No Certified Airport Diagram Available
LiveATC.net: Live Air Traffic - From Their Headsets to You

F70
FRENCH VALLEY
PublicPUB

2 miles NE of MURRIETA/TEMECULA, CA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
33° 34' 27"N 117° 07' 43"W
1350' MSL
2350' MSL
13E
JET A, 100LL
RIVERSIDE (RAL)
LOS ANGELES
LOS ANGELES (ZLA)
12/26/24-1/23/25
No METAR is available for this location.
Add Your Business

F70 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

AWOS-3

AWOS-3
951-696-1018
 119.025

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

No TAF is available for this location.
F70
FDC
3/15/241556Z !FDC 4/7757 F70 ODP FRENCH VALLEY, MURRIETA/TEMECULA, CA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
DEPARTURE PROCEDURE NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
HDF VOR OUT OF SERVICE. 2403151556-2506181556EST
10/6/231519Z !FDC 3/1672 F70 ODP FRENCH VALLEY, MURRIETA/TEMECULA, CA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
DEPARTURE PROCEDURE : RWY 36, CLIMB RUNWAY HEADING TO 2200, THEN CLIMBING LEFT TURN VIA HDF R-145 TO HDF VOR. AIRCRAFT DEPARTING HDF VOR 065 CW 352 CLIMB ON COURSE. AIRCRAFT DEPARTING NORTHEAST BOUND, CLIMB IN HDF VOR HOLDING PATTERN, (SE, RIGHT TURNS, 315 INBOUND) TO DEPART HDF VOR AT OR ABOVE: 353 CW 054, 8000; 055 CW 064, 5800; BEFORE PROCEEDING ON COURSE.
TAKEOFF OBSTACLE NOTES: RWY 36: VEHICLES ON ROAD BEGINNING 500 FT FROM DER, 140 FT RIGHT OF CENTERLINE, 3 FT AGL/1364 FT MSL TREES BEGINNING 994 FT FROM DER, 570 FT RIGHT OF CENTERLINE, 50 FT AGL/1416 MSL. 2310061519-2510061518EST
No
0600-1800
COUNTY OF RIVERSIDE
4080 LEMON STREET, 14TH FLOOR
RIVERSIDE, CA 92501
Phone: 951-955-9722
ANGELA JAMISON
4080 LEMON STREET, 14TH FLOOR
RIVERSIDE, CA 92501
Phone: 951-955-9418
RIVERSIDE FSS (RAL)
Toll Free: 1-800-WX-BRIEF
RAL
--
ACTVT REIL RWY 18 & 36; PAPI RWY 18 & 36; MIRL RWY 18/36; TWY LGTS - CTAF.
N/A
Yes - Lighted
Yes
No
Tie-Down
No
0
0
0
0
0
0
Major
Major
Low Pressure
None
Air Ambulance
Avionics
Charter Service
Pilot Instruction
Aircraft Rental

Runway 18/36

6000 ft. x 75 ft.
ASPH
Good
NONE
MED

30,000lbs
58,000lbs
--
--
  Runway 18 Runway 36
True Heading 192°12°
Traffic Pattern Right
Markings NPI BSC
Markings Condition GOOD GOOD
Latitude 33° 34' 56"N 33° 33' 58"N
Longitude 117° 07' 35"W 117° 07' 50"W
Elevation 1,350' 1,340'
Threshold Crossing Height 40 ft. AGL 40 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes
A110-3ALL DEPS - NOISE SENSITIVE AREAS IN VCNTY OF ARPT. BEST ROC RCMDD TO TFC PAT ALT BFR DEPARTING THE PAT. CALM WIND RWY 18.
A110-4FOR CD CTC MARCH APCH AT 951-655-2355; WHEN MARCH APCH CLSD CTC SOCAL APCH AT 800-448-3724.
FRENCH VALLEY (IATA: F70) is a public airport located in MURRIETA/TEMECULA, CA.
