| Domestic |
|
5/19/250702Z
|
!BTA 05/017 BTA OBST TOWER LGT (ASR 1278004) 412845.90N0960839.10W (4.2NM NNW BTA) 1573.2FT (228.0FT AGL) U/S 2505190702-2509160702
|
|
5/12/250808Z
|
!BTA 05/007 BTA OBST TOWER LGT (ASR 1252240) 412238.80N0961728.40W (8.5NM WSW BTA) 1388.1FT (245.1FT AGL) U/S 2505120808-2508100400
|
| FDC |
|
4/8/251529Z
|
!FDC 5/3581 BTA PART 1 OF 2 ODP BLAIR EXEC, BLAIR, NE.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
CHANGE DEPARTURE PROCEDURE TO READ: RWY 13: CLIMB ON A HEADING
BETWEEN 314 CW TO 124 FROM DEPARTURE END OF RUNWAY OR MINIMUM CLIMB
OF 239 FT/NM TO 3000 FOR HEADINGS 125 THROUGH 313. CHANGE TAKEOFF
OBSTACLE NOTES TO READ: NOTE: RWY 13: NAVAID, LIGHT POLES BEGINNING
9 FT FROM DER, 29 FT RIGHT OF CENTERLINE, UP TO 2 FT AGL/1300 FT
MSL. LIGHT POLES BEGINNING 10 FT FROM DER, 60 FT LEFT OF
CENTERLINE, UP TO 1300 FT MSL. TERRAIN 46 FT FROM DER, 402 FT RIGHT
OF CENTERLINE, 1301 FT MSL. TREE 141 FT FROM DER, 489 FT LEFT OF
CENTERLINE, 1303 FT MSL. TREE 1528 FT FROM DER, 751 FT LEFT OF
CENTERLINE, 1339 FT MSL. POLE 1928 FT FROM DER, 415 FT LEFT OF
CENTERLINE, 1350 FT MSL. TREE, POLES BEGINNING 2018 FT FROM DER,
171 FT LEFT OF CENTERLINE, UP TO 1358 FT MSL. TREE 2213 FT FROM
DER, 841 FT LEFT OF CENTERLINE, 1359 FT MSL. NOTE: RWY 31: NAVAID,
LIGHT POLES BEGINNING 9 FT FROM DER, 29 FT LEFT OF CENTERLINE, UP
TO 2 FT AGL/1319 FT MSL. LIGHT POLES, TERRAIN BEGINNING 9 FT FROM
DER, 29 FT RIGHT OF CENTERLINE, UP TO 1319 FT MSL. TERRAIN 140 FT
FROM DER, 362 FT RIGHT OF CENTERLINE, 1322 FT MSL. TERRAIN 183 FT
FROM DER, 452 FT RIGHT OF CENTERLINE, 1323 FT MSL. TREES BEGINNING
699 FT FROM DER, 583 FT LEFT OF CENTERLINE, UP TO 1350 FT MSL.
ORIG-A. 2504081529-PERM
END PART 1 OF 2
!FDC 5/3581 BTA PART 2 OF 2 ODP BLAIR EXEC, BLAIR, NE.
TREES BEGINNING 864 FT FROM DER, 574 FT LEFT OF CENTERLINE, UP TO
35 FT AGL/1353 FT MSL. TREE 1274 FT FROM DER, 571 FT LEFT OF
CENTERLINE, 32 FT AGL/1354 FT MSL. POLE 1631 FT FROM DER, 891 FT
RIGHT OF CENTERLINE, 35 FT AGL/1363 FT MSL. TREES BEGINNING 1653 FT
FROM DER, 22 FT LEFT OF CENTERLINE, UP TO 1375 FT MSL. TREE 1818 FT
FROM DER, 401 FT RIGHT OF CENTERLINE, 1376 FT MSL. TREE 1911 FT
FROM DER, 491 FT RIGHT OF CENTERLINE, 1377 FT MSL. TREES BEGINNING
1996 FT FROM DER, 562 FT RIGHT OF CENTERLINE, UP TO 1378 FT MSL.
TREES BEGINNING 2299 FT FROM DER, 162 FT RIGHT OF CENTERLINE, UP TO
1384 FT MSL. TREE 2507 FT FROM DER, 177 FT LEFT OF CENTERLINE, 1382
FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED.
THIS IS TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES, AMDT
ORIG-A. 2504081529-PERM
END PART 2 OF 2
|
|
10/30/231658Z
|
!FDC 3/3757 BTA PART 1 OF 2 ODP BLAIR EXEC, BLAIR, NE.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
CHANGE TAKEOFF OBSTACLE NOTES TO READ:
NOTE: RWY 13: NAVAID, LIGHT POLES BEGINNING 9 FT FROM DER, 29 FT
RIGHT OF CENTERLINE, UP TO 2 FT AGL/1300 FT MSL.
LIGHT POLES BEGINNING 10 FT FROM DER, 60 FT LEFT OF CENTERLINE, UP
TO 1300 FT MSL.
TERRAIN 46 FT FROM DER, 402 FT RIGHT OF CENTERLINE, 1301 FT MSL.
TREE 141 FT FROM DER, 489 FT LEFT OF CENTERLINE, 1303 FT MSL.
TREE 1528 FT FROM DER, 751 FT LEFT OF CENTERLINE, 1339 FT MSL.
POLE 1928 FT FROM DER, 415 FT LEFT OF CENTERLINE, 1350 FT MSL.
TREE, POLES BEGINNING 2018 FT FROM DER, 171 FT LEFT OF CENTERLINE,
UP TO 1358 FT MSL.
TREE 2213 FT FROM DER, 841 FT LEFT OF CENTERLINE, 1359 FT MSL.
NOTE: RWY 31: NAVAID, LIGHT POLES BEGINNING 9 FT FROM DER, 29 FT
LEFT OF CENTERLINE, UP TO 2 FT AGL/1319 FT MSL.
LIGHT POLES, TERRAIN BEGINNING 9 FT FROM DER, 29 FT RIGHT OF
CENTERLINE, UP TO 1319 FT MSL.
TERRAIN 140 FT FROM DER, 362 FT RIGHT OF CENTERLINE, 1322 FT MSL.
TERRAIN 183 FT FROM DER, 452 FT RIGHT OF CENTERLINE, 1323 FT MSL.
TREES BEGINNING 699 FT FROM DER, 583 FT LEFT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2310301658-2510301657EST
END PART 1 OF 2
!FDC 3/3757 BTA PART 2 OF 2 ODP BLAIR EXEC, BLAIR, NE.
1350 FT MSL.
TREES BEGINNING 864 FT FROM DER, 574 FT LEFT OF CENTERLINE, UP TO
35 FT AGL/1353 FT MSL.
TREE 1274 FT FROM DER, 571 FT LEFT OF CENTERLINE, 32 FT AGL/1354 FT
MSL.
POLE 1631 FT FROM DER, 891 FT RIGHT OF CENTERLINE, 35 FT AGL/1363
FT MSL.
TREES BEGINNING 1653 FT FROM DER, 22 FT LEFT OF CENTERLINE, UP TO
1375 FT MSL.
TREE 1818 FT FROM DER, 400 FT RIGHT OF CENTERLINE, 1376 FT MSL.
TREE 1911 FT FROM DER, 491 FT RIGHT OF CENTERLINE, 1377 FT MSL.
TREES BEGINNING 1996 FT FROM DER, 562 FT RIGHT OF CENTERLINE, UP TO
1378 FT MSL.
TREES BEGINNING 2299 FT FROM DER, 162 FT RIGHT OF CENTERLINE, UP TO
1384 FT MSL.
TREE 2507 FT FROM DER, 177 FT LEFT OF CENTERLINE, 1382 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2310301658-2510301657EST
END PART 2 OF 2
|
