KAFO
AFTON LINCOLN COUNTY/GENERAL BOYD L EDDINS FLD
PublicPUB

1 miles SW of AFTON, WY
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
42° 42' 32"N 110° 56' 32"W
6221' MSL
7221' MSL
14E
JET A, 100LL
CASPER (CPR)
SALT LAKE CITY
SALT LAKE CITY (ZLC)
4/17/25-5/15/25
KAFO VFR
4:55 AM MDT
Broken 12,000'
10sm
54°F
39°F
30.26"Hg
090° 4kts
AO2
KAFO 241055Z AUTO 09004KT 10SM BKN120 12/04 A3026 RMK AO2
+ Add Your Business

KAFO FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

AWOS-3P

AWOS-3P
307-885-2654
 119.025

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KBPI (38nm)
Sat, 8/23 11:20 PM MDT
Sun, 8/24 12:00 AM MDT - Mon, 8/25 12:00 AM MDT
VFR
12:00 AM MDT - 5:00 AM MDT
Scattered 20,000'
Few 12,000'
6sm
330° 7kts
VFR
5:00 AM MDT - 3:00 PM MDT
Broken 20,000'
Few 8,000'
6sm
150° 6kts
VFR
3:00 PM MDT - 7:00 PM MDT
Overcast 15,000'
Scattered 9,000'
6sm
300° 11kts
VFR
7:00 PM MDT - 9:00 PM MDT
Broken 15,000'
Scattered 9,000'
6sm
170° 18kts
Gusts 28kts
VFR
9:00 PM MDT - 12:00 AM MDT
Scattered 12,000'
Scattered 8,000'
6sm
190° 11kts
KBPI 240520Z 2406/2506 33007KT P6SM FEW120 SCT200
   FM241100 15006KT P6SM FEW080 BKN200
   FM242100 30011KT P6SM SCT090 OVC150
   FM250100 17018G28KT P6SM SCT090 BKN150
   FM250300 19011KT P6SM SCT080 SCT120
KAFO
No NOTAM Available
No
MON-FRI 0800-1700
TOWN OF AFTON
BOX 1181
AFTON, WY 83110
Phone: (307) 885-9831
RICK SESSIONS
BOX 1181
AFTON, WY 83110
Phone: 307-885-3245
CASPER FSS (CPR)
Toll Free: 1-800-WX-BRIEF
CPR
--
ACTVT REIL RWY 16 & 34; MIRL RWY 16/34 - CTAF. PAPI RWY 16 & 34 OPR CONSLY.
N/A
Yes - Lighted
Yes
Yes
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Major
Major
None
Low Pressure
Pilot Instruction

Runway 16/34

7025 ft. x 75 ft.
ASPH
Good
NONE
MED

24,000lbs
--
--
--
  Runway 16 Runway 34
True Heading 180°0°
Traffic Pattern Right
Markings NPI NPI
Markings Condition FAIR FAIR
Latitude 42° 43' 06"N 42° 41' 57"N
Longitude 110° 56' 32"W 110° 56' 32"W
Elevation 6,188' 6,221'
Threshold Crossing Height 52 ft. AGL 52 ft. AGL
Visual Glide Path Angle 3.5° 3.5°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes
A110-1SNBNKS 4 FT TO 7 FT ALG RWYS & TXYS EDGES FM NOV-APR WITH SLICK SPOTS ALL SFCS.
A110-2COLD TEMPERATURE AIRPORT. ALTITUDE CORRECTION REQUIRED AT OR BELOW -18C.
A110-3FOR CD CTC SALT LAKE ARTCC AT 801-320-2568.
A110-4WILDLIFE ON & INVOF ARPT.
AFTON LINCOLN COUNTY/GENERAL BOYD L EDDINS FLD (ICAO: KAFO, IATA: AFO) is a public airport located in AFTON, WY.
