3/7/251343Z
|
!FDC 5/0423 82C PART 1 OF 2 ODP MAUSTON/NEW LISBON UNION,
NEW LISBON, WI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG-A...
NOTE: RWY 14: TAKEOFF OBSTACLE NOTES: NOTE: RWY 14: TREE 20 FT FROM
DER, 470 FT RIGHT OF CENTERLINE, 925 FT MSL. TRAVERSE WAY BEGINNING
22 FT FROM DER, 213 FT LEFT OF CENTERLINE, UP TO 907 FT MSL. TREES
BEGINNING 152 FT FROM DER, 14 FT RIGHT OF CENTERLINE, UP TO 965 FT
MSL. TREE 716 FT FROM DER, 440 FT LEFT OF CENTERLINE, 944 FT MSL.
TREES BEGINNING 785 FT FROM DER, 217 FT LEFT OF CENTERLINE, UP TO
958 FT MSL. TREES BEGINNING 893 FT FROM DER, 365 FT LEFT OF
CENTERLINE, UP TO 965 FT MSL. TREE 1088 FT FROM DER, 353 FT LEFT OF
CENTERLINE, 969 FT MSL. TREES BEGINNING 1177 FT FROM DER, 39 FT
LEFT OF CENTERLINE, UP TO 976 FT MSL. TREES BEGINNING 2119 FT FROM
DER, 202 FT RIGHT OF CENTERLINE, UP TO 987 FT MSL. TREES BEGINNING
2419 FT FROM DER, 152 FT LEFT OF CENTERLINE, UP TO 985 FT MSL.
NOTE: RWY 32: FENCE 67 FT FROM DER, 301 FT RIGHT OF CENTERLINE, 912
FT MSL. TRAVERSE WAY 72 FT FROM DER, 466 FT LEFT OF CENTERLINE, 930
FT MSL. TREES, TRAVERSE WAYS, SIGNS BEGINNING 110 FT FROM DER, 39
FT LEFT OF CENTERLINE, UP TO 961 FT MSL. TREES, FENCE BEGINNING 133
FT FROM DER, 114 FT RIGHT OF CENTERLINE, UP TO 946 FT MSL. TREES
BEGINNING 284 FT FROM DER, 200 FT RIGHT OF CENTERLINE, UP TO 972 FT
MSL. TREES, TRAVERSE WAYS BEGINNING 425 FT FROM DER, 157 FT RIGHT
ALL OTHER DATA REMAINS AS PUBLISHED. 2503071343-2510171343EST
END PART 1 OF 2
!FDC 5/0423 82C PART 2 OF 2 ODP MAUSTON/NEW LISBON UNION,
NEW LISBON, WI.
OF CENTERLINE, UP TO 978 FT MSL. TREES, TRAVERSE WAYS BEGINNING 574
FT FROM DER, 6 FT RIGHT OF CENTERLINE, UP TO 987 FT MSL. TREES,
BUILDING BEGINNING 1846 FT FROM DER, 149 FT LEFT OF CENTERLINE, UP
TO 1003 FT MSL. TREE 2056 FT FROM DER, 175 FT RIGHT OF CENTERLINE,
988 FT MSL. TREE, BUILDINGS BEGINNING 2165 FT FROM DER, 249 FT
RIGHT OF CENTERLINE, UP TO 1007 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2503071343-2510171343EST
END PART 2 OF 2
|
