KAWG
WASHINGTON MUNI
PublicPUB

2 miles SE of WASHINGTON, IA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
41° 16' 33"N 91° 40' 34"W
754' MSL
1754' MSL
01W
JET A, 100LL
FORT DODGE (FOD)
CHICAGO
CHICAGO (ZAU)
10/31/24-11/28/24
KAWG VFR
5:35 AM CST
Clear
9sm
45°F
43°F
30.15"Hg
100° 12kts
AO2
KAWG 091135Z AUTO 10012KT 9SM CLR 07/06 A3015 RMK AO2
Add Your Business

KAWG FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.7 122.7

AWOS-3

AWOS-3
319-653-4149
 127.825

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KOTM (36nm)
Sat, 11/9 5:20 AM CST
Sat, 11/9 6:00 AM CST - Sun, 11/10 6:00 AM CST
VFR
6:00 AM CST - 10:00 AM CST
Broken 15,000'
6sm
110° 9kts
VFR
10:00 AM CST - 3:00 PM CST
Light Showers and Rain
Overcast 8,000'
6sm
120° 11kts
MVFR
3:00 PM CST - 5:00 PM CST
Overcast 1,500'
6sm
130° 12kts
Gusts 20kts
IFR
5:00 PM CST - 1:00 AM CST
Overcast 600'
6sm
130° 11kts
MVFR
1:00 AM CST - 4:00 AM CST
Broken 1,400'
6sm
180° 8kts
VFR
4:00 AM CST - 6:00 AM CST
Scattered 5,000'
6sm
200° 9kts
KOTM 091120Z 0912/1012 11009KT P6SM BKN150
   FM091600 12011KT 6SM -SHRA OVC080
   FM092100 13012G20KT P6SM OVC015
   FM092300 13011KT P6SM OVC006
   FM100700 18008KT P6SM BKN014
   FM101000 20009KT P6SM SCT050
KAWG
Domestic
11/6/240042Z !AWG 11/001 AWG AD AP JET A FUEL NOT AVBL 2411060042-2412062359
10/14/241141Z !AWG 10/003 AWG OBST TOWER LGT (ASR 1235154) 412727.10N0914304.10W (11.1NM N AWG) 1058.1FT (265.1FT AGL) U/S 2410141141-2501142359
10/7/241346Z !AWG 10/002 AWG RWY 18 PAPI UNUSABLE 2410071346-2504072111EST
10/7/241345Z !AWG 10/001 AWG RWY 18 RWY END ID LGT U/S 2410071345-2504072111EST
8/25/242012Z !AWG 08/005 AWG OBST TOWER LGT (ASR 1229383) 411259.30N0913138.40W (7.6NM ESE AWG) 1039.7FT (319.9FT AGL) U/S 2408252012-2411302359
No
MON-THURS 0700-1500
AVAILABLE 24/7 AT 319-653-7002
CITY OF WASHINGTON
215 E WASHINGTON
WASHINGTON, IA 52353
Phone: 319-461-0359
KURT KUCERA
1625 SOUTH AIRPORT RD
WASHINGTON, IA 52353
Phone: 319-461-0359
FORT DODGE FSS (FOD)
Toll Free: 1-800-WX-BRIEF
AWG
--
ACTVT MIRL RY 13/31, MIRL RY 18/36; PAPI RYS 18/36 AND 13/31 AND REIL RYS 18/36 AND 13/31- CTAF.
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
None
High Pressure
Aircraft Sales

Runway 13/31

3401 ft. x 60 ft.
CONC
Excellent
NONE
MED
5 /R/C/W/U
28,000lbs
--
--
--
  Runway 13 Runway 31
True Heading 135°315°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 41° 16' 51"N 41° 16' 27"N
Longitude 91° 40' 47"W 91° 40' 16"W
Elevation 753' 754'
Threshold Crossing Height 36 ft. AGL 30 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes

Runway 18/36

4000 ft. x 75 ft.
CONC
Good
WC
MED
5 /R/C/W/U
--
--
--
--
  Runway 18 Runway 36
True Heading 183°3°
Traffic Pattern
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 41° 16' 46"N 41° 16' 07"N
Longitude 91° 40' 35"W 91° 40' 37"W
Elevation 751' 751'
Threshold Crossing Height 45 ft. AGL 35 ft. AGL
Visual Glide Path Angle 4° 3°
Visual Slope Indicator P2R P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes
A110-2RY 36 IS CALM WIND RY.
A110-4FOR CD CTC CHICAGO ARTCC AT 630-906-8921.
WASHINGTON MUNI (ICAO: KAWG, IATA: AWG) is a public airport located in WASHINGTON, IA.
