iFlightPlanner



...
No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

KATY
WATERTOWN RGNL
PublicPUB

2 miles NW of WATERTOWN, SD
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
44° 54' 50"N 97° 09' 17"W
1749' MSL
2749' MSL
06E
JET A, 100LL
HURON (HON)
TWIN CITIES
MINNEAPOLIS (ZMP)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

KATY FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
123.05 123.05

ASOS

ASOS
605-882-0578
 126.625

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

No TAF is available for this location.
KATY
Domestic
1/15/250216Z !ATY 01/079 ATY AD AP SFC COND NOT REP 2501150216-2501151130
1/10/251332Z !ATY 01/043 ATY COM REMOTE COM OUTLET 122.5 U/S 2501101332-2501302000EST
1/3/251118Z !ATY 01/016 ATY RWY 12 RWY END ID LGT NOT STD 2501031118-2501242200
12/30/242156Z !ATY 12/192 ATY OBST TOWER LGT (ASR 1206577) 450617.00N0965918.00W (13.5NM NNE ATY) 2876.0FT (875.0FT AGL) U/S 2412302156-2506302359
FDC
12/18/241705Z !FDC 4/8446 ATY ODP WATERTOWN RGNL, WATERTOWN, SD.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG-A...
ADD TAKEOFF OBSTACLE NOTE: RWY 35, TEMPORARY CRANE BEGINNING 2601FT FROM DER, 972FT LEFT OF CENTERLINE, 90FT AGL/1840FT MSL (2024-AGL-5520 TO 5523-OE). ALL OTHER DATA REMAINS AS PUBLISHED. 2412181705-2601111705EST
12/18/241705Z !FDC 4/8445 ATY IAP WATERTOWN RGNL, WATERTOWN, SD.
RNAV (GPS) RWY 17, ORIG-B...
LNAV MDA 2140/HAT 399 ALL CATS, VIS CAT C/D 1 1/8. TEMPORARY CRANE 1840 MSL 2640FT N/NW OF RWY 17 (2024-AGL-5520 TO 5523-OE).
2412181705-2601111705EST
10/7/241300Z !FDC 4/4981 ATY IAP WATERTOWN RGNL, WATERTOWN, SD.
RNAV (GPS) RWY 12, ORIG-B...
LNAV MDA 2140/HAT 391 ALL CATS, VIS CAT C/D 1 1/8. TEMPORARY CRANE 1840 MSL 3912FT NE OF RWY 12 (2024-AGL-5520 TO 5523-OE).
2410071300-2601111835EST
No
0430-2030
CITY OF WATERTOWN
P.O. BOX 910
WATERTOWN, SD 57201
Phone: 605-882-6209
IAN MERIWETHER-CHALFANT
550 E AIRPORT DRIVE
WATERTOWN, SD 57201
Phone: 605-753-9357
HURON FSS (HON)
Toll Free: 1-800-WX-BRIEF
ATY
--
ACTVT MALSR RWY 35; PAPI RWY 12, 17, 30, & 35; HIRL RWY 17/35; MIRL RWY 12/30; REIL RWY 12, 17, & 30 - CTAF.
N/A
Yes - Lighted
Yes
Yes
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
Major
Major
None
None
Air Freight
Crop Dusting
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales

Runway 12/30

6898 ft. x 100 ft.
CONC
Excellent
GRVD
MED
30 /R/D/X/T
80,000lbs
97,000lbs
160,000lbs
--
  Runway 12 Runway 30
True Heading 125°305°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 44° 55' 20"N 44° 54' 41"N
Longitude 97° 10' 09"W 97° 08' 51"W
Elevation 1,748' 1,733'
Threshold Crossing Height 48 ft. AGL 34 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes

Runway 17/35

6893 ft. x 100 ft.
CONC
Good
GRVD
HIGH
50 /R/B/W/T
120,000lbs
177,000lbs
301,000lbs
--
  Runway 17 Runway 35
True Heading 180°0°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 44° 55' 14"N 44° 54' 06"N
Longitude 97° 09' 04"W 97° 09' 04"W
Elevation 1,741' 1,743'
Threshold Crossing Height 35 ft. AGL 54 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSR
Centerline Lights
Runway End Identifier Lights Yes
A110-1GULLS & GEESE ON & INVOF ARPT APR-NOV.
A110-3GLIDER OPNS APR THRU SEP.
A110-4ANNUALLY APRIL- SEPT HAY CUTTING OPNS IN PROGRESS; FARMING EQUIP MAY BE IN APCHS.
A110-5ACR OPNS INVOLVING ACFT WITH MORE THAN 9 PSGRS ARE NOT AUZD IN EXCESS OF 15 MINS BEFORE OR AFTER SKED ARR/DEP TIMES WITHOUT PRIOR COORDINATION WITH AMGR AND CFMN THAT ARFF IS AVBL PRIOR TO LANDING OR TAKEOFF.
A110-8ARPT SFC COND NOT MONITORED SUN-FRI 2200-0500 & SAT 1400-SUN 0500.
A110-9FOR CD IF UNA TO CTC ON FSS FREQ, CTC MINNEAPOLIS ARTCC AT 651-463-5588.
WATERTOWN RGNL (ICAO: KATY, IATA: ATY) is a public airport located in WATERTOWN, SD.
