9/8/25 1619Z | 9/8/27 1619Z | | !FDC 5/9593 BTR PART 1 OF 6 ODP BATON ROUGE METRO,
RYAN FLD, BATON ROUGE, LA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1B...
CHANGE TAKEOFF OBSTACLE NOTES TO READ:
NOTE: RWY 4L: LIGHT POLES BEGINNING 9 FT FROM DER, 4 FT RIGHT OF
CENTERLINE, UP TO 1 FT AGL/71 FT MSL.
POLE 632 FT FROM DER, 470 FT LEFT OF CENTERLINE, 34 FT AGL/92 FT
MSL.
TREES BEGINNING 1052 FT FROM DER, 507 FT LEFT OF CENTERLINE, UP TO
108 FT MSL.
TREE 1229 FT FROM DER, 585 FT LEFT OF CENTERLINE, 129 FT MSL.
TREE 1260 FT FROM DER, 729 FT LEFT OF CENTERLINE, 137 FT MSL.
TREE 1407 FT FROM DER, 609 FT LEFT OF CENTERLINE, 138 FT MSL.
TREES BEGINNING 1411 FT FROM DER, 312 FT LEFT OF CENTERLINE, UP TO
147 FT MSL.
TREES BEGINNING 1591 FT FROM DER, 273 FT RIGHT OF CENTERLINE, UP TO
140 FT MSL.
TRANSMISSION LINE 2516 FT FROM DER, 897 FT LEFT OF CENTERLINE, 92
FT AGL/149 FT MSL.
NOTE: RWY 4R: LIGHT POLES BEGINNING 9 FT FROM DER, 16 FT LEFT OF
CENTERLINE, UP TO 1 FT AGL/70 FT MSL.
TRAVERSE WAYS BEGINNING 51 FT FROM DER, 455 FT RIGHT OF CENTERLINE,
ALL OTHER DATA REMAINS AS PUBLISHED. 2509081619-2709081619EST
END PART 1 OF 6
!FDC 5/9593 BTR PART 2 OF 6 ODP BATON ROUGE METRO,
RYAN FLD, BATON ROUGE, LA.
UP TO 82 FT MSL.
TREE 1867 FT FROM DER, 764 FT RIGHT OF CENTERLINE, 116 FT MSL.
TREE 2579 FT FROM DER, 214 FT RIGHT OF CENTERLINE, 140 FT MSL.
TERRAIN BEGINNING 5289 FT FROM DER, 1812 FT RIGHT OF CENTERLINE, UP
TO 266 FT MSL.
NOTE: RWY 13: LIGHT POLES BEGINNING 61 FT FROM DER, 14 FT LEFT OF
CENTERLINE, UP TO 2 FT AGL/71 FT MSL.
LIGHT POLES BEGINNING 61 FT FROM DER, 14 FT RIGHT OF CENTERLINE, UP
TO 2 FT AGL/71 FT MSL.
POLE, TRAVERSE WAYS BEGINNING 300 FT FROM DER, 136 FT LEFT OF
CENTERLINE, UP TO 25 FT AGL/91 FT MSL.
BUILDING 478 FT FROM DER, 247 FT RIGHT OF CENTERLINE, 26 FT AGL/91
FT MSL.
SIGN 968 FT FROM DER, 740 FT RIGHT OF CENTERLINE, 32 FT AGL/100 FT
MSL.
TREE 1624 FT FROM DER, 677 FT RIGHT OF CENTERLINE, 118 FT MSL.
TREE 1690 FT FROM DER, 485 FT RIGHT OF CENTERLINE, 125 FT MSL.
TREE 1778 FT FROM DER, 275 FT RIGHT OF CENTERLINE, 128 FT MSL.
TREE 1783 FT FROM DER, 108 FT RIGHT OF CENTERLINE, 132 FT MSL.
TREE 1804 FT FROM DER, 215 FT RIGHT OF CENTERLINE, 134 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2509081619-2709081619EST
END PART 2 OF 6
!FDC 5/9593 BTR PART 3 OF 6 ODP BATON ROUGE METRO,
RYAN FLD, BATON ROUGE, LA.
TREES BEGINNING 1805 FT FROM DER, 45 FT LEFT OF CENTERLINE, UP TO
123 FT MSL.
TREES BEGINNING 1838 FT FROM DER, 12 FT RIGHT OF CENTERLINE, UP TO
135 FT MSL.
TREES BEGINNING 1907 FT FROM DER, 40 FT LEFT OF CENTERLINE, UP TO
131 FT MSL.
TREE 2134 FT FROM DER, 205 FT RIGHT OF CENTERLINE, 145 FT MSL.
NOTE: RWY 22L: LIGHT POLES BEGINNING 9 FT FROM DER, 17 FT RIGHT OF
CENTERLINE, 2 FT AGL/68 FT MSL.
ANTENNA 313 FT FROM DER, 280 FT RIGHT OF CENTERLINE, 20 FT AGL/82
FT MSL.
TREES BEGINNING 2202 FT FROM DER, 44 FT LEFT OF CENTERLINE, UP TO
150 FT MSL.
TREE 3092 FT FROM DER, 94 FT LEFT OF CENTERLINE, 152 FT MSL.
SIGN 3508 FT FROM DER, 284 FT LEFT OF CENTERLINE, 105 FT AGL/163 FT
MSL.
TERRAIN BEGINNING 5469 FT FROM DER, 1879 FT LEFT OF CENTERLINE, UP
TO 266 FT MSL.
NOTE: RWY 22R: LIGHT POLES 9 FT FROM DER, 55 FT LEFT OF CENTERLINE,
1 FT AGL/66 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2509081619-2709081619EST
END PART 3 OF 6
!FDC 5/9593 BTR PART 4 OF 6 ODP BATON ROUGE METRO,
RYAN FLD, BATON ROUGE, LA.
LIGHT POLES 9 FT FROM DER, 54 FT RIGHT OF CENTERLINE, 1 FT AGL/66
FT MSL.
POLE, BUILDING BEGINNING 432 FT FROM DER, 449 FT RIGHT OF
CENTERLINE, UP TO 19 FT AGL/79 FT MSL.
POLE 760 FT FROM DER, 363 FT RIGHT OF CENTERLINE, 30 FT AGL/91 FT
MSL.
UTILITY BUILDING 903 FT FROM DER, 570 FT RIGHT OF CENTERLINE, 33 FT
AGL/94 FT MSL.
TREES, POLE BEGINNING 1009 FT FROM DER, 563 FT LEFT OF CENTERLINE,
UP TO 98 FT MSL.
TREE 1112 FT FROM DER, 695 FT LEFT OF CENTERLINE, 103 FT MSL.
TREE 1212 FT FROM DER, 523 FT LEFT OF CENTERLINE, 114 FT MSL.
TREE 1241 FT FROM DER, 763 FT LEFT OF CENTERLINE, 122 FT MSL.
TREE 1275 FT FROM DER, 645 FT LEFT OF CENTERLINE, 124 FT MSL.
TREES BEGINNING 1389 FT FROM DER, 370 FT LEFT OF CENTERLINE, UP TO
125 FT MSL.
POLES, TRAVERSE WAY, SIGN BEGINNING 1457 FT FROM DER, 81 FT RIGHT
OF CENTERLINE, UP TO 58 FT AGL/120 FT MSL.
TREES, POLE BEGINNING 1553 FT FROM DER, 77 FT LEFT OF CENTERLINE,
UP TO 130 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2509081619-2709081619EST
END PART 4 OF 6
!FDC 5/9593 BTR PART 5 OF 6 ODP BATON ROUGE METRO,
RYAN FLD, BATON ROUGE, LA.
TREES BEGINNING 1976 FT FROM DER, 42 FT RIGHT OF CENTERLINE, UP TO
139 FT MSL.
POLE, TREES BEGINNING 2290 FT FROM DER, 508 FT LEFT OF CENTERLINE,
UP TO 103 FT AGL/158 FT MSL.
TREES BEGINNING 2697 FT FROM DER, 114 FT RIGHT OF CENTERLINE, UP TO
142 FT MSL.
TREE 3302 FT FROM DER, 174 FT RIGHT OF CENTERLINE, 149 FT MSL.
TREE 3305 FT FROM DER, 279 FT RIGHT OF CENTERLINE, 154 FT MSL.
TREE 3698 FT FROM DER, 789 FT LEFT OF CENTERLINE, 166 FT MSL.
TREE 4029 FT FROM DER, 320 FT RIGHT OF CENTERLINE, 170 FT MSL.
SMOKESTACKS BEGINNING 1.6 NM FROM DER, 2394 FT LEFT OF CENTERLINE,
UP TO 301 FT AGL/352 FT MSL.
SMOKESTACK 1.8 NM FROM DER, 2499 FT LEFT OF CENTERLINE, 311 FT
AGL/366 FT MSL.
NOTE RWY 31: FENCE BEGINNING 175 FT FROM DER, 467 FT RIGHT OF
CENTERLINE, UP TO 7 FT AGL/73 FT MSL.
VEGETATION 552 FT FROM DER, 198 FT RIGHT OF CENTERLINE, 80 FT MSL.
TREE 799 FT FROM DER, 96 FT RIGHT OF CENTERLINE, 90 FT MSL.
TREE 829 FT FROM DER, 115 FT RIGHT OF CENTERLINE, 91 FT MSL.
TREE 951 FT FROM DER, 150 FT RIGHT OF CENTERLINE, 92 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2509081619-2709081619EST
END PART 5 OF 6
!FDC 5/9593 BTR PART 6 OF 6 ODP BATON ROUGE METRO,
RYAN FLD, BATON ROUGE, LA.
TREE 996 FT FROM DER, 166 FT RIGHT OF CENTERLINE, 94 FT MSL.
POLE 1353 FT FROM DER, 832 FT RIGHT OF CENTERLINE, 48 FT AGL/115 FT
MSL.
POLE 1544 FT FROM DER, 658 FT RIGHT OF CENTERLINE, 52 FT AGL/118 FT
MSL.
TANK 1862 FT FROM DER, 867 FT RIGHT OF CENTERLINE, 52 FT AGL/119 FT
MSL.
TRANSMISSION LINES, POLE BEGINNING 1962 FT FROM DER, 95 FT RIGHT OF
CENTERLINE, UP TO 58 FT AGL/123 FT MSL.
TREE 2248 FT FROM DER, 482 FT LEFT OF CENTERLINE, 131 FT MSL.
TREE 2289 FT FROM DER, 555 FT LEFT OF CENTERLINE, 132 FT MSL.
TRANSMISSION LINE, TREES BEGINNING 2340 FT FROM DER, 102 FT LEFT OF
CENTERLINE, UP TO 76 FT AGL/141 FT MSL.
POLES, TRANSMISSION LINES BEGINNING 2507 FT FROM DER, 274 FT LEFT
OF CENTERLINE, UP TO 75 FT AGL/142 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2509081619-2709081619EST
END PART 6 OF 6
|
