CHINLE MUNI - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

E91
Local E91
CHINLE MUNI
PublicPUB

3 miles SW of CHINLE, AZ, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
36° 06' 33"N 109° 34' 32"W
Elevation
5550' MSL
Pattern Alt
6550' MSL
Mag Variation
9°E
Declination
11°E
Fuel
None Listed
FSS
PRESCOTT (PRC)
Sectional
DENVER
ARTCC
DENVER (ZDV)
Data Effective
2/19/26-3/19/26
KRQE (37nm) VFR
6:53 PM MST
Clear
10sm
47°F
10°F
30.02"Hg
210° 5kts
AO2 SLP146 T00831122
METAR KRQE 050153Z AUTO 21005KT 10SM CLR 08/M12 A3002 RMK AO2 SLP146 T00831122
+ Add Your Business

E91 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.9
ACTVT PAPI RWY 36; MIRL RWY 18/36 - CTAF.

Center

DENVER CENTER 127.55
LOW, APCH/DEP CTL SVC PRVDD BY DENVER ARTCC (ZDV) ON 127.55/256.875 (TUBA CITY RCAG).

FAA A/FD Pages

Terminal Area Forecast

KGUP (52nm)
Wed, 3/4 4:25 PM MST
Wed, 3/4 5:00 PM MST - Thu, 3/5 5:00 PM MST
VFR
5:00 PM MST - 7:00 PM MST
Few 25,000'
6sm
240° 10kts
VFR
7:00 PM MST - 10:00 AM MST
Scattered 25,000'
6sm
VRB° 3kts
VFR
10:00 AM MST - 2:00 PM MST
Scattered 20,000'
6sm
230° 14kts
Gusts 24kts
VFR
2:00 PM MST - 5:00 PM MST
Broken 20,000'
6sm
240° 25kts
Gusts 35kts
TAF KGUP 042325Z 0500/0524 24010KT P6SM FEW250
   FM050200 VRB03KT P6SM SCT250
   FM051700 23014G24KT P6SM SCT200
   FM052100 24025G35KT P6SM BKN200
E91
No NOTAM Available
No
UNATNDD
NAVAJO NATION
P.O. BOX 9000
WINDOW ROCK, AZ 86515
Phone: 505-371-8325
KYRON HARDY
P.O. BOX 4620
WINDOW ROCK, AZ 86515
Phone: 505-371-8323
PRESCOTT FSS (PRC)
Toll Free: 1-800-WX-BRIEF
PRC
--
ACTVT PAPI RWY 36; MIRL RWY 18/36 - CTAF.
Green Only
Yes - Lighted
Yes
No
Tie-Down
No
None
None
None
None
Air Ambulance

Runway 18/36

6902 ft. x 60 ft.
ASPH
Good
NONE
MED

12,000lbs
--
--
--
  Runway 18 Runway 36
True Heading 187°7°
Traffic Pattern
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 36° 07' 07"N 36° 05' 60"N
Longitude 109° 34' 26"W 109° 34' 37"W
Elevation 5,526' 5,550'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-2FOR CD CTC DENVER ARTCC AT 303-651-4257.
A110-4PRKG APRON HAS LRG CRACKS & LOOSE AGGREGATE.
A81-APTACTVT PAPI RWY 36; MIRL RWY 18/36 - CTAF.
CHINLE MUNI (IATA: E91) is a public airport located in CHINLE, AZ, US.
