945401.00W (5.0NM W CIN) 1591.9FT (256.9FT AGL) U/S 2411041046-2412040001
11/1/242216Z !CIN 11/001 CIN OBST TOWER LGT (ASR 1245791) 420228.40N0943749.60W (7.1NM E CIN) 1439.0FT (315.0FT AGL) U/S 2411012216-2412162215
10/26/242329Z !CIN 10/004 CIN RWY 13/31 PAPI U/S 2410262329-2412312359
10/26/242329Z !CIN 10/003 CIN RWY 03/21 PAPI U/S 2410262329-2412312359
No
0800-DUSK
FOR SVC AFTER HOURS CALL 712-792-4980.
CITY OF CARROLL
627 NORTH ADAMS
CARROLL, IA 51401
Phone: 712-792-1000
DONALD MENSEN
21177 QUAIL AVE
CARROLL, IA 51401
Phone: 712-792-4980
FORT DODGE FSS (FOD)
Toll Free: 1-800-WX-BRIEF
CIN
--
DUSK-DAWN. MIRL RYS 13/31 & 03/21 PRESET ON LOW INTST; TO INCR INTST & ACTVT PAPI RYS 13/31 & 03/21 AND REIL RYS 13/31 & 03/21 - CTAF.
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
None
None
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 03/21

3301 ft. x 60 ft.
CONC
Good
NONE
MED
6 /R/D/W/T
--
--
--
--
  Runway 03 Runway 21
True Heading 30°210°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 42° 02' 37"N 42° 03' 05"N
Longitude 94° 47' 30"W 94° 47' 08"W
Elevation 1,202' 1,200'
Threshold Crossing Height 30 ft. AGL 32 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes

Runway 13/31

5506 ft. x 100 ft.
CONC
Good
NONE
MED
7 /R/B/W/T
30,000lbs
--
--
--
  Runway 13 Runway 31
True Heading 137°317°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 42° 03' 06"N 42° 02' 26"N
Longitude 94° 47' 44"W 94° 46' 54"W
Elevation 1,204' 1,203'
Threshold Crossing Height 26 ft. AGL 29 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes
A110-1RY 31 IS CALM WIND RY.
A110-2FOR CD CTC MINNEAPOLIS ARTCC AT 651-463-5588.
ARTHUR N NEU (ICAO: KCIN, IATA: CIN) is a public airport located in CARROLL, IA.
