KBED
LAURENCE G HANSCOM FLD
PublicPUB

0 miles NE of BEDFORD, MA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
42° 28' 12"N 71° 17' 20"W
132' MSL
1132' MSL
16W
JET A, 100LL
BRIDGEPORT (BDR)
NEW YORK
BOSTON (ZBW)
4/17/25-5/15/25
KBED VFR
12:51 PM EST
Few 7,500'
10sm
55°F
21°F
29.87"Hg
310° 25kts
Gusts 43kts
AO2 PK WND 31043/1748 SLP129 T01281061 10128 20078 53015
METAR KBED 041751Z 31025G43KT 10SM FEW075 13/M06 A2987 RMK AO2 PK WND 31043/1748 SLP129 T01281061 10128 20078 53015
+ Add Your Business

KBED FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.95 118.5

ATIS

ATIS
781-372-5509
 124.6

ASOS

ASOS
781-372-5512
 124.6

Clearance Delivery

CD/P
 121.85

Emergency

EMERG
 121.5

Ground

GND/P
 121.7

Tower

LCL/P
 118.5

Terminal Area Forecast

KBED
Tue, 11/4 12:20 PM EST
Tue, 11/4 1:00 PM EST - Wed, 11/5 1:00 PM EST
VFR
1:00 PM EST - 4:00 PM EST
Few 6,000'
6sm
300° 18kts
Gusts 37kts
VFR
4:00 PM EST - 7:00 PM EST
Sky Clear
6sm
290° 15kts
Gusts 28kts
VFR
7:00 PM EST - 2:00 AM EST
Sky Clear
6sm
270° 8kts
VFR
2:00 AM EST - 10:00 AM EST
Few 25,000'
6sm
250° 5kts
VFR
10:00 AM EST - 1:00 PM EST
Broken 25,000'
6sm
230° 8kts
TAF KBED 041720Z 0418/0518 30018G37KT P6SM FEW060
   FM042100 29015G28KT P6SM SKC
   FM050000 27008KT P6SM SKC
   FM050700 25005KT P6SM FEW250
   FM051500 23008KT P6SM BKN250
KBED
EffectiveExpiresCategoryNOTAM
Domestic
10/29/25
1340Z
10/29/25
1500Z
Runway!BED 10/064 BED RWY 23 RWY END ID LGT U/S 2510291340-2510291500
10/29/25
1200Z
10/29/25
1330Z
Runway!BED 10/063 BED RWY 05 RWY END ID LGT U/S 2510291200-2510291330
10/22/25
2103Z
11/6/25
2103Z
!BED 10/046 BED OBST POWER LINE LGT (ASN 2021-ANE-7143-OE) 422810N0711532W (1.3NM E BED) 175FT (61FT AGL) U/S 2510222103-2511062103
10/19/25
2056Z
11/3/25
2056Z
!BED 10/042 BED OBST POWER LINE LGT (ASN 2021-ANE-7141-OE) 422803N0711533W (1.3NM E BED) 173FT (57FT AGL) U/S 2510192056-2511032056
10/16/25
0942Z
12/31/25
1900Z
!BED 10/038 BED TWY M EDGE LGT BTN APCH END RWY 05 AND TWY E U/S EXC LOW INTST ON CONS 2510160942-2512311900
10/15/25
2226Z
1/15/26
2359Z
!BED 10/037 BED NAV VOT U/S 2510152226-2601152359
10/3/25
1144Z
!BED 10/011 BED NAV ILS RWY 11 GP U/S 2510031144-2511052359EST
9/17/25
0513Z
12/31/25
1800Z
!BED 09/079 BED OBST POLE (ASN UNKNOWN) 422748N0711726W (0.28NM E APCH END RWY 05)
232FT (103FT AGL) NOT LGTD 2509170513-2512311800
9/8/25
1933Z
12/31/25
2200Z
!BED 09/049 BED TWY T DIRECTION MARKINGS REMOVED 2509081933-2512312200
FDC
8/17/25
2127Z
3/29/26
2127Z
!FDC 5/9160 BED ODP LAURENCE G HANSCOM FLD, BEDFORD, MA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 6A...
TAKEOFF OBSTACLE NOTE: RWY 23, TEMPORARY CRANE 893FT FROM DER, 513FT LEFT OF CENTERLINE, 80FT AGL/212FT MSL (2023-AEA-897-NRA).
ALL OTHER DATA REMAINS AS PUBLISHED. 2508172127-2603292127EST
6/23/25
1512Z
!FDC 5/7427 BED IAP LAURENCE G HANSCOM FLD, BEDFORD, MA.
ILS OR LOC RWY 29, AMDT 9B...
S-LOC 29 MDA 680/HAT 552 ALL CATS. VISIBILITY CAT C/D 1 1/8. VDP AT I-ULJ 1.30 DME; DISTANCE VDP TO THLD 1.58NM. TEMPORARY CRANE 367FT MSL 1.76NM EAST OF RWY 29 (2025-ANE-967-OE).
2506231512-2602021512EST
3/31/25
1314Z
!FDC 5/9802 BED IAP LAURENCE G HANSCOM FLD, BEDFORD, MA.
RNAV (RNP) Y RWY 11, AMDT 1...
RNP 0.30 DA 539/HAT 407 ALL CATS.
2503311314-2703312359EST
3/7/25
1849Z
!FDC 5/0511 BED ODP LAURENCE G HANSCOM FLD, BEDFORD, MA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 6A...
IN ADDITION TO EXISTING TAKEOFF OBSTACLE NOTES, ADD: RWY 11: TOWER 5027 FT FROM DER, 1683 FT LEFT OF CENTERLINE, 155 FT AGL/282 FT MSL. ANTENNA 5027 FT FROM DER, 1682 FT LEFT OF CENTERLINE, 285 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED. 2503071849-2703051849EST
9/5/24
1510Z
!FDC 4/1007 BED IAP LAURENCE G HANSCOM FLD, BEDFORD, MA.
RNAV (GPS) RWY 23, AMDT 1A...
LNAV MDA 660/HAT 532 ALL CATS, VISIBILITY CATS C/D 1 1/2.
TOWER 391 MSL 2.83 NM NE OF RWY 23 (2022-ANE-2542-OE PERMANENT).
2409051510-2611051509EST
Yes
ALL
MASS PORT AUTHORITY
ONE HARBORSIDE DR
E BOSTON, MA 02128
Phone: 617-212-6592
SHARON M. WILLIAMS
MASSPORT, 200 HANSCOM DR
BEDFORD, MA 01730
Phone: 617-212-6592
BRIDGEPORT FSS (BDR)
Toll Free: 1-800-WX-BRIEF
BED
--
ACTVT MALSR RWY 11 & 29; REIL RWY 05 & 23; HIRL RWY 11/29; MIRL RWY 05/23; TWY LGTS - 118.5.
N/A
Yes - Lighted
Yes
Yes
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Major
Major
High & Low Pressure
High & Low Pressure
Air Freight
Air Ambulance
Avionics
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 05/23

5107 ft. x 150 ft.
ASPH
Good
GRVD
MED

120,000lbs
248,000lbs
323,000lbs
823,000lbs
  Runway 05 Runway 23
True Heading 37°217°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 42° 27' 48"N 42° 28' 29"N
Longitude 71° 17' 49"W 71° 17' 08"W
Elevation 128' 128'
Threshold Crossing Height 55 ft. AGL 55 ft. AGL
Visual Glide Path Angle 3.5° 3.2°
Visual Slope Indicator P4L P4R
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes

Runway 11/29

7011 ft. x 150 ft.
ASPH
Good
GRVD
HIGH

120,000lbs
250,000lbs
389,000lbs
916,000lbs
  Runway 11 Runway 29
True Heading 97°277°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 42° 28' 19"N 42° 28' 10"N
Longitude 71° 18' 01"W 71° 16' 28"W
Elevation 132' 123'
Threshold Crossing Height 67 ft. AGL 52 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4R
Approach Lights MALSR MALSR
Centerline Lights No No
Runway End Identifier Lights No No
A110-1PPR FOR ALL ACFT CARRYING EXPLOSIVES CALL 617-212-6592.
A110-10TWY C, F, J, N, R, S, T, TWY M SOUTH OF TWY E & TWY G BTN RWY 11/29 & RWY 05/23 CLSD TO ACFT GTR THAN 118 FT WINGSPAN. TWY R CLSD TO ACR OPS-GA USE ONLY.
A110-14NO PLAS/TGLS FOR ACFT UNDER 12500 LBS BTN 2300-0700.
A110-16SVC-TRAN ALERT: OPR 1200-0400Z++ WKD; 1400-2200Z++ SUN; PPR OT AND HOL DSN 845-5589/5592. DE-ICING AVBL FR VENDOR.
A110-18AF: PPR ALL MIL ACFT, PAX MNFST REQ ALL INBD PAX, CTC BASE OPS DSN 845-5589/5592, C781-225-5589/5592.
A110-19AF: COMD POST DSN 845-6960/6961, C781-225-6960/6961.
A110-2NO PLAS/TGLS FOR ACFT 12500 LBS & OVER.
A110-20VOLUNTARY NOISE ABATEMENT PROCS IN EFCT CTC AMGR 617-212-6592. NOISE SENSITIVE HISTORIC AREA S OF ARPT; FOR RWY 23 DEP CONT RWY HDG TO 1000 FT AGL, TURNING CROSSWIND OVR RTE 2.
A110-21PPR FOR MAINT ENG RUN - CTC AMGR.
A110-22SERVICE: MIL ACFT MUST ARNG FOR PRKG ON EAST RAMP WITH TRAN ALERT OR VENDOR.
A110-23TWY R1, R2 CLSD TO ACFT GTR THAN 49 FT WINGSPAN.
A110-3NOISE RULES IN EFCT - HELS OPERG WI CNTLD ASP ARE RQRD TO MNTN HIST PSBL ALT.
A110-4SUPPORT: OPR 1200-0400Z++ MON-FRI, 1300-1900Z++ SAT & SUN, CLSD HOL. CTC BASE OPS PRIOR TO 1700Z++ FRI FOR OT SUPPORT.
A110-6BIRDS & WILDLIFE ON & INVOF ARPT.
A110-8BE ALERT FOR SML ACFT PARKED ON RAMPS.
A110-9(A23) RWY 29 RIGHT TFC ACFT OVR 12500 LBS.
LAURENCE G HANSCOM FLD (ICAO: KBED, IATA: BED) is a public airport located in BEDFORD, MA.
