KBAC
BARNES COUNTY MUNI
PublicPUB

1 miles NW of VALLEY CITY, ND
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
46° 56' 28"N 98° 01' 05"W
1402' MSL
2402' MSL
07E
100LL
GRAND FORKS (GFK)
TWIN CITIES
MINNEAPOLIS (ZMP)
7/11/24-8/8/24
KBAC VFR
5:35 AM CDT
Clear
9sm
59°F
59°F
29.58"Hg
180° 7kts
AO2
KBAC 191035Z AUTO 18007KT 9SM CLR 15/15 A2958 RMK AO2
Add Your Business

KBAC FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

AWOS-3

AWOS-3
701-845-9117
 118.725

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KJMS (27nm)
Thu, 9/19 1:27 AM CDT
Thu, 9/19 1:00 AM CDT - Fri, 9/20 1:00 AM CDT
VFR
1:00 AM CDT - 8:00 AM CDT
Scattered 25,000'
6sm
210° 10kts
VFR
8:00 AM CDT - 10:00 AM CDT
Scattered 25,000'
6sm
220° 14kts
Gusts 23kts
VFR
10:00 AM CDT - 1:00 PM CDT
Few 25,000'
6sm
240° 16kts
Gusts 25kts
VFR
1:00 PM CDT - 4:00 PM CDT
Few 8,000'
6sm
250° 18kts
Gusts 27kts
VFR
4:00 PM CDT - 8:00 PM CDT
Scattered 8,000'
6sm
260° 19kts
Gusts 29kts
VFR
8:00 PM CDT - 1:00 AM CDT
Few 25,000'
6sm
270° 14kts
Gusts 23kts
KJMS 190627Z 1906/2006 21010KT P6SM SCT250
   FM191300 22014G23KT P6SM SCT250
   FM191500 24016G25KT P6SM FEW250
   FM191800 25018G27KT P6SM FEW080
   FM192100 26019G29KT P6SM SCT080
   FM200100 27014G23KT P6SM FEW250
KBAC
Domestic
9/13/240516Z !GFK 09/092 BAC OBST TOWER LGT (ASR 1224844) 465517.60N0974059.20W (13.8NM E BAC) 1518.0FT (345.1FT AGL) U/S 2409130516-2409280416
9/8/240522Z !GFK 09/043 BAC OBST TOWER LGT (ASR 1228273) 465417.10N0981124.60W (7.4NM WSW BAC) 1815.6FT (359.9FT AGL) U/S 2409080522-2409230422
8/30/240306Z !GFK 08/271 BAC OBST TOWER LGT (ASR 1220580) 465518.40N0974821.90W (8.8NM E BAC) 1671.3FT (389.1FT AGL) U/S 2408300306-2410140305
8/16/242253Z !GFK 08/171 BAC OBST TOWER LGT (ASR 1219401) 465402.60N0981002.30W (6.6NM WSW BAC) 1821.2FT (349.1FT AGL) U/S 2408162253-2409302252
8/16/242120Z !GFK 08/169 BAC OBST TOWER LGT (ASR 1219402) 465401.30N0981954.70W (13.1NM W BAC) 1828.1FT (349.1FT AGL) U/S 2408162120-2409302119
7/18/241300Z !GFK 07/139 BAC AIRSPACE AEROBATIC ACFT WI AN AREA DEFINED AS 2NM RADIUS OF BAC SFC-6000FT AGL 2407181300-2411010100
FDC
3/28/231943Z !FDC 3/3362 BAC IAP BARNES COUNTY MUNI, VALLEY CITY, ND.
RNAV (GPS) RWY 13, ORIG-B...
FEEDER SEGMENT HUHJO TO JEVLO (IAF) MINIMUM ALTITUDE 3200.
2303281943-2503281943EST
No
MON-FRI 0800-1700
SAT-SUN ON CALL
FOR ARPT ATTENDANT AFTER HRS CALL 701-840-5903.
BARNES COUNTY AIRPORT AUTHORITY
P.O. BOX 2
VALLEY CITY, ND 58072
Phone: 701-840-2029
MIKE LERUD
P.O. BOX 2
VALLEY CITY, ND 58072
Phone: 701-840-5903
GRAND FORKS FSS (GFK)
Toll Free: 1-800-WX-BRIEF
GFK
--
MIRL RWY 13/31 PRESET ON MED INTST; TO INCR INTST AND ACTVT PAPI RWY 13 & 31 - CTAF.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
23
1
0
0
0
0
Major
Major
None
None
Crop Dusting
Air Ambulance
Charter Service
Pilot Instruction
Aircraft Sales

Runway 05/23

2525 ft. x 120 ft.
TURF
Good
NONE


--
--
--
--
  Runway 05 Runway 23
True Heading 58°238°
Traffic Pattern Left Left
Markings
Markings Condition
Latitude 46° 56' 13"N 46° 56' 26"N
Longitude 98° 01' 16"W 98° 00' 46"W
Elevation 1,379' 1,385'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No

Runway 08/26

2520 ft. x 120 ft.
TURF
Good
NONE


--
--
--
--
  Runway 08 Runway 26
True Heading 90°270°
Traffic Pattern Left Left
Markings
Markings Condition
Latitude 46° 56' 23"N 46° 56' 22"N
Longitude 98° 01' 17"W 98° 00' 40"W
Elevation 1,386' 1,384'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No

Runway 13/31

4201 ft. x 75 ft.
CONC
Good
NONE
MED

12,000lbs
--
--
--
  Runway 13 Runway 31
True Heading 134°314°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 46° 56' 51"N 46° 56' 22"N
Longitude 98° 01' 21"W 98° 00' 37"W
Elevation 1,402' 1,385'
Threshold Crossing Height 28 ft. AGL 28 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No

Runway 17/35

3539 ft. x 100 ft.
TURF
Good
NONE


--
--
--
--
  Runway 17 Runway 35
True Heading 180°360°
Traffic Pattern Left Left
Markings
Markings Condition
Latitude 46° 56' 47"N 46° 56' 12"N
Longitude 98° 01' 18"W 98° 01' 18"W
Elevation 1,397' 1,380'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No
A110-1RWYS 05/23 08/26 17/35 CLSD WINTER MONTHS DUE TO LACK OF SNOW REMOVAL
A110-5CONFIRM SNOW REMOVAL & WINTER CONDITIONS DURING NOV-MAR, CALL 701-840-5903.
A110-6BIRDS AND DEER ON & INVOF ARPT.
A110-7FOR CD CTC MINNEAPOLIS ARTCC AT 651-463-5588.
BARNES COUNTY MUNI (ICAO: KBAC, IATA: BAC) is a public airport located in VALLEY CITY, ND.
