ARLINGTON MUNI - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KAWO
ICAO KAWOLocal AWO
ARLINGTON MUNI
PublicPUB

3 miles SW of ARLINGTON, WA, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
48° 09' 39"N 122° 09' 32"W
Elevation
142' MSL
Pattern Alt
1200' MSL
Mag Variation
15°E
Declination
17°E
Fuel
JET A, 100LL
FSS
SEATTLE (SEA)
Sectional
SEATTLE
ARTCC
SEATTLE (ZSE)
Data Effective
2/19/26-3/19/26
KAWO MVFR
8:56 PM PST
Overcast 2,200'
10sm
51°F
49°F
29.97"Hg
130° 14kts
AO2 SLP154 T01060094
METAR KAWO 040456Z AUTO 13014KT 10SM OVC022 11/09 A2997 RMK AO2 SLP154 T01060094
+ Add Your Business

KAWO FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

AWOS-3PT 135.625
(360) 435-8045

Common

CTAF 122.725
REIL RWY 11 & 29 OPR SS-SR; PAPI RWY 11, 16, 29 & 34 OPR CONSLY. ACTVT MALS RWY 34; REILS RWY 16; RWY 16/34 EDGE LIGHTS; TWY LGTS CTAF.

Clearance

Clearance Delivery 121.725

Approach

SEATTLE APPROACH 128.5

Departure

SEATTLE DEPARTURE 128.5

FAA A/FD Pages

Airport Minimums

Departure Procedures

Instrument Approach

Terminal Area Forecast

KPAE (15nm)
Tue, 3/3 3:20 PM PST
Tue, 3/3 4:00 PM PST - Wed, 3/4 4:00 PM PST
MVFR
4:00 PM PST - 10:00 PM PST
Light Showers and Rain
Broken 5,000'
Broken 3,000'
6sm
190° 17kts
Gusts 25kts
MVFR
10:00 PM PST - 4:00 AM PST
Light Rain
Overcast 2,500'
6sm
150° 10kts
MVFR
4:00 AM PST - 1:00 PM PST
Overcast 1,500'
6sm
180° 11kts
MVFR
1:00 PM PST - 4:00 PM PST
Light Showers and Rain
Overcast 2,500'
6sm
220° 9kts
TAF KPAE 032320Z 0400/0424 19017G25KT P6SM -SHRA BKN030 BKN050
   FM040600 15010KT P6SM -RA OVC025
   FM041200 18011KT P6SM OVC015
   FM042100 22009KT P6SM -SHRA OVC025
KAWO
EffectiveExpiresCategoryNOTAM
Domestic
2/24/26
1500Z
3/2/26
1600Z
Runway!AWO 02/007 AWO RWY 34 ALS U/S 2602241500-2603021600
2/13/26
2209Z
8/13/26
2000Z
!AWO 02/006 AWO NAV ILS RWY 34 U/S 2602132209-2608132000
No
M-F 0800-1700
CITY OF ARLINGTON
CITY HALL 238 N OLYMPIC
ARLINGTON, WA 98223
Phone: 360-403-3470
MARTY WRAY
18204 59TH AVE NE, STE A
ARLINGTON, WA 98223
Phone: 360-403-3471
SEATTLE FSS (SEA)
Toll Free: 1-800-WX-BRIEF
AWO
--
REIL RWY 11 & 29 OPR SS-SR; PAPI RWY 11, 16, 29 & 34 OPR CONSLY. ACTVT MALS RWY 34; REILS RWY 16; RWY 16/34 EDGE LIGHTS; TWY LGTS CTAF.
N/A
Yes - Lighted
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Major
Major
None
None
Air Ambulance
Avionics
Cargo Handling
Charter Service
Glider Service
Pilot Instruction
Aircraft Rental
Aircraft Sales
Annual Surveying
Glider Towing

Runway 11/29

3498 ft. x 75 ft.
ASPH
Excellent
NONE


32,000lbs
34,000lbs
59,000lbs
--
  Runway 11 Runway 29
True Heading 127°307°
Traffic Pattern Right Left
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 48° 09' 42"N 48° 09' 21"N
Longitude 122° 10' 08"W 122° 09' 27"W
Elevation 132' 128'
Threshold Crossing Height 42 ft. AGL 40 ft. AGL
Visual Glide Path Angle 3.5° 4°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes

Runway 16/34

5332 ft. x 100 ft.
ASPH
Excellent
NONE
MED

114,000lbs
150,000lbs
270,000lbs
--
  Runway 16 Runway 34
True Heading 179°359°
Traffic Pattern Right Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 48° 10' 10"N 48° 09' 17"N
Longitude 122° 09' 23"W 122° 09' 22"W
Elevation 141' 128'
Threshold Crossing Height 40 ft. AGL 36 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P2L P2L
Approach Lights MALS
Centerline Lights
Runway End Identifier Lights Yes
A110-1GLIDER OPERATIONS AT ARPT DAILY.
A110-10RWY 11/29 TURF LCTD BTN D2 AND D3 DIMENSIONS 1400 FT X 100 FT.
A110-2ULTRALIGHT AND POWERED PARACHUTE OPS DAILY WEST OF RWY 16/34
A110-3OCCASIONAL HOT AIR BALLOON ACTIVITY.
A110-4WILDLIFE ON AND INVOF ARPT. ALTERNATE PHONE NUMBER FOR AIRPORT: 360-403-3470
A110-6WINTER WEATHER OPERATIONS AND REPORTING MONDAY-FRIDAY 1600-0000Z.
A110-7FOR ADDNL DETAILS & RULES ON LOCAL PROCS CALL 360-403-3470.
A110-8FOR CD WHEN ATCT IS CLSD CTC SEATTLE APCH AT 206-214-4722.
A110-9GLDR TURF PARL EAST OF RWY 16/34, FULL LEN DIMENSIONS 4000 FT X 145 FT.
A30-16/34RWY 34 CALM WIND RWY.
A70-100LL100L FUEL AVBL 24 HR CREDIT CARD SVC.
A70-APHONE 360-435-5700 FOR AFTER HRS SVC.
A75-HPILOTS PROVIDE OWN ROPES.
A81-APTREIL RWY 11 & 29 OPR SS-SR; PAPI RWY 11, 16, 29 & 34 OPR CONSLY. ACTVT MALS RWY 34; REILS RWY 16; RWY 16/34 EDGE LIGHTS; TWY LGTS CTAF.
E111EXISTED PRIOR TO 1959.
E147TPA FOR ULTRALGTS 542 (400), HELICOPTERS 642 (500).
ARLINGTON MUNI (ICAO: KAWO, IATA: AWO) is a public airport located in ARLINGTON, WA, US.
