KBHM
BIRMINGHAM-SHUTTLESWORTH INTL
PublicPUB

4 miles NE of BIRMINGHAM, AL
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
33° 33' 50"N 86° 45' 08"W
650' MSL
1650' MSL
03W
JET A, 100LL
ANNISTON (ANB)
ATLANTA
ATLANTA (ZTL)
10/31/24-11/28/24
KBHM VFR
5:53 AM CST
Overcast 15,000'
Broken 4,000'
10sm
66°F
59°F
30.11"Hg
080° 7kts
AO2 SLP189 T01890150 10200 20189 51005
KBHM 091153Z 08007KT 10SM BKN040 OVC150 19/15 A3011 RMK AO2 SLP189 T01890150 10200 20189 51005
Add Your Business

KBHM FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 --

ATIS

ATIS
 119.4

Approach/Departure

APCH/P DEP/P
231-049
 127.675
APCH/P DEP/P IC
050-230
 123.8

Clearance Delivery

CD PRE TAXI CLNC
 125.675

Emergency

EMERG
 121.5

Ground

GND/P
 121.7

Tower

LCL/P
 119.9
LCL/S
 118.25

Other

CLASS C
050-230
 123.8
CLASS C
231-049
 127.675

Terminal Area Forecast

KBHM
Sat, 11/9 5:22 AM CST
Sat, 11/9 6:00 AM CST - Sun, 11/10 6:00 AM CST
VFR
6:00 AM CST - 9:00 AM CST
Broken 6,000'
6sm
080° 5kts
MVFR
9:00 AM CST - 12:00 PM CST
Broken 2,200'
6sm
100° 7kts
MVFR
12:00 PM CST - 3:00 PM CST
Showers in vicinity
Broken 2,700'
6sm
110° 9kts
VFR
3:00 PM CST - 12:00 AM CST
Broken 3,500'
6sm
110° 9kts
MVFR
3:00 PM CST - 9:00 PM CST
Light Showers and Rain and Mist
Overcast 2,500'
4sm
Calm
MVFR
12:00 AM CST - 6:00 AM CST
Overcast 2,200'
6sm
120° 10kts
Gusts 19kts
IFR
3:00 AM CST - 6:00 AM CST
Light Showers and Rain and Mist
Overcast 800'
4sm
Calm
KBHM 091122Z 0912/1012 08005KT P6SM BKN060
   FM091500 10007KT P6SM BKN022
   FM091800 11009KT P6SM VCSH BKN027
   FM092100 11009KT P6SM BKN035
   PROB30 0921/1003 4SM -SHRA BR OVC025
   FM100600 12010G19KT P6SM OVC022
   PROB30 1009/1012 4SM -SHRA BR OVC008
KBHM
Domestic
11/5/240615Z !BHM 11/019 BHM RWY 06/24 CLSD EXC 1HR PPR DLY 0615-1015 2411050615-2411111015
11/5/240335Z !BHM 11/021 BHM OBST TOWER LGT (ASR 1009818) 334028.00N0865739.00W (12.3NM WNW BHM) 669.9FT (254.9FT AGL) U/S 2411050335-2502020500
11/1/241500Z !BHM 11/007 BHM NAV ILS RWY 24 CAT II NA 2411011500-2411082000EST
11/1/241459Z !BHM 11/006 BHM RWY 24 ALS U/S 2411011459-2411082000EST
10/29/240425Z !BHM 10/169 BHM OBST TOWER LGT (ASR 1300774) 333058.30N0864504.70W (2.9NM S BHM) 1122.0FT (160.1FT AGL) U/S 2410290425-2411130325
10/28/241121Z !BHM 10/165 BHM RWY 36 RWY END ID LGT U/S 2410281121-2411152000EST
10/24/241049Z !BHM 10/142 BHM RWY 24 PAPI HIGH INTST U/S 2410241049-2505292000EST
10/22/241200Z !BHM 10/121 BHM OBST RIG (ASN 2024-ASO-9158-NRA) 333336N0864521W (0.3NM SW BHM) 619FT (15FT AGL) FLAGGED AND LGTD 2410221200-2411182300
10/22/241200Z !BHM 10/120 BHM OBST RIG (ASN 2024-ASO-9155-NRA) 333353N0864505W (0.1NM NE BHM) 624FT (15FT AGL) FLAGGED AND LGTD 2410221200-2411182300
10/22/241200Z !BHM 10/119 BHM OBST RIG (ASN 2024-ASO-9154-NRA) 333346N0864457W (0.2NM ESE BHM) 624FT (15FT AGL) FLAGGED AND LGTD 2410221200-2411182300
10/22/241200Z !BHM 10/118 BHM OBST RIG (ASN 2024-ASO-9151-NRA) 333351N0864457W (0.2NM E BHM) 624FT (15FT AGL) FLAGGED AND LGTD 2410221200-2411182300
10/22/241200Z !BHM 10/117 BHM OBST RIG (ASN 2024-ASO-9148-NRA) 333342N0864524W (0.3NM WSW BHM) 618FT (15FT AGL) FLAGGED AND LGTD 2410221200-2411182300
10/22/241200Z !BHM 10/116 BHM OBST RIG (ASN 2024-ASO-9146-NRA) 333349N0864512W (0.1NM WSW BHM) 620FT (15FT AGL) FLAGGED AND LGTD 2410221200-2411182300
10/22/240425Z !BHM 10/130 BHM NAV ILS RWY 06 CAT II NA 2410220425-2411162000EST
10/16/241330Z !BHM 10/089 BHM OBST RIG (ASN 2024-ASO-12038-NRA) 333359N0864439W (0.4NM ENE BHM) 643FT (22FT AGL) FLAGGED AND LGTD 2410161330-2411112300
10/16/241327Z !BHM 10/088 BHM OBST RIG (ASN 2024-ASO-12037-NRA) 333359N0864441W (0.4NM ENE BHM) 641FT (22FT AGL) FLAGGED AND LGTD 2410161327-2411112300
10/16/241326Z !BHM 10/087 BHM OBST RIG (ASN 2024-ASO-12036-NRA) 333359N0864444W (0.4NM ENE BHM) 638FT (22FT AGL) FLAGGED AND LGTD 2410161326-2411112300
10/16/240248Z !BHM 10/085 BHM RWY 24 RTHL U/S 2410160248-2411152000EST
10/14/241338Z !BHM 10/073 BHM TWY N BTN TWY G AND EAST FIXED BASE OPR RAMP CLSD 2410141338-2411112200
9/7/240922Z !BHM 09/040 BHM OBST RIG (ASN UNKNOWN) 333334N0864530W (0.47NM SW BHM)
611FT (15FT AGL) FLAGGED 2409070922-2411090001
9/7/240921Z !BHM 09/039 BHM OBST RIG (ASN UNKNOWN) 333335N0864530W (0.46NM SW BHM)
611FT (15FT AGL) FLAGGED 2409070921-2411090001
9/7/240920Z !BHM 09/038 BHM OBST RIG (ASN UNKNOWN) 333338N0864530W (0.42NM SW BHM)
611FT (15FT AGL) FLAGGED 2409070920-2411090001
9/7/240920Z !BHM 09/037 BHM OBST RIG (ASN UNKNOWN) 333334N0864534W (0.51NM SW BHM)
611FT (15FT AGL) FLAGGED 2409070920-2411090001
9/7/240919Z !BHM 09/036 BHM OBST RIG (ASN UNKNOWN) 333335N0864534W (0.5NM SW BHM)
611FT (15FT AGL) FLAGGED 2409070919-2411090001
9/7/240918Z !BHM 09/035 BHM OBST RIG (ASN UNKNOWN) 333336N0864534W (0.49NM SW BHM)
611FT (15FT AGL) FLAGGED 2409070918-2411090001
9/7/240914Z !BHM 09/034 BHM OBST RIG (ASN 2023-ASO-5013-NRA) 333334N0864534W (0.4NM SW BHM) 619FT (15FT AGL) FLAGGED AND LGTD 2409070914-2411082200
9/7/240914Z !BHM 09/033 BHM OBST RIG (ASN 2023-ASO-5012-NRA) 333336N0864537W (0.5NM WSW BHM) 622FT (15FT AGL) FLAGGED AND LGTD 2409070914-2411082200
9/7/240913Z !BHM 09/032 BHM OBST RIG (ASN 2023-ASO-5011-NRA) 333341N0864528W (0.3NM WSW BHM) 622FT (15FT AGL) FLAGGED AND LGTD 2409070913-2411082200
9/7/240911Z !BHM 09/031 BHM OBST RIG (ASN 2023-ASO-5010-NRA) 333334N0864528W (0.4NM SW BHM) 619FT (15FT AGL) FLAGGED AND LGTD 2409070911-2411082200
9/7/240832Z !BHM 09/025 BHM APRON PEMCO TXL CLSD 2409070832-2411082200
9/7/240823Z !BHM 09/023 BHM TWY A3, A4, TWY A BTN TWY A2 AND TERMINAL RAMP SOUTHWEST ACCESS CLSD 2409070823-2411082200
8/30/241600Z !BHM 08/110 BHM SVC SEE DOMESTIC NOTICES UNIVERSITY OF ALABAMA FOOTBALL 2408301600-2412011600
8/1/242002Z !BHM 08/002 BHM TWY H2 CLSD TO ACFT WINGSPAN MORE THAN 105FT 2408012002-2412312300
8/1/241953Z !BHM 08/003 BHM TWY H3 CLSD TO ACFT WINGSPAN MORE THAN 105FT 2408011953-2412312300
7/31/242213Z !BHM 07/145 BHM TWY H BTN TWY H4 AND APCH END RWY 06 CLSD TO ACFT WINGSPAN MORE THAN 118FT 2407312213-2412312359
FDC
10/8/241750Z !FDC 4/6512 BHM ODP BIRMINGHAM-SHUTTLESWORTH INTL, BIRMINGHAM, AL.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 8...
ADD TAKEOFF OBSTACLE NOTE: RWY 36, TEMPORARY EQUIPMENT 1438FT FROM DER, 687FT LEFT OF CENTERLINE, 21FT AGL/ 746FT MSL (2020-ASO-3334-NRA), TEMPORARY EQUIPMENT 1438FT FROM DER, 653FT LEFT OF CENTERLINE, 21FT AGL/ 746FT MSL (2020-ASO-3335-NRA). ALL OTHER DATA REMAINS AS PUBLISHED. 2410081750-2412151750EST
6/26/241612Z !FDC 4/3969 BHM IAP BIRMINGHAM-SHUTTLESWORTH INTL, BIRMINGHAM, AL.
LOC RWY 18, AMDT 2C...
DME REQUIRED EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
OKW VOR OUT OF SERVICE. 2406261612-2502051612EST
Yes
ALL
BIRMINGHAM AIRPORT AUTHORITY
5900 MESSER AIRPORT HWY
BIRMINGHAM, AL 35212
Phone: (205) 599-0505
RONALD MATHIEU
BIRMINGHAM AIRPORT AUTHORITY, 5900 MESSER AIRPORT HWY
BIRMINGHAM, AL 35212
Phone: (205) 599-0505
ANNISTON FSS (ANB)
Toll Free: 1-800-WX-BRIEF
BHM
--
--
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
None
High & Low Pressure
Air Freight
Air Ambulance
Avionics
Cargo Handling
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales
Annual Surveying

Runway 06/24

12007 ft. x 150 ft.
ASPH
Good
GRVD
HIGH
65 /F/C/X/T
175,000lbs
205,000lbs
350,000lbs
--
  Runway 06 Runway 24
True Heading 55°235°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition FAIR FAIR
Latitude 33° 33' 17"N 33° 34' 25"N
Longitude 86° 46' 18"W 86° 44' 21"W
Elevation 603' 650'
Threshold Crossing Height 68 ft. AGL 69 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights ALSF2 MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 18/36

7099 ft. x 150 ft.
ASPH
Good
GRVD
MED
45 /F/C/X/T
75,000lbs
170,000lbs
240,000lbs
--
  Runway 18 Runway 36
True Heading 180°0°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 33° 34' 24"N 33° 33' 13"N
Longitude 86° 44' 50"W 86° 44' 50"W
Elevation 644' 634'
Threshold Crossing Height 51 ft. AGL --
Visual Glide Path Angle 3.2° --
Visual Slope Indicator P4L --
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes
A110-15TWY F BTN RWY 18/36 & TWY G RSTRD TO ACFT 100000 LBS OR LESS.
A110-16ANG: PPR RQR FOR ANG RAMP. NML OPR HRS 1300-2330Z++ TUE-FRI, CLSD WKNDS & HOL. NO SVC AVBL OUTSIDE THESE HRS WITHOUT PRIOR APVL. NO LCL OR ROUND-ROBIN FLT BY TRAN ACFT. CALL AIRFIELD OPS DSN 778-2555, C205-714-2555 FOR PPR 72 HR PRIOR (96 HRS FOR CARGO MSN). ALL INBD ACFT CTC ANG COMD POST "VULCN CONTROL" NO LATER THAN 15 MIN PRIOR TO LDG WITH PPR NR AND SUPPORT REQ. SPACE-A CAPABILITIES EXTREMELY LTD, PAX SVC LTD AVAILABILITY.
A110-17TWY H S OF TWY H4 RSTRD TO ACFT WITH WINGSPAN LESS THAN 118 FT.
A110-18TWY A BTN TWY A HLDG BAY AND TWY A3 RSTRD TO ACFT WITH WINGSPAN LESS THAN 150 FT.
A110-19TWY H2 RSTRD TO ACFT WITH WINGSPAN LESS THAN 105 FT.
A110-2TWY G RSTRD TO ACFT 65000 LBS OR LESS.
A110-20TWY H3 RSTRD TO ACFT WITH WINGSPAN LESS THAN 105 FT.
A110-3TWY M N OF RWY 6/24 RSTRD TO ACFT 75000 LBS OR LESS.
A110-6TWY N RSTRD TO ACFT 204000 LBS OR LESS.
A110-7BIRD ACTV INVOF RWYS.
BIRMINGHAM-SHUTTLESWORTH INTL (ICAO: KBHM, IATA: BHM) is a public airport located in BIRMINGHAM, AL.
