MAVERICK COUNTY MEML INTL - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

5T9
Local 5T9
MAVERICK COUNTY MEML INTL
PublicPUB

8 miles N of EAGLE PASS, TX, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
28° 51' 26"N 100° 30' 48"W
Elevation
887' MSL
Pattern Alt
1887' MSL
Mag Variation
5°E
Declination
6°E
Fuel
JET A, 100LL
FSS
SAN ANGELO (SJT)
Sectional
SAN ANTONIO
ARTCC
HOUSTON (ZHU)
Data Effective
2/19/26-3/19/26
K5T9 VFR
7:50 PM CST
Clear
10sm
81°F
52°F
29.85"Hg
130° 7kts
A01
METAR K5T9 040150Z AUTO 13007KT 10SM CLR 27/11 A2985 RMK A01
+ Add Your Business

5T9 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

AWOS-3 119.175
(830) 757-6795

Common

CTAF 122.8
DUSK-DAWN. MIRL RWY 13/31 PRESET LOW INTST; TO INCR INTST ACTVT - CTAF.
UNICOM 122.8

Approach

DEL RIO APPROACH 127.75

Departure

DEL RIO DEPARTURE 127.75

Center

DEL RIO CENTER 125.75
LOW, APCH/DEP CTL SVC PRVDD BY HOUSTON ARTCC (ZHU) ON FREQS 125.75/346.4 (ROCK SPRINGS RCAG) WHEN DEL RIO APCH CTL (DLF) CLSD.

Flight Service

Flight Service 122.3
(SJT)

FAA A/FD Pages

Airport Minimums

Instrument Approach

Terminal Area Forecast

MMPG (14nm)
Tue, 3/3 11:33 AM CST
Tue, 3/3 12:00 PM CST - Wed, 3/4 12:00 PM CST
MVFR
12:00 PM CST - 2:00 PM CST
Haze
Scattered 3,000'
5sm
170° 10kts
VFR
2:00 PM CST - 9:00 PM CST
Sky Clear
6sm
180° 10kts
Gusts 20kts
VFR
9:00 PM CST - 12:00 AM CST
Scattered 2,000'
6sm
160° 5kts
MVFR
12:00 AM CST - 10:00 AM CST
Broken 1,500'
6sm
140° 10kts
VFR
10:00 AM CST - 12:00 PM CST
Broken 20,000'
Scattered 3,000'
6sm
160° 5kts
TAF MMPG 031733Z 0318/0418 17010KT 5SM HZ SCT030
   FM032000 18010G20KT P6SM SKC
   FM040300 16005KT P6SM SCT020
   FM040600 14010KT 6SM BKN015
   FM041600 16005KT P6SM SCT030 BKN200
5T9
EffectiveExpiresCategoryNOTAM
Domestic
2/25/26
0251Z
2/25/26
0848Z
!SJT 02/312 5T9 AIRSPACE SEE ZHU 02/453 UAS 2602250251-2602250848
2/25/26
0021Z
2/25/26
0800Z
!SJT 02/310 5T9 AIRSPACE SEE ZHU 02/450 UAS 2602250021-2602250800
2/25/26
0018Z
2/25/26
0800Z
!SJT 02/309 5T9 AIRSPACE SEE ZHU 02/449 UAS 2602250018-2602250800
2/25/26
0018Z
2/25/26
0800Z
!SJT 02/308 5T9 AIRSPACE SEE ZHU 02/448 UAS 2602250018-2602250800
2/25/26
0008Z
2/25/26
0800Z
!SJT 02/307 5T9 AIRSPACE SEE ZHU 02/447 UAS 2602250008-2602250800
12/9/25
1427Z
3/3/26
2359Z
!SJT 12/131 5T9 AIRSPACE SEE ZHU 12/170 UAS 2512091427-2603032359
FDC
2/23/26
1734Z
!FDC 6/8751 5T9 IAP MAVERICK COUNTY MEML INTL,
EAGLE PASS, TX.
RNAV (GPS) RWY 31, ORIG-A...
LNAV CAT C VISIBILITY 1 1/8. DELETE NOTE DME/DME RNP-0.3 NA. PBN
REQUIREMENTS NOTE: RNP APCH - GPS. CHART NOTE: FOR UNCOMPENSATED
BARO-VNAV SYSTEMS, LNAV/VNAV NA BELOW -16C OR ABOVE 54C. ALTERNATE
MINIMUMS: STANDARD. DELETE *LNAV ONLY. CHANGE MIN ALT AT OCILU TO
READ: OCILU/1.50 NM TO RW31 1400. DELETE NOTE: USE LAUGHLIN AFB
ALTIMETER SETTING; WHEN NOT RECEIVED, USE DEL RIO INTL ALTIMETER
SETTING. DELETE NOTE: BARO-VNAV NA. DELETE CHART: LAUGHLIN AFB
ATIS, 114.4.
THIS IS RNAV (GPS) RWY 31, ORIG-B. 2602231734-PERM
No
MON-FRI 0830-1400
SAT-SUN 1000-1600
COUNTY OF MAVERICK
500 QUARRY
EAGLE PASS, TX 78852
Phone: 830-773-3824
RAUL PEREZ
500 QUARRY STREET, SUITE 3
EAGLE PASS, TX 78852
Phone: 830-773-9636
SAN ANGELO FSS (SJT)
Toll Free: 1-800-WX-BRIEF
SJT
--
DUSK-DAWN. MIRL RWY 13/31 PRESET LOW INTST; TO INCR INTST ACTVT - CTAF.
N/A
Yes - Lighted
Yes
No
Tie-Down
NOT a Landing Rights Airport
Airport of Entry
None
None
None
None
None

Runway 13/31

5506 ft. x 100 ft.
ASPH
Poor
NONE
MED

--
--
--
--
  Runway 13 Runway 31
True Heading 135°315°
Traffic Pattern
Markings NPI NPI
Markings Condition POOR POOR
Latitude 28° 51' 45"N 28° 51' 06"N
Longitude 100° 31' 10"W 100° 30' 27"W
Elevation 887' 882'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1FLIGHT NOTIFICATION SERVICE (ADCUS) AVBL.
A110-2FOR CD CTC LAUGHLIN APCH AT 830-298-5192, WHEN APCH CLSD CTC HOUSTON ARTCC AT 281-230-5622.
A110-3TWYS - EXTSV CRACKING, LOOSE STONES, VEGETATION, NO MRKGS, NO LGTS.
A110-4RWY 31 - PAVEMENT MRKG INDCS RWY 30.
A110-5OLD RWY MKGS SHOW IN PAVED AREA APRXLY 300 FT BFR EACH RWY END.
A16ARPT OFC PHONE 830-773-9636.
A33-13/31_CONDEXTSV CRACKING, VEGETATION.
A42-13_CONDRWY MRKGS FADED. AIMING POINT IN OLD RWY APPRS BFR THR.
A42-31_CONDRWY MRKGS FADED. AIMING POINT IN OLD RWY APPRS BFR THR.
A58-1318 FT BRUSH 0-199 FT DSTC 185 FT LEFT.
A58-3118 FT BRUSH 0-199 FT DSTC, 200 FT RIGHT.
A81-APTDUSK-DAWN. MIRL RWY 13/31 PRESET LOW INTST; TO INCR INTST ACTVT - CTAF.
MAVERICK COUNTY MEML INTL (IATA: 5T9) is a public airport located in EAGLE PASS, TX, US.
