HARTSFIELD/JACKSON ATLANTA INTL - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KATL
ICAO KATLIATA ATLLocal ATL
HARTSFIELD/JACKSON ATLANTA INTL
PublicPUB

7 miles S of ATLANTA, GA, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
33° 38' 12"N 84° 25' 40"W
Elevation
1026' MSL
Pattern Alt
2026' MSL
Mag Variation
5°W
Declination
5°W
Fuel
JET A, 100LL, 100
FSS
MACON (MCN)
Sectional
ATLANTA
ARTCC
ATLANTA (ZTL)
Data Effective
2/19/26-3/19/26
KATL MVFR
10:52 PM EST
Broken 25,000'
Broken 1,300'
9sm
56°F
51°F
30.31"Hg
140° 8kts
AO2 SLP265 T01330106
METAR KATL 040352Z 14008KT 9SM BKN013 BKN250 13/11 A3031 RMK AO2 SLP265 T01330106
+ Add Your Business

KATL FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

Digital ATIS 119.65
ARR - (404) 763-7988
Digital ATIS 125.55
DEP - (404) 763-7988
ASOS (404) 559-5166

Common

UNICOM 122.95

Clearance

Clearance Delivery 118.1

Ground

ATLANTA GROUND 121.65
RWY 10/28
ATLANTA GROUND 121.75
RWY 09L/27R, 09R/27L
ATLANTA GROUND 121.9
RWY 08L/26R, 08R/26L
Ramp Control 128.975
RAMP 8
Ramp Control 129.25
RAMP 6N SNOW AND ICE
Ramp Control 129.25
RAMP 7 SNOW AND ICE
Ramp Control 129.275
RAMP 3
Ramp Control 129.375
RAMP 5
Ramp Control 129.4
RAMP 33 SNOW AND ICE
Ramp Control 130.075
RAMP 4
Ramp Control 130.775
RAMP 20 SNOW AND ICE
Ramp Control 131.375
NON MOVEMENT AREA
Ramp Control 131.375
RAMP 6
Ramp Control 131.375
RAMP 6S SNOW AND ICE
Ramp Control 131.45
RAMP 1
Ramp Control 131.85
RAMP 2
Ramp Control 131.875
RAMP 9

Tower

ATLANTA TOWER 119.1
RWY 08L/26R
ATLANTA TOWER 119.3
RWY 09R/27L
ATLANTA TOWER 119.5
RWY 10/28
ATLANTA TOWER 123.85
RWY 09L/27R
ATLANTA TOWER 125.325
RWY 08R/26L
Tower Final Control 124.6
When assigned On approach - RWY 09L, 09R, 27L, 27R
Tower Final Control 127.25
When assigned On approach - RWY 08L, 08R, 26L, 26R
Tower Final Control 135.375
When assigned On approach - RWY 10, 28

Arrival

BUKHD STAR 121.0
CHPPR STAR 128.0
DEHAN STAR 126.975
GLAVN STAR 128.0
GNDLF STAR 127.9
HOBTT STAR 127.9
JJEDI STAR 127.9
ONDRE STAR 128.525
OZZZI STAR 128.525
SITTH STAR 127.9

Approach

ATLANTA APPROACH 127.9
Initial Contact - 090-269
ATLANTA APPROACH 128.0

Departure

ATLANTA DEPARTURE 121.225
RWY 10/28
ATLANTA DEPARTURE 125.65
RWY 09L/27R, 09R/27L
ATLANTA DEPARTURE 133.475
RWY 08L/26R, 08R/26L
ATLANTA DP 121.225
RWY 10/28
ATLANTA DP 125.65
RWY 09L/27R, 09R/27L
ATLANTA DP 133.475
RWY 08L/26R, 08R/26L
BANNG DP 121.225
RWY 10/28
BANNG DP 125.65
RWY 09L/27R, 09R/27L
BANNG DP 133.475
RWY 08L/26R, 08R/26L
CUTTN DP 121.225
RWY 10/28
CUTTN DP 125.65
RWY 09L/27R, 09R/27L
CUTTN DP 133.475
RWY 08L/26R, 08R/26L
GAIRY DP 121.225
RWY 10/28
GAIRY DP 125.65
RWY 09L/27R, 09R/27L
GAIRY DP 133.475
RWY 08L/26R, 08R/26L
HAALO DP 121.225
RWY 10/28
HAALO DP 125.65
RWY 09L/27R, 09R/27L
HAALO DP 133.475
RWY 08L/26R, 08R/26L
JACCC DP 121.225
RWY 10/28
JACCC DP 125.65
RWY 09L/27R, 09R/27L
JACCC DP 133.475
RWY 08L/26R, 08R/26L
KAJIN DP 121.225
RWY 10/28
KAJIN DP 125.65
RWY 09L/27R, 09R/27L
KAJIN DP 133.475
RWY 08L/26R, 08R/26L
NASSA DP 121.225
RWY 10/28
NASSA DP 125.65
RWY 09L/27R, 09R/27L
NASSA DP 133.475
RWY 08L/26R, 08R/26L
PADGT DP 121.225
RWY 10/28
PADGT DP 125.65
RWY 09L/27R, 09R/27L
PADGT DP 133.475
RWY 08L/26R, 08R/26L
PENCL DP 121.225
RWY 10/28
PENCL DP 125.65
RWY 09L/27R, 09R/27L
PENCL DP 133.475
RWY 08L/26R, 08R/26L
PHIIL DP 121.225
RWY 10/28
PHIIL DP 125.65
RWY 09L/27R, 09R/27L
PHIIL DP 133.475
RWY 08L/26R, 08R/26L
PLMMR DP 121.225
RWY 10/28
PLMMR DP 125.65
RWY 09L/27R, 09R/27L
PLMMR DP 133.475
RWY 08L/26R, 08R/26L
POUNC DP 121.225
RWY 10/28
POUNC DP 125.65
RWY 09L/27R, 09R/27L
POUNC DP 133.475
RWY 08L/26R, 08R/26L
SMKEY DP 121.225
RWY 10/28
SMKEY DP 125.65
RWY 09L/27R, 09R/27L
SMKEY DP 133.475
RWY 08L/26R, 08R/26L
SMLTZ DP 121.225
RWY 10/28
SMLTZ DP 125.65
RWY 09L/27R, 09R/27L
SMLTZ DP 133.475
RWY 08L/26R, 08R/26L
VARNM DP 121.225
RWY 10/28
VARNM DP 125.65
RWY 09L/27R, 09R/27L
VARNM DP 133.475
RWY 08L/26R, 08R/26L
VRSTY DP 121.225
RWY 10/28
VRSTY DP 125.65
RWY 09L/27R, 09R/27L
VRSTY DP 133.475
RWY 08L/26R, 08R/26L
ZELAN DP 121.225
RWY 10/28
ZELAN DP 125.65
RWY 09L/27R, 09R/27L
ZELAN DP 133.475
RWY 08L/26R, 08R/26L

RADAR

Precision Runway Monitor (PRM) 132.55
RWY 09L/27R, 09R/27L
Precision Runway Monitor (PRM) 133.425
RWY 10/28

Emergency

Emergency 121.5

FAA A/FD Pages

Airport Diagrams

Airport Minimums

Departure Procedures

Arrival Procedures

Instrument Approach

Hotspot

Terminal Area Forecast

KATL
Tue, 3/3 10:33 PM EST
Tue, 3/3 11:00 PM EST - Thu, 3/5 1:00 AM EST
MVFR
11:00 PM EST - 3:00 AM EST
Broken 1,500'
6sm
120° 4kts
IFR
3:00 AM EST - 10:00 AM EST
Mist
Broken 600'
4sm
110° 3kts
LIFR
Temporary 5:00 AM EST - 9:00 AM EST
Mist
Overcast 300'
1sm
Calm
IFR
10:00 AM EST - 12:00 PM EST
Overcast 1,500'
Broken 800'
6sm
150° 4kts
MVFR
12:00 PM EST - 2:00 PM EST
Broken 7,000'
Broken 2,500'
6sm
170° 5kts
VFR
2:00 PM EST - 1:00 AM EST
Scattered 12,000'
Scattered 3,500'
6sm
170° 6kts
TAF KATL 040333Z 0404/0506 12004KT P6SM BKN015
   FM040800 11003KT 4SM BR BKN006
   TEMPO 0410/0414 1SM BR OVC003
   FM041500 15004KT P6SM BKN008 OVC015
   FM041700 17005KT P6SM BKN025 BKN070
   FM041900 17006KT P6SM SCT035 SCT120
KATL
EffectiveExpiresCategoryNOTAM
Domestic
3/3/26
1300Z
3/3/26
1700Z
!ATL 02/252 ATL SVC TAR/SSR U/S 2603031300-2603031700
2/25/26
1430Z
2/25/26
1630Z
Runway!ATL 02/255 ATL RWY 08L/26R CLSD 2602251430-2602251630
2/25/26
0547Z
2/25/26
1000Z
!ATL 02/262 ATL APRON NUMBER 8 SOUTH RAMP WIP HVY EQPT ADJ GATE F6
2602250547-2602251000
2/25/26
0544Z
2/25/26
1000Z
!ATL 02/261 ATL APRON NUMBER 8 WEST RAMP WIP HVY EQPT ADJ TO GATE F6
2602250544-2602251000
2/25/26
0542Z
2/25/26
0800Z
!ATL 02/260 ATL TWY D BTN TWY L AND TXL D WIP MAINT 2602250542-2602250800
2/25/26
0530Z
2/25/26
0830Z
!ATL 02/259 ATL NAV ILS RWY 08L LOC U/S 2602250530-2602250830
2/25/26
0430Z
2/25/26
0900Z
Runway!ATL 02/256 ATL RWY 08L/26R CLSD 2602250430-2602250900
2/24/26
1545Z
2/25/26
1630Z
Runway!ATL 02/254 ATL RWY 10/28 SAFETY AREA WIP SW SIDE 2602241545-2602251630
2/23/26
1230Z
Runway!ATL 02/245 ATL RWY 28 ALSF-2 NOW SSALR 2602231230-2602272359EST
2/23/26
0916Z
6/23/26
0916Z
!ATL 02/244 ATL OBST TOWER LGT (ASR 1223288) 333711.70N0843657.80W (9.5NM W ATL) 1140.4FT (264.8FT AGL) U/S 2602230916-2606230916
2/20/26
1041Z
2/27/26
1130Z
!ATL 02/205 ATL TWY H CL LGT BTN APCH END RWY 08R AND TWY E U/S 2602201041-2602271130
2/11/26
1710Z
2/25/26
1700Z
!ATL 02/109 ATL AD AP BIRD ACT LARGE FLOCKS SOUTH TO NORTH 2602111710-2602251700
2/4/26
1850Z
5/5/26
0500Z
!ATL 02/059 ATL OBST TOWER LGT (ASR 1044148) 333557.80N0842547.30W (2.2NM S ATL) 1106.6FT (149.0FT AGL) U/S 2602041850-2605050500
1/29/26
1310Z
2/28/26
1200Z
Runway!ATL 01/359 ATL RWY 09R/27L CL MARKINGS OBSC 2601291310-2602281200
1/29/26
1310Z
2/28/26
1200Z
Runway!ATL 01/358 ATL RWY 08L/26R CL MARKINGS OBSC 2601291310-2602281200
1/29/26
1310Z
2/28/26
1200Z
Runway!ATL 01/357 ATL RWY 10/28 CL MARKINGS OBSC 2601291310-2602281200
1/6/26
1546Z
3/20/26
1900Z
!ATL 01/039 ATL TWY N2 CL MARKINGS BTN RWY 09R/27L AND TWY N OBSC 2601061546-2603201900
12/17/25
1840Z
4/16/26
1840Z
!ATL 12/178 ATL OBST TOWER LGT (ASR 1022036) 334137.30N0841925.30W (6.3NM ENE ATL) 1137.8FT (278.9FT AGL) U/S 2512171840-2604161840
12/4/25
0234Z
2/28/26
1000Z
!ATL 12/035 ATL TWY R10 CLSD EXC ACFT UNDER TOW 2512040234-2602281000
11/25/25
1557Z
!ATL 11/276 ATL NAV ILS RWY 10 IM U/S 2511251557-2605282111EST
10/30/25
0936Z
6/24/26
2359Z
!ATL 10/363 ATL NAV ILS RWY 09L DME U/S 2510300936-2606242359
9/8/25
1205Z
!ATL 09/126 ATL NAV ILS RWY 09R IM U/S 2509081205-2603092111EST
9/8/25
1201Z
!ATL 09/124 ATL NAV ILS RWY 27L IM U/S 2509081201-2603092111EST
FDC
12/2/25
1812Z
!FDC 5/3374 ATL IAP HARTSFIELD/JACKSON ATLANTA INTL, ATLANTA, GA.
ILS PRM RWY 10 (CAT II-III), AMDT 5 ...
ILS RWY 10 (CAT II-III), AMDT 5C ...
NOTE FOR CAT III: LOCALIZER NOT SUITABLE FOR ELECTRONIC ROLLOUT GUIDANCE. 2512021812-2712021809EST
10/31/25
1609Z
!FDC 5/9673 ATL IAP HARTSFIELD/JACKSON ATLANTA INTL, ATLANTA, GA.
RNAV (GPS) RWY 8R, AMDT 5...
LNAV/VNAV DA 1516/HAT 492 ALL CATS, VIS ALL CATS 1 3/8. LNAV MDA 1620/HAT 596 ALL CATS, VIS CATS C/D 1 3/4. VDP 1.7NM TO RW08R. TEMPORARY CRANE 1305 MSL 3981FT SW OF RWY 8R (2025-ASO-3650-NRA). TEMPORARY CRANES UP TO 1268 MSL 4010FT SW OF RWY 8R (2024-ASO-5839 THRU 5843-NRA). TEMPORARY CRANE 1240 MSL 3981FT SW OF RWY 8R (2023-ASO-3161-NRA).
2510311609-2701151609EST
10/31/25
1609Z
!FDC 5/9671 ATL IAP HARTSFIELD/JACKSON ATLANTA INTL, ATLANTA, GA.
RNAV (GPS) RWY 09L, AMDT 4D...
LPV DA 1444/HAT 425 ALL CATS, VIS ALL CATS 1 1/4. LNAV/VNAV DA 1516/HAT 497 ALL CATS, VIS ALL CATS 1 3/8. LNAV MDA 1620/HAT 601 ALL CATS, VIS CATS C/D 1 3/4. VDP 1.7 NM TO RW09L. TEMPORARY CRANE 1305 MSL 2552FT N OF RWY 9L (2025-ASO-3650-NRA). TEMPORARY CRANE 1240 MSL 2552FT N OF RWY 9L (2023-ASO-3161-NRA). TEMPORARY CRANE 1240 MSL 1067FT NW OF RWY 9L (2023-ASO-3166-NRA). TEMPORARY CRANES UP TO 1268 MSL 2354FT N OF RWY 9L (2024-ASO-5839 THRU 5843-NRA).
2510311609-2701151609EST
10/31/25
1609Z
!FDC 5/9669 ATL IAP HARTSFIELD/JACKSON ATLANTA INTL, ATLANTA, GA.
RNAV (GPS) RWY 9R, AMDT 4B...
LNAV/VNAV DA 1516/HAT 490 ALL CATS, VIS ALL CATS RVR 5000. LNAV MDA 1620/HAT 594 ALL CATS, VIS CATS C/D 1 1/4. VDP 1.6 NM TO RW09R. TEMPORARY CRANE 1305 MSL 3585FT N OF RWY 9R (2025-ASO-3650-NRA). TEMPORARY CRANES UP TO 1268 MSL 2966FT N OF RWY 9R (2024-ASO-5839 THRU 5843-NRA). TEMPORARY CRANE 1240 MSL 2552FT N OF RWY 9L (2023-ASO-3161-NRA). TEMPORARY CRANE 1240 MSL 2055FT N OF RWY 9R (2023-ASO-3166-NRA).
2510311609-2701151609EST
10/31/25
1609Z
!FDC 5/9661 ATL IAP HARTSFIELD/JACKSON ATLANTA INTL, ATLANTA, GA.
RNAV (GPS) Y RWY 08L, AMDT 4A...
LNAV/VNAV DA 1516/HAT 501 ALL CATS, VIS ALL CATS RVR 5500. LNAV MDA 1620/HAT 605 ALL CATS, CIS CATS C/D 1 3/8. VDP 1.7 NM TO RW08L. CHANGE NOTE TO READ: FOR INOP ALSF-2, INCREASE LNAV/VNAV ALL CATS VISIBILITY TO 1 3/8 SM AND LNAV CAT C/D VISIBILITY TO 1 3/4 SM. TEMPORARY CRANE 1305 MSL 4393FT SW OF RWY 8L (2025-ASO-3650-NRA). TEMPORARY CRANES UP TO 1268 MSL 4043FT SW OF RWY 8L (2024-ASO-5839 THRU 5843-NRA). TEMPORARY CRANE 1240 MSL 4393FT SW OF RWY 8L (2023-ASO-3161-NRA).
2510311609-2701151609EST
10/31/25
1602Z
!FDC 5/9657 ATL IAP HARTSFIELD/JACKSON ATLANTA INTL, ATLANTA, GA.
ILS OR LOC RWY 9L, AMDT 11...
S-ILS 9L DA 1444/HAT 425 ALL CATS, VIS ALL CATS 1 1/4. TEMPORARY CRANE 1240 MSL 1067FT NW OF RWY 9L (2023-ASO-3166-NRA).
2510311602-2603261602EST
10/30/25
1416Z
!FDC 5/8981 ATL IAP HARTSFIELD/JACKSON ATLANTA INTL, ATLANTA, GA.
ILS OR LOC RWY 9L, AMDT 11...
VDP NA.
I-HZK DME OUT OF SERVICE.
2510301416-2710311415EST
10/29/25
1552Z
!FDC 5/8266 ATL IAP HARTSFIELD/JACKSON ATLANTA INTL, ATLANTA, GA.
RNAV (RNP) Z RWY 28, AMDT 1...
RNP 0.11 DA 1315/HAT 317 ALL CATS. RNP 0.30 DA 1382/HAT 384, VIS RVR 2600 ALL CATS.
2510291552-2710291552EST
9/29/25
1622Z
!FDC 5/1984 ATL IAP HARTSFIELD - JACKSON ATLANTA INTL, ATLANTA, GA.
RNAV (RNP) Z RWY 26R, AMDT 1...
FOR INOPERATIVE ALS, INCREASE RNP 0.30 DA ALL CATS VISIBILITY TO RVR 6000.
2509291622-2709301622EST
9/10/25
1955Z
!FDC 5/1389 ATL IAP HARTSFIELD/JACKSON ATLANTA INTL, ATLANTA, GA.
ILS RWY 27L (CAT II), AMDT 19 ...
PROCEDURE NA EXCEPT FOR ACFT EQUIPPED WITH RADAR ALITMETER. I-FSQ INNER MARKER OUT OF SERVICE. 2509101955-2604221953EST
9/10/25
1951Z
!FDC 5/1364 ATL IAP HARTSFIELD/JACKSON ATLANTA INTL, ATLANTA, GA.
ILS RWY 9R (CAT II-III), AMDT 20 ...
CAT II NA EXCEPT FOR AIRCRAFT EQUIPPED WITH RADAR ALTIMETER. I-FUN IM OUT OF SERVICE. 2509101951-2604221949EST
7/29/25
1629Z
!FDC 5/6546 ATL IAP HARTSFIELD/JACKSON ATLANTA INTL, ATLANTA, GA.
RNAV (GPS) PRM RWY 9R, ORIG-A...
LNAV/VNAV DA 1516/HAT 490 ALL CATS, VIS ALL CATS RVR 5000. TEMPORARY CRANE 1305 MSL 3585FT N OF RWY 9R (2025-ASO-3650-NRA). TEMPORARY CRANES UP TO 1268 MSL 2966FT N OF RWY 9R (2024-ASO-5839 THRU 5843-NRA). TEMPORARY CRANE 1240 MSL 2552FT N OF RWY 9L (2023-ASO-3161-NRA). TEMPORARY CRANE 1240 MSL 2055FT N OF RWY 9R (2023-ASO-3166-NRA).
2507291629-2701151629EST
7/7/25
1106Z
!FDC 5/3263 ATL IAP HARTSFIELD/JACKSON ATLANTA INTL, ATLANTA, GA.
RNAV (RNP) Z RWY 8L, AMDT 1A...
RNP 0.30 DA 1516/HAT 501 ALL CATS, VIS ALL CATS RVR 5500. CHANGE NOTE TO READ: FOR INOP ALS, INCREASE RNP 0.15 ALL CATS RVR TO 5500 AND RNP 0.30 ALL CATS VISIBILITY TO 1 3/8 SM. TEMPORARY CRANE 1305 MSL 4393FT SW OF RWY 8L (2025-ASO-3650-NRA).
2507071106-2701151106EST
4/10/25
1841Z
!FDC 5/5012 ATL IAP HARTSFIELD/JACKSON ATLANTA INTL, ATLANTA, GA.
ILS OR LOC RWY 10, AMDT 5C ...
ILS RWY 10 (SA CAT I), AMDT 5C ...
ILS PRM RWY 10 (CLOSE PARALLEL), AMDT 5 ...
ILS PRM RWY 10 (SA CAT I)(CLOSE PARALLEL), AMDT 5 ...
ILS PRM RWY 10 (CAT II AND III)(CLOSE PARALLEL), AMDT 5 ...
VGSI AND ILS GLIDEPATH NOT COINCIDENT (VGSI ANGLE 3.00/TCH 69). 2504101841-2704101841EST
4/10/25
1841Z
!FDC 5/5010 ATL IAP HARTSFIELD/JACKSON ATLANTA INTL, ATLANTA, GA.
RNAV (GPS) Y RWY 10, AMDT 4A...
RNAV (RNP) Z RWY 10, AMDT 1...
VGSI AND RNAV GLIDEPATH NOT COINCIDENT (VGSI ANGLE 3.00/TCH 69).
2504101841-2704101841EST
4/10/25
1840Z
!FDC 5/5008 ATL IAP HARTSFIELD/JACKSON ATLANTA INTL, ATLANTA, GA.
RNAV (GPS) PRM Y RWY 28, ORIG-A...
RNAV (GPS) Y RWY 28, AMDT 4A...
RNAV (RNP) Z RWY 28, AMDT 1...
VGSI AND RNAV GLIDEPATH NOT COINCIDENT (VGSI ANGLE 3.00/TCH 72).
2504101840-2704101840EST
Yes
ALL
CITY OF ATLANTA
CITY HALL
ATLANTA, GA 30303
Phone: 404-330-6000
RICKY SMITH
PO BOX 20509
ATLANTA, GA 30320
Phone: 404-530-6600
MACON FSS (MCN)
Toll Free: 1-800-WX-BRIEF
ATL
--
--
N/A
ROTG BCN LCTD S OF TWY R7, N OF TWY SJ2 NR FIRE STATION.
Yes
No
Yes
Hangar
Landing Rights Airport
NOT an Airport of Entry
Major
Major
High & Low Pressure
High & Low Pressure
Air Ambulance
Cargo Handling
Charter Service

Runway 08L/26R

9000 ft. x 150 ft.
CONC
Good
GRVD
HIGH

120,000lbs
200,000lbs
360,000lbs
--
  Runway 08L Runway 26R
True Heading 90°270°
Traffic Pattern
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 33° 38' 58"N 33° 38' 58"N
Longitude 84° 26' 20"W 84° 24' 34"W
Elevation 1,015' 990'
Threshold Crossing Height 70 ft. AGL 69 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights ALSF2 MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 08R/26L

9999 ft. x 150 ft.
CONC
Good
GRVD
HIGH

120,000lbs
200,000lbs
360,000lbs
--
  Runway 08R Runway 26L
True Heading 90°270°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 33° 38' 48"N 33° 38' 48"N
Longitude 84° 26' 18"W 84° 24' 20"W
Elevation 1,024' 995'
Threshold Crossing Height 67 ft. AGL 63 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 09L/27R

12390 ft. x 150 ft.
CONC
Good
GRVD
HIGH

120,000lbs
200,000lbs
360,000lbs
--
  Runway 09L Runway 27R
True Heading 90°270°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 33° 38' 05"N 33° 38' 05"N
Longitude 84° 26' 53"W 84° 24' 26"W
Elevation 1,019' 977'
Threshold Crossing Height 71 ft. AGL 72 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4R
Approach Lights MALS
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 09R/27L

9000 ft. x 150 ft.
CONC
Fair
GRVD
HIGH

120,000lbs
200,000lbs
360,000lbs
--
  Runway 09R Runway 27L
True Heading 90°270°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 33° 37' 55"N 33° 37' 55"N
Longitude 84° 26' 53"W 84° 25' 06"W
Elevation 1,026' 985'
Threshold Crossing Height 70 ft. AGL 79 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4R
Approach Lights ALSF2 ALSF2
Centerline Lights Yes Yes
Runway End Identifier Lights

Runway 10/28

9000 ft. x 150 ft.
CONC
Good
GRVD
HIGH

75,000lbs
209,000lbs
600,000lbs
900,000lbs
  Runway 10 Runway 28
True Heading 90°270°
Traffic Pattern Right
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 33° 37' 13"N 33° 37' 13"N
Longitude 84° 26' 52"W 84° 25' 06"W
Elevation 1,000' 998'
Threshold Crossing Height 69 ft. AGL 72 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4R
Approach Lights ALSF2 ALSF2
Centerline Lights Yes Yes
Runway End Identifier Lights
A110-11ALL RWYS, TOUCH AND GO OPERATIONS, LOW APPROACHES, AND PRACTICE INSTRUMENT APPROACHES NOT PERMITTED.
A110-12ACFT WITH A WINGSPAN OF GREATER THAN 214FT ARE RESTRICTED FM USING TWY F EAST OF RAMP 5 NORTH AND WEST OF TWY D.
A110-15ACFT WITH WINGSPAN GREATER THAN 171 FT ARE RSTRD FROM USING TWY V. ACFT WITH WINGSPAN GREATER THAN 171 FT ARE REQUIRED TO USE TAXI SPEEDS LESS THAN 15 MPH WHEN PASSING ACFT WITH WINGSPAN GREATER THAN 214FT ON TXWY L/M (EAST OF L7).
A110-16RWY 9L DEPARTURES CAN EXPECT INTERSECTION DEPARTURE FM M2 WITH RWY REMAINING 11,440 FT (TORA/TODA) AND 10,780 (ASDA).
A110-17ALL ACFT WITH WINGSPANS GREATER THAN 214 FT ARE REQUIRED TO USE TAXI SPEEDS NOT GREATER THAN 15 MPH ON TWYS A, L, M, AND SJ.
A110-18WHEN ACFT WITH WINGSPANS GREATER THAN 214 FT ARE PRESENT ON THE FIELD, ALL OTHER ACFT MUST ADHERE TO THE TWY CENTERLINE ON TWYS L AND M, TWYS E AND F, AND TWYS SC AND SJ BETWEEN SG AND R DUE TO SEPARATION BETWEEN THE PARALLEL TWYS.
A110-20TWO ACFT WITH WINGSPANS GREATER THAN 225 FT MAY NOT TAXI SIMULTANEOUSLY ON ADJACENT PARALLEL TWYS L/M EXCEPT WEST OF L7 AT SPEEDS LESS THAN 15 MPH. NO ACFT WITH WINGSPAN 226 FT OR GTR CAN TAXI ON TWY M BTN L14 AND L16, TWY N BTN P AND SC, OR TWY N BTN U AND K.
A110-21NO ACFT WITH WINGSPAN GREATER THAN 213 FT MAY PASS ANOTHER ACFT WITH WINGSPAN GREATER THAN OR EQUAL TO 225 FT ON TWY L/M EAST OF L7.
A110-23ACFT WITH WINGSPAN GTR THAN 171 FT AND/OR TAIL HGT GTR THAN 45 FT ARE RSTD FROM USING TWY W. DURG TWY W OPNS RWY 27R INTXN DEPS FROM TWY LB OR TWY LC CAN EXPC THE FLWG DSTCS WITH RWY RMNG: FROM TWY LB 11,040 FT (TORA/TODA) AND 12,140 FT (ASDA); FROM TWY LC 10,810 FT (TORA/TODA) AND 11,910 FT (ASDA). ACFT MAY REQ THE FULL LEN OF RWY 27R FOR DEP UPON INITIAL CTC WITH ATC.
A110-24BIRD ACT ON AND INVOF ARPT.
A110-26ACFT SHOULD NOT EXCT THE ACUTE ANGLED TWY TURN EBND TO NBND FROM TWY N TO TWY J.
A110-27WHEN ACFT WITH WINGSPAN GREATER THAN OR EQUAL TO 172FT IS PRESENT ON TWY E BTN TWY E13 & APCH END RWY 26L, NO ACFT WITH WINGSPAN GREATER THAN OR EQUAL TO 144FT MAY BE PRESENT ON ECHO PAD.
A110-3BE ALERT TO RWY CROSSING CLEARANCES. READBACK OF ALL RWY HOLDING INSTRUCTIONS IS REQUIRED.
A110-7PREFERENTIAL RWY USE IN EFFECT, EXPECT TO USE RWYS 08R/26L, 09L/27R FOR DEPS; RWYS 08L/26R, 09R/27L ARE USED PRIMARILY FOR ARRIVALS.
A110-8RUNUPS ARE PERMITTED AT VARIOUS SITES; COORD USE OF CITY FACS, MOVEMENT AREAS, ALLOWABLE NON-MOVEMENT AREAS WITH DEPT OF AVN OPNS, 404-787-6095; AND COORD THE USE OF THE AIRLINES FACS WITH THEM.
A110-9NOISE & OPNS MONITORING SYSTEM (NOMS) PROGRAM IN EFFECT; CALL THE ATLANTA DEPT OF AVIATION 770-43-NOISE OR 770-436-6473 FOR MORE INFO.
A39-08L/26RPCR VALUE: 1437/R/D/W/T
A39-08R/26LPCR VALUE: 1307/R/C/W/T
A39-09L/27RPCR VALUE: 1336/R/C/W/T
A39-09R/27LPCR VALUE: 1068/R/C/W/T
A39-10/28PCR VALUE: 1378/R/C/W/T
A43-26LPAPI RWY 26L UNUSBL BYD 7 DEG LEFT AND RIGHT OF RCL.
A43-26RPAPI RWY 26R UNUSBL BYD 6 DEG LEFT AND 7 DEG RIGHT OF RCL.
A52-09LCONCRETE HOPPER
A80ROTG BCN LCTD S OF TWY R7, N OF TWY SJ2 NR FIRE STATION.
HARTSFIELD/JACKSON ATLANTA INTL (ICAO: KATL, IATA: ATL) is a public airport located in ATLANTA, GA, US.
