No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KCHD
CHANDLER MUNI
PublicPUB

3 miles SE of CHANDLER, AZ
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
33° 16' 09"N 111° 48' 40"W
1243' MSL
2300' MSL
12E
JET A (FSII), 100LL
PRESCOTT (PRC)
PHOENIX
ALBUQUERQUE (ZAB)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

KCHD FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 126.1

ATIS

ATIS
 128.325

Ground

GND/P
 124.4

Tower

LCL/P
ARR N &W
 126.1
LCL/P
DEP RWY 04L/22R
 126.1
LCL/P
ARR S & E
 133.1
LCL/P
DEP RWY 04R/22L
 133.1

Terminal Area Forecast

No TAF is available for this location.
KCHD
Domestic
1/11/251951Z !CHD 01/032 CHD OBST DRILL RIG (ASN 2024-AWP-13953-OE) 331659N1114858W (0.9NM NNW CHD) 1328FT (75FT AGL) 2501111951-2505030100
1/8/251400Z !CHD 01/017 CHD OBST CRANE (ASN 2024-AWP-9623-OE) 331450N1114526W (3.0NM ESE CHD) 1535FT (250FT AGL) FLAGGED AND LGTD 2501081400-2503212359
12/22/240320Z !CHD 12/056 CHD OBST TOWER LGT (ASR 1210712) 331619.20N1114424.50W (3.6NM E CHD) 1567.9FT (270.0FT AGL) U/S 2412220320-2502050319
11/27/241500Z !CHD 11/082 CHD RWY 04R PAPI U/S 2411271500-2501312359
9/13/242231Z !CHD 09/021 CHD TWY A BTN TWY D AND TWY H CLSD ENGINE RUN-UPS 2409132231-PERM
FDC
1/13/251748Z !FDC 5/2912 CHD IAP CHANDLER MUNI, CHANDLER, AZ.
RNAV (GPS) RWY 4R, AMDT 1...
CIRCLING MDA CAT A 1760/HAA 517, CAT C MDA 1900/HAA 657, VIS CAT C 1 3/4. TEMPORARY CRANE 1403FT MSL 5273FT N OF CHD AIRPORT (2024-AWP-13953-OE), TEMPORARY CRANE 1535 MSL 3.0NM SE OF CHD AIRPORT (2024-AWP-9623-OE).
2501131748-2505151748EST
1/10/250318Z !FDC 5/2079 CHD IAP CHANDLER MUNI, CHANDLER, AZ.
VOR RWY 4R, ORIG-B...
VOR PORTION NA,
IWA VOR OUT OF SERVICE. 2501100318-2502100318EST
1/6/251323Z !FDC 5/0612 CHD IAP CHANDLER MUNI, CHANDLER, AZ.
VOR RWY 4R, ORIG-B...
S-4R CAT A/B/C MDA 1960/HAT 720, VIS CAT C 2.
CIRCLING CAT A/B/C MDA 1960/HAA 717, VIS CAT C 2.
VDP AT 10.62 DME; DISTANCE VDP TO THLD 2.14 MILES.
TEMPORARY CRANES UP TO 1653 MSL BEGINNING 4.0NM W OF RWY 4R (2024-AWP-12427 THRU 12430-OE), TEMPORARY CRANE 1491 MSL 4.0 NM W OF RWY 4R (2024-AWP-252-OE), TEMPORARY CRANE 1535 MSL 3.0NM SE OF CHD AIRPORT (2024-AWP-9623-OE).
2501061323-2507011323EST
Yes
MON-FRI 0500-1700
SAT-SUN 0500-1530
CITY OF CHANDLER
175 S. ARIZONA AVE
CHANDLER, AZ 85225
Phone: 480-782-2200
RYAN REEVES
CHANDLER MUNICIPAL AIRPORT, MS 802, PO BOX 4008
CHANDLER, AZ 85244
Phone: 480-782-3540
PRESCOTT FSS (PRC)
Toll Free: 1-800-WX-BRIEF
CHD
--
WHEN ATCT CLSD ACTVT PAPI RWY 04L, 04R, 22L & 22R; MIRL RWY 04R/22L & 04L/22R - CTAF. REIL RWY 4R & 22L ON CONSLY.
N/A
Yes - Lighted
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
High & Low Pressure
High & Low Pressure
Avionics
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 04L/22R

4401 ft. x 75 ft.
ASPH
Good
NONE
MED

30,000lbs
--
--
--
  Runway 04L Runway 22R
True Heading 50°230°
Traffic Pattern Right
Markings BSC BSC
Markings Condition FAIR FAIR
Latitude 33° 15' 51"N 33° 16' 19"N
Longitude 111° 49' 12"W 111° 48' 32"W
Elevation 1,231' 1,236'
Threshold Crossing Height 48 ft. AGL 40 ft. AGL
Visual Glide Path Angle 3.5° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights No No
Runway End Identifier Lights

Runway 04R/22L

4870 ft. x 75 ft.
ASPH
Good
NONE
MED

30,000lbs
--
--
--
  Runway 04R Runway 22L
True Heading 50°230°
Traffic Pattern Right
Markings NPI NPI
Markings Condition GOOD FAIR
Latitude 33° 15' 57"N 33° 16' 28"N
Longitude 111° 48' 51"W 111° 48' 07"W
Elevation 1,236' 1,243'
Threshold Crossing Height 39 ft. AGL 45 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes

Runway H1

100 ft. x 100 ft.
CONC
Excellent
NONE


--
--
--
--
  Runway H1 Runway
True Heading 78°258°
Traffic Pattern
Markings BSC
Markings Condition GOOD
Latitude 33° 16' 25"N N/A
Longitude 111° 47' 58"W N/A
Elevation 1,236' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-10135 FT LGTD PWR POLES & LINES N-S 1.5 MI W.
A110-11135 FT UNLGTD PWR POLES & LINES E-W 1 MI S.
A110-13TWY A BTN TWY D & F NOT VIS FM ATCT.
A110-15TSNT HELI PRKG & PAX PUP N SIDE BY TWY N.
A110-17HOPS ON TWY C; CHARLIE PAT FOR HEL TRNG.
A110-18WHEN ATCT CLSD, FOR CD CTC PHOENIX APCH - 602-306-2565.
A110-19GA TSNT FIXED WING PRKG BOXES IN FRONT OF TRML.
A110-2BIRDS & WILDLIFE ON & INVOF OF ARPT.
A110-20PARL RWYS; STAGGERED APCH ENDS.
A110-9AVOID OVERFLIGHT OF HIGH SCHOOL 2 NM SW.
CHANDLER MUNI (ICAO: KCHD, IATA: CHD) is a public airport located in CHANDLER, AZ.
