5M5
CRYSTAL LAKE
PublicPUB

2 miles NE of DECATUR, AR
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
36° 20' 37"N 94° 26' 41"W
1178' MSL
2178' MSL
03E
None Listed
JONESBORO (JBR)
KANSAS CITY
MEMPHIS (ZME)
7/11/24-8/8/24
KXNA (7nm) VFR
5:53 AM CDT
Clear
10sm
67°F
61°F
29.94"Hg
170° 4kts
AO2 SLP122 T01940161
KXNA 191053Z 17004KT 10SM CLR 19/16 A2994 RMK AO2 SLP122 T01940161
Add Your Business

5M5 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

KXNA (7nm)
Thu, 9/19 12:35 AM CDT
Thu, 9/19 1:00 AM CDT - Fri, 9/20 1:00 AM CDT
VFR
1:00 AM CDT - 11:00 AM CDT
Broken 15,000'
Few 10,000'
6sm
160° 5kts
VFR
11:00 AM CDT - 7:00 PM CDT
Scattered 12,000'
Scattered 5,000'
6sm
190° 10kts
VFR
7:00 PM CDT - 1:00 AM CDT
Broken 25,000'
Scattered 12,000'
6sm
170° 7kts
KXNA 190535Z 1906/2006 16005KT P6SM FEW100 BKN150
   FM191600 19010KT P6SM SCT050 SCT120
   FM200000 17007KT P6SM SCT120 BKN250
5M5
Domestic
9/2/240720Z !JBR 09/012 5M5 OBST TOWER LGT (ASR 1268043) 362738.90N0942711.50W (7.0NM N 5M5) 1489.8FT (319.9FT AGL) U/S 2409020720-2410170719
8/28/241509Z !JBR 08/378 5M5 OBST TOWER LGT (ASR 1290417) 363347.70N0942114.60W (13.9NM NNE 5M5) 1331.7FT (259.8FT AGL) U/S 2408281509-2412261509
7/26/241300Z !JBR 07/336 5M5 AIRSPACE SEE RZC 07/335 UAS DLY 1300-0400
2407261300-2501010400
7/4/240122Z !JBR 07/030 5M5 OBST TOWER LGT (ASR 1234422) 362554.30N0943046.80W (6.2NM NNW 5M5) 1739.8FT (500.0FT AGL) U/S 2407040122-2501032359
FDC
8/15/231708Z !FDC 3/4764 5M5 IAP CRYSTAL LAKE, DECATUR, AR.
RNAV (GPS) RWY 13, ORIG-C...
DISREGARD PROFILE NOTE: VGSI AND DESCENT ANGLES NOT COINCIDENT (VGSI ANGLE 3.50/TCH 53).
NORTHWEST ARKANSAS NTL (XNA) ASOS 119.425.
2308151708-2508151708EST
No
UNATNDD
CRYSTAL LAKE FLY-IN COMMUNITY, LLC
33801 KANIS ROAD
PARON, AR 72122
Phone: 501-351-4545
LANCE DIXON
18820 CRYSTAL LAKE ROAD
DECATUR, AR 72722
Phone: 479-220-5047
JONESBORO FSS (JBR)
Toll Free: 1-800-WX-BRIEF
JBR
Sunset to Sunrise
--
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
11
0
0
3
0
0
Major
Major
None
None
Pilot Instruction

Runway 13/31

3863 ft. x 75 ft.
ASPH
Fair
NONE
LOW

10,000lbs
--
--
--
  Runway 13 Runway 31
True Heading 134°314°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition FAIR FAIR
Latitude 36° 20' 50"N 36° 20' 24"N
Longitude 94° 26' 58"W 94° 26' 25"W
Elevation 1,154' 1,176'
Threshold Crossing Height 53 ft. AGL 37 ft. AGL
Visual Glide Path Angle 3.5° 3.5°
Visual Slope Indicator V2L V2L
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1BE ALERT FOR +176 FT TWR APRXLY 1300 FT N OF RY 13.
A110-3DEER & GEESE ON & INVOF ARPT.
A110-4FOR CD CTC RAZORBACK APCH 479-649-2416, WHEN APCH CLSD CTC MEMPHIS ARTCC AT 901-368-8453/8449.
CRYSTAL LAKE (IATA: 5M5) is a public airport located in DECATUR, AR.
