8S3
SANTIAM JUNCTION STATE
PublicPUB

0 miles S of SANTIAM JUNCTION, OR
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
44° 26' 04"N 121° 56' 32"W
3780' MSL
4780' MSL
19E
None Listed
MC MINNVILLE (MMV)
KLAMATH FALLS
SEATTLE (ZSE)
7/11/24-8/8/24
KRDM (36nm) VFR
2:56 AM PDT
Clear
10sm
47°F
40°F
30.01"Hg
Calm
AO2 SLP147 T00830044 $
KRDM 190956Z AUTO 00000KT 10SM CLR 08/04 A3001 RMK AO2 SLP147 T00830044 $
Add Your Business

8S3 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- 122.9

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

KRDM (36nm)
Wed, 9/18 10:20 PM PDT
Wed, 9/18 11:00 PM PDT - Thu, 9/19 11:00 PM PDT
VFR
11:00 PM PDT - 1:00 PM PDT
Sky Clear
6sm
150° 3kts
VFR
1:00 PM PDT - 11:00 PM PDT
Sky Clear
6sm
320° 9kts
KRDM 190520Z 1906/2006 15003KT P6SM SKC
   FM192000 32009KT P6SM SKC
8S3
Domestic
9/5/241838Z !MMV 09/024 8S3 RWY 06/24 CLSD EXC FIRE FIGHTING ACFT 2409051838-2409272359
No
UNATNDD
STATE HIGHWAY MAINTENANCE STATION NEARBY.
OREGON DEPT OF AVIATION
3040 25TH ST SE
SALEM, OR 97302
Phone: 503-378-4880
ANTHONY BEACH
3040 25TH ST SE
SALEM, OR 97302
Phone: 503-378-4880
MC MINNVILLE FSS (MMV)
Toll Free: 1-800-WX-BRIEF
MMV
--
--
N/A
Yes
Yes
No
None
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
None

Runway 06/24

2800 ft. x 150 ft.
GRAVEL
Good
NONE


--
--
--
--
  Runway 06 Runway 24
True Heading Not ListedNot Listed
Traffic Pattern Left Left
Markings
Markings Condition
Latitude N/A N/A
Longitude N/A N/A
Elevation -- --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1ARPT SURROUNDED BY TREES AND HIGH TERRAIN.
A110-3OWNER ADVISES CONTACT WITH DEPT OF AVIATION (503-378-4880) PRIOR TO USE.
A110-4ARPT CLSD NOV 1- MAY 1 OR WHEN COVERED BY SNOW.
A110-5RY THLDS MARKED WITH WHITE TIRES AT CORNERS.
A110-6FOR CD CTC SEATTLE ARTCC AT 253-351-3694.
A110-7SFC CONDS NOT RPRTD
SANTIAM JUNCTION STATE (IATA: 8S3) is a public airport located in SANTIAM JUNCTION, OR.
