5V4
Local 5V4
CALHAN
PublicPUB

1 miles N of CALHAN, CO, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
39° 02' 54"N 104° 17' 35"W
Elevation
6450' MSL
Pattern Alt
7250' MSL
Mag Variation
7°E
Declination
11°E
Fuel
None Listed
FSS
DENVER (DEN)
Sectional
DENVER
ARTCC
DENVER (ZDV)
Data Effective
2/19/26-3/19/26
KFLY (14nm) MVFR
8:55 PM MST
Rain
Overcast 2,100'
Broken 1,400'
10sm
36°F
34°F
30.24"Hg
360° 7kts
AO2 T00210010
METAR KFLY 040355Z AUTO 36007KT 10SM RA BKN014 OVC021 02/01 A3024 RMK AO2 T00210010
+ Add Your Business

5V4 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.725
DUSK-DAWN. ACTVT NSTD LIRL RY 17/35 & VASI RY 17 - CTAF.
UNICOM 122.725

FAA A/FD Pages

Terminal Area Forecast

KCOS (23nm)
Tue, 3/3 6:02 PM MST
Tue, 3/3 6:00 PM MST - Wed, 3/4 5:00 PM MST
MVFR
6:00 PM MST - 12:00 AM MST
Light Showers and Rain
Overcast 2,000'
6sm
340° 8kts
MVFR
7:00 PM MST - 12:00 AM MST
Light Snow and Rain
Overcast 1,500'
3sm
Calm
MVFR
Temporary 12:00 AM MST - 3:00 AM MST
Mist
Broken 1,500'
5sm
Calm
VFR
12:00 AM MST - 8:00 AM MST
Scattered 9,000'
Few 1,500'
6sm
330° 5kts
VFR
8:00 AM MST - 11:00 AM MST
Sky Clear
6sm
160° 6kts
VFR
11:00 AM MST - 5:00 PM MST
Mist
Broken 25,000'
6sm
160° 6kts
TAF KCOS 040102Z 0401/0424 34008KT 6SM -SHRA OVC020
   PROB30 0402/0407 3SM -SNRA OVC015
   FM040700 33005KT P6SM FEW015 SCT090
   TEMPO 0407/0410 5SM BR BKN015
   FM041500 16006KT P6SM SKC
   FM041800 16006KT 6SM BR BKN250
5V4
EffectiveExpiresCategoryNOTAM
Domestic
1/19/26
1632Z
3/19/26
2359Z
!DEN 01/426 5V4 OBST TOWER LGT (ASR 1007397) 391810.00N1040851.00W (16.7NM NNE 5V4) 6518.7FT (339.9FT AGL) U/S 2601191632-2603192359
No
IREG
EDWARD GLASER
PO BOX 38
CALHAN, CO 80808
Phone: 719-347-2338
DAVID E GLASER
PO BOX 69
CALHAN, CO 80808
Phone: 719-338-2149
DENVER FSS (DEN)
Toll Free: 1-800-WX-BRIEF
DEN
--
DUSK-DAWN. ACTVT NSTD LIRL RY 17/35 & VASI RY 17 - CTAF.
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
No
None
None
None
None
None

Runway 17/35

4565 ft. x 50 ft.
TURF GRVL
Good
NONE
NSTD

--
--
--
--
  Runway 17 Runway 35
True Heading 180°0°
Traffic Pattern Left Right
Markings
Markings Condition
Latitude 39° 03' 16"N 39° 02' 31"N
Longitude 104° 17' 35"W 104° 17' 35"W
Elevation -- --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator TRIL --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1S END OF RY HAS SIDE SLOPE. -6 FT DITCH 40 FT W OF CNTRLN. GROUND RISES ON EAST SIDE OF RY.
A110-11BE ALERT; INTENSIVE USAF STUDENT TRAINING IN VICINITY OF COLORADO SPRINGS & PUEBLO COLORADO.
A110-12RY 17/35 HAS +15 FT ROAD 110 FT FM & PARALLEL TO RY CNTRLN W SIDE OF RY - FULL LENGTH.
A110-13RWY 35 HAS 4 FT FENCE 200 FT FM THLD OB; APPX 20 FT TREES 70 FT WEST OF CNTRLN FOR FIRST 500 FT OF RWY; APPX 25 FT P-LINE 850 FT FM THLD OB; APPX 2 FT BURM AT RWY THLD.
A110-14FOR CD CTC COLORADO SPRINGS APCH AT 719-556-9105.
A110-2AEROBATIC PRACTICE AREA ONE-HALF MILE W OF RY 17/35 300 FT AGL TO 10000 FT MSL.
A110-3VEHICLES CROSSING RY.
A110-4RWY 17 HAS 25 FT P-POLE 400 FT FM THLD, 110 FT R OF CNTRLN.
A16ALTERNATE NUMBER 719-347-2338
A32-17/35WIDTH VARIES FM 50 FT TO 100 FT.
A33-17/35_SURFRY 17 FIRST 1250 FT 45 FT WIDE ARTIFICIAL TURF.
A40-17/35RY 17/35 NSTD LIRL. NORTH 3000 FT RY LIGHTED.
A81-APTDUSK-DAWN. ACTVT NSTD LIRL RY 17/35 & VASI RY 17 - CTAF.
E111PROVIDED A NON-STD RIGHT-HAND TFC PAT IS CONDUCTED TO RWY 35.
CALHAN (IATA: 5V4) is a public airport located in CALHAN, CO, US.
